ATEN USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)
ATEN USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View) - 2 Computer(s) - 2 Local User(s) - 328.08 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 5 x USB - DisplayPort - Rack-mountable
| $1,436.65 | Retail $1,873.00 |
- Allows dual view DisplayPort access to a computer and KVM control from a remote console
- Supports HDBaseT 2.0 technology: Extends video, audio, USB, and RS-232 signals via a single Cat6 / 6a / 2L-2910 Cat 6 cable : Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions: Status detection and LED indication for HDBaseT™ signal transmission on the remote unit
- EDID Buffer for smooth power-up and the highest quality display
- Single category cable to transmit AV and control signal : HDBaseT Standard mode up to 4K @ 100 m (via Cat 6 / 6a / 2L-2910); (single view only; dual-view resolution up to 1080p) : HDBaseT Long-Reach mode up to 1080P @ 150 m (single view only; dual-view resolution up to 720p)
- Supports 4 ports USB 2.0 full speed hub on the receiver - allowing to connect up to 4 various USB 2.0 peripheral
- HDCP Compatible
- Supports individual 2-channel stereo audio f
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
173594
Item:
CE924
UPC Code:
672792012426
Our Part #
9AY865
Condition
New
$1,436.65EA
$1,873.00
$1,873.00
Availability
Only 9 Left In Stock
Product description
ATEN USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View) - 2 Computer(s) - 2 Local User(s) - 328.08 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 5 x USB - DisplayPort - Rack-mountable
2 Computer(s) - 2 Local User(s) - 328.08 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 5 x USB - DisplayPort - Rack-mountable
Specifications
Receiver Weight (Approximate)
1.87 lb
Receiver Width
6.13"
Transmitter Depth
6.86"
Transmitter Height
1.13"
Transmitter Weight (Approximate)
1.81 lb
Transmitter Width
6.07"
UPC Alternates
672792012426
Brand Name
ATEN
Certifications & Standards
- CE
- FCC
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
China RoHS
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphic Mode
4K
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
CE924
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The ATEN CE924 USB DisplayPort Dual View HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K video stereo audio USB and RS-232 signals. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as it provides long-reach capability that extends Full HD 1080P signals up to 150 meters. In addition CE924 supports single 4K display or dual 1080p display for DisplayPort video output resolution up to 100m by using a single Cat6 / 2L-2910 Cat 6 cable.
With an easy cable installation supporting various signals the CE924 is ideal for applications where convenient remote access is required - such as transportation control centers medical facilities industrial warehouses and extended workstations.
Maximum Operating Distance
328.08 ft
Maximum Video Resolution
4096 x 2160
Number of Network (RJ-45) Ports
2
Number of USB Ports
5
Package Contents
- 1 x CE924L USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (Local Unit)
- 1 x CE924R USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (Remote Unit)
- 2 x DisplayPort cables
- 1 x Pink audio jack cable set
- 1 x Green audio jack cable set
- 1 x USB Type-A to Type-B cable
- 2 x Power adapters
- 2 x Mounting kits
- 1 x User instructions
Product Name
USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)
Product Type
KVM Extender
