Advantech IMC-390 Transceiver/Media Converter
Advantech IMC-390 Transceiver/Media Converter - 2 x Network (RJ-45) - 2x PoE+ (RJ-45) Ports - 1 x SC Ports - Multi-mode - Gigabit Ethernet - 10/100/1000Base-T - Wall Mountable, DIN Rail Mountable, Desktop
| $194.40 |
- Supports IEEE802.3at PoE+ (25.5W) and IEEE802.3af PoE (15.4W) standards
- Serves as a power sourcing equipment (PSE) device
- Supports jumbo frame functionality (up to 10240 bytes)
- Supports multiple mounting options (desktop, DIN rail or wall-mount)
- Features in configurable PoE reset on fiber LOS
- Supports Link Fault Pass Through (LFPT)
By:
Advantech
Manufacturer:
Advantech Co., Ltd
Product ID:
173795
Item:
IMC-390-MM
Our Part #
9DG182
Condition
New
$194.40EA
Availability
Only 10 Left In Stock
Product description
Advantech IMC-390 Transceiver/Media Converter - 2 x Network (RJ-45) - 2x PoE+ (RJ-45) Ports - 1 x SC Ports - Multi-mode - Gigabit Ethernet - 10/100/1000Base-T - 1804.46 ft - AC Adapter - Wall Mountable, DIN Rail Mountable, Desktop
2 x Network (RJ-45) - 2x PoE+ (RJ-45) Ports - 1 x SC Ports - Multi-mode - Gigabit Ethernet - 10/100/1000Base-T - 1804.46 ft - AC Adapter - Wall Mountable, DIN Rail Mountable, Desktop
Specifications
Fiber Mode Supported
Multi-mode
Fiber Optic Wavelength
850 nm
Maximum Distance Supported
1804.46 ft
Number of SC Ports
1
PoE Port Type
PSE
Brand Name
Advantech
Country of origin
Taiwan
Depth
3.8"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Form factor
DIN Rail Mountable
Form factor
Desktop
Form factor
Wall Mountable
Height
0.8"
Manufacturer
Advantech Co. Ltd
Manufacturer Part Number
IMC-390-MM
Manufacturer Website Address
http://www.advantech.com
Marketing Information
Introduction
The IMC-380 and IMC-390 series are compact multi-port media converters that support both IEEE802.3at PoE+ and IEEE802.3af PoE standards. These unmanaged plug-n-play media converters with PoE capability are thus ideal solutions for Ethernet networks.
Designed with two 10/100/1000Base-T copper UTP ports and SFP or a fixed fiber transceiver 1x9 uplink port for the network connection the IMC-380 series can power one PD device through a standard CAT5 (or higher version) cable via one copper port while delivering data over the other port. The IMC-390 series is capable of powering up to two PD devices with a power budget of 60W.
The IMC-380 and IMC-390 series support Link Fault Pass Through (LFPT) functionality. LFPT is a troubleshooting feature that combines TX LinkLoss (Twisted Pair copper interface) and FX LinkLoss (Fiber fiber interface) from both local and remote IMC network media converters when used in pairs. This feature when enabled will pass a link fault through the device at each segment. If a link fails on one interface of the media converter the media converter will force the link down on its link partner and then forward it to the next interface.
The IMC-380 and IMC-390 series are compact multi-port media converters that support both IEEE802.3at PoE+ and IEEE802.3af PoE standards. These unmanaged plug-n-play media converters with PoE capability are thus ideal solutions for Ethernet networks.
Designed with two 10/100/1000Base-T copper UTP ports and SFP or a fixed fiber transceiver 1x9 uplink port for the network connection the IMC-380 series can power one PD device through a standard CAT5 (or higher version) cable via one copper port while delivering data over the other port. The IMC-390 series is capable of powering up to two PD devices with a power budget of 60W.
The IMC-380 and IMC-390 series support Link Fault Pass Through (LFPT) functionality. LFPT is a troubleshooting feature that combines TX LinkLoss (Twisted Pair copper interface) and FX LinkLoss (Fiber fiber interface) from both local and remote IMC network media converters when used in pairs. This feature when enabled will pass a link fault through the device at each segment. If a link fails on one interface of the media converter the media converter will force the link down on its link partner and then forward it to the next interface.
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
10/100/1000Base-T
Number of Network (RJ-45) Ports
2
Power source
AC Adapter
Product Name
IMC-390 Transceiver/Media Converter
Product Series
IMC-390
Product Type
Transceiver/Media Converter
Total Number of Ports
3
Weight (Approximate)
15.87 oz
Width
3.6"
