ATEN HDMI HDBaseT-Lite Extender with POH (4K@40m) (HDBaseT Class B)-TAA Compliant
ATEN HDMI HDBaseT-Lite Extender with POH (4K@40m) (HDBaseT Class B)-TAA Compliant - 1 Input Device - 1 Output Device - 229.66 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
| $339.10 | Retail $476.00 |
- Rack- Mountable
- HDBaseT Connectivity - extends an HDMI connection over a long distance via one Cat 5e/6/6a cable
- Superior video quality - up to 4K@35m (Cat 5e/6) / 40m (Cat 6a or ATEN 2L-2910 Cat 6 cable)
- HDBaseT Anti-jamming - resists signal interference during high-quality video transmission using HDBaseT technology
- POH (Power over HDBaseT) - supplies power from Transmitter to Receiver over a long distance via one Cat 5e/6/6a cable
- Bi-directional RS-232 channel - allows you to connect to serial terminals or serial devices, such as touch screens and barcode scanners
- Bi-directional IR channel - IR transmission is processed one direction at a time
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
174166
Item:
VE802
UPC Code:
672792006074
Our Part #
4V0614
Condition
New
$339.10EA
$476.00
$476.00
Availability
Only 22 Left In Stock
Product description
ATEN HDMI HDBaseT-Lite Extender with POH (4K@40m) (HDBaseT Class B)-TAA Compliant - 1 Input Device - 1 Output Device - 229.66 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
1 Input Device - 1 Output Device - 229.66 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
Specifications
Receiver Weight (Approximate)
1.01 lb
Transmitter Depth
4.84"
Transmitter Height
1.18"
Transmitter Weight (Approximate)
15.52 oz
Transmitter Width
5.53"
UPC Alternates
672792006074
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphics Modes
4K
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE802
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The VE802 HDMI HDBaseT-Lite Extender extends an HDBaseT signal up to 70m from the HDBaseT source using one Cat 5e/6/6a cable. VE802 supports RS-232 and IR signaling passthrough allowing you to control the HDMI source device from the remote unit (VE802R) while also granting access to the HDMI display device from the local unit (VE802T). IR signals can also be extended in both directions. The VE802 features Power over HDBaseT (POH) which can send power over Cat 5e/6/6a cable without an additional power supply. The VE802 is HDMI (3D Deep Color4k) and HDCP compatible. The VE802 is perfect for a digital entertainment center or any installation that requires superior video quality.
Maximum Operating Distance
229.66 ft
Maximum Video Resolution
4096 x 2160
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Package Contents
- 1 x Transmitter
- 1 x Receiver
- 1 x Power Adapter (VE802T)
- 1 x IR Transmitter
- 1 x IR Receiver
- 2 x Terminal Blocks
- 1 x User Instructions
Product Line
VanCryst
Product Name
HDMI HDBaseT-Lite Extender with POH (4K@40m) (HDBaseT Class B)
Product Type
Video Extender Transmitter/Receiver
Twisted Pair Cable Standard
Category 6a
