ATEN VE170RQ Video Console-TAA Compliant
ATEN VE170RQ Video Console-TAA Compliant - 1 Input Device - 1 Output Device - 1000 ft Range - 1 x VGA Out - WUXGA - 1920 x 1200 - Twisted Pair - Category 5e - Rack-mountable
| $178.96 | Retail $226.00 |
- Long distance transmission up to 300 m
- Deskew Function - allows you to synchronize the time delay of RGB signals to compensate for distance
- Superior video quality -
- 1920x1200 @ 60Hz (150 m);1280x1024 @ 60Hz (300 m)
- Audio enabled (mono)
- Adjustable gain/compensation control
- Built-in 8KV/15KV ESD protection
- Rack-mountable
- Complies with VESA FDMI mount standard
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
174204
Item:
VE170RQ
UPC Code:
672792002618
Our Part #
KP9607
Condition
New
$178.96EA
$226.00
$226.00
Availability
Only 4 Left In Stock
You may be also interested
Product description
ATEN VE170RQ Video Console-TAA Compliant - 1 Input Device - 1 Output Device - 1000 ft Range - 1 x VGA Out - WUXGA - 1920 x 1200 - Twisted Pair - Category 5e - Rack-mountable
1 Input Device - 1 Output Device - 1000 ft Range - 1 x VGA Out - WUXGA - 1920 x 1200 - Twisted Pair - Category 5e - Rack-mountable
Specifications
Product Material
Metal
Receiver Depth
5.03"
Receiver Height
0.89"
Receiver Weight (Approximate)
8.80 oz
Receiver Width
3.56"
UPC Alternates
672792002618 678149190823
VGA Out
Yes
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
Taiwan
Form factor
Rack-mountable
Graphics Modes
WUXGA
Input voltage
5.3 V DC
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE170RQ
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
VE170RQ is the long distance receiver of the VE170 series Audio / Video extending system it connects to a VE170T over standard CAT5e cabling [ sheilded recommended ] to a maximum distance of 1000ft. and a maximum video resolution of 1920x1200 @ 60Hz. To ensure the highest quality of video the VE170RQ has three manual adjustments to compensate for the time shift between the Red Green and Blue color channels that occurs beyond 500 ft.
Maximum Operating Distance
1000 ft
Maximum Video Resolution
1920 x 1200
Media Type Supported
Twisted Pair
Number of VGA Outputs
1
Package Contents
- VE170RQ Video Console
- Power Adapter
- Rack Mount Kit
- Grounding Wire
- User Guide
Product Name
VE170RQ Video Console
Product Type
Video Extender Receiver
Twisted Pair Cable Standard
Category 5e
