ATEN 16 x 16 Modular Matrix Switch-TAA Compliant
ATEN 16 x 16 Modular Matrix Switch-TAA Compliant - 4096 x 2160 - 4K - 16 x 16 - Display
| $5,483.22 |
- Connects any of 16 video sources to any of 16 displays in combination with ATEN Modular Matrix I/O Boards
- Multiple means for system configuration including front-panel pushbuttons, RS-232/422/485 control, and Ethernet connections for web GUI or Telnet
- 4K resolutions -up to UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0)*
- Scaler -features a (4K) video scaling function to convert input resolutions to the display's native resolutions*
- Seamless Switch™ -features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*
- Video wall -allows you to create custom video wall layouts via intuitive web GUI*
- Calendar-based scheduling -plays connection profiles that synchronized with real-time clock
- EDID Expert -selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolutions acro
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
174206
Item:
VM1600A
UPC Code:
672792008238
Our Part #
5DB516
Condition
New
$5,483.22EA
Availability
Only 1 Left In Stock
Product description
ATEN 16 x 16 Modular Matrix Switch-TAA Compliant - 4096 x 2160 - 4K - 16 x 16 - Display
4096 x 2160 - 4K - 16 x 16 - Display
Specifications
Number of Connectivity (RJ-45) Ports
1
UPC Alternates
672792008238
Brand Name
ATEN
Connectivity technology
Cable
Country of origin
Taiwan
Depth
19"
Device Supported
Display
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphics Modes
4K
Height
10.5"
Limited Warranty
3 Year
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VM1600A
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The ATEN Modular Matrix Solution Series comprises the VM1600A/VM3200 Modular Matrix Switch in tandem with a range of hot-swappable I/O boards. The solution offers real-time control and advanced access to manage 16/32 video sources and 16/32 displays simultaneously through modular I/O boards in a single chassis. Empowered by ATEN Seamless Switch™ technology the VM1600A/VM3200 video matrix switches incorporate a speed-progressive video switching function and a unique scaler that integrates seamlessly with video wall systems.
The ATEN Modular Matrix Solution is easily expandable and ideal for large-scale A/V applications such as broadcasting stations traffic and transportation-related control rooms emergency service centers and any application that requires customizable high-speed A/V signal routing.
Boasting a sophisticated and intuitive design to deliver the best audio/visual distribution and control reliability and lowest maintenance costs the solution also incorporates ATEN's Red Dot Award-winning GUI that can be accessed from anywhere over a network or the internet. Configuring a video wall or digital signage installation has never been easier.
Maximum Video Resolution
4096 x 2160
Number of Displays Supported
16
Package Contents
- 16 x 16 Modular Matrix Switch
- 1 x Power Cord
- 1 x Terminal Block connector
- 1 x Fan Module (pluggable)
- 1 x Power Module (pluggable)
- 1 x User Instructions
Product Line
VanCryst
Product Name
16 x 16 Modular Matrix Switch
Product Type
Audio/Video Switchbox
Weight (Approximate)
33.31 lb
Width
18.4"
