ATEN HDMI USB Extender
ATEN HDMI USB Extender - 1 Input Device - 1 Output Device - 131.23 ft Range - 2 x Network (RJ-45) - 2 x USB - 1 x HDMI In - 1 x HDMI Out - WUXGA - 1920 x 1200
| $113.35 | Retail $168.00 |
- Uses two Cat 5e cables to connect the local and the remote units
- Extends 1080p by 40m; extend 1080i by 60m
- Superior video quality - HDTV resolutions of 480p, 720p, 1080i, 1080p (1920 x 1080), VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200)
- Supports USB touch panel
- 8 segment equalization adjustment switch optimizes display quality
- Support Dolby True HD and DTS HD Master Audio
- Built-in 8KV/15KV ESD protection
- Transparent USB Support - supports all USB 2.0 full speed device (up to 12 Mbps)
- Supports wide screen formats
- HDMI (3D, Deep Color); HDCP compatible - signaling rates up to 2.25Gbits
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
174406
Item:
VE803
UPC Code:
672792004285
Our Part #
TG1985
Condition
New
$113.35EA
$168.00
$168.00
Availability
Only 111 Left In Stock
Product description
ATEN HDMI USB Extender - 1 Input Device - 1 Output Device - 131.23 ft Range - 2 x Network (RJ-45) - 2 x USB - 1 x HDMI In - 1 x HDMI Out - WUXGA - 1920 x 1200
1 Input Device - 1 Output Device - 131.23 ft Range - 2 x Network (RJ-45) - 2 x USB - 1 x HDMI In - 1 x HDMI Out - WUXGA - 1920 x 1200
Specifications
Product Material
Metal
Transmitter Height
0.91"
Transmitter Weight (Approximate)
5.64 oz
Transmitter Width
1.24"
UPC Alternates
672792004285
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
China
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Graphics Modes
WUXGA
Input voltage
5 V DC
Length
2.8"
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE803
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The VE803 HDMI USB Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters and 1080p signals up to 40 meters. The VE803 is equipped with USB connectors which allow you to extend any USB device between the units. The USB feature also provides support for touch panel control allowing you to control the local HDMI source device from the remote display or control the remote display through the local unit.
The VE803 is ideal for transportation centers medical facilities shopping malls or anywhere touch panel control or a kiosk is required. For flexibility and convenience the VE803 local unit can be powered via the USB cable when connected to an appropriate source device. The VE803 is HDCP compliant providing an easy and ideal HDMI extender solution for any application.
The VE803 is ideal for transportation centers medical facilities shopping malls or anywhere touch panel control or a kiosk is required. For flexibility and convenience the VE803 local unit can be powered via the USB cable when connected to an appropriate source device. The VE803 is HDCP compliant providing an easy and ideal HDMI extender solution for any application.
Maximum Operating Distance
131.23 ft
Maximum Video Resolution
1920 x 1200
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Package Contents
- 1 x VE803T HDMI USB Extender
- 1 x VE803R HDMI USB Extender
- 1 x Power Adapter
- 1 x USB Cable (1.8 m)
- 1 x Mounting Kit
- 1 x User Instructions
Product Name
HDMI USB Extender
Product Type
Video Extender Transmitter/Receiver
Twisted Pair Cable Standard
Category 5e
