ATEN HDMI HDBaseT-Lite Transmitter with POH (HDBaseT Class B)-TAA Compliant
ATEN HDMI HDBaseT-Lite Transmitter with POH (HDBaseT Class B)-TAA Compliant - 1 Input Device - 229.66 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
| $169.55 | Retail $238.00 |
- HDBaseT Connectivity - extends an HDMI connection over a long distance via one Cat 5e/6/6a cable
- Superior video quality - up to 4K@35m (Cat 5e/6) / 40m (Cat 6a or ATEN 2L-2910 Cat 6 cable)
- HDBaseT Anti-jamming - resists signal interference during high-quality video transmission using HDBaseT technology
- POH (Power over HDBaseT) - supplies power from Transmitter to Receiver over a long distance via one Cat 5e/6/6a cable
- Bi-directional RS-232 channel - allows you to connect to serial terminals or serial devices, such as touch screens and barcode scanners
- Bi-directional IR channel - IR transmission is processed one direction at a time
- Rack- Mountable
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
175064
Item:
VE802T
UPC Code:
672792006203
Our Part #
3F1605
Condition
New
$169.55EA
$238.00
$238.00
Availability
Only 11 Left In Stock
Product description
ATEN HDMI HDBaseT-Lite Transmitter with POH (HDBaseT Class B)-TAA Compliant - 1 Input Device - 229.66 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
1 Input Device - 229.66 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
Specifications
Transmitter Depth
5.35"
Transmitter Height
1.14"
Transmitter Weight (Approximate)
15.52 oz
Transmitter Width
3.98"
UPC Alternates
672792006203 997253066726
Brand Name
ATEN
Connectivity technology
Wired
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphics Modes
4K
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE802T
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The VE802T HDMI HDBaseT-Lite Transmitter connects with HDBaseT receivers* to extend signals up to 70m from the source using one Cat 5e/6/6a cable. It supports RS-232 and IR signaling pass-through allowing you to control the HDMI source device from the remote unit (VE802R) while also granting access to the HDMI display device from the local unit (VE802T). IR signals can also be extended in both directions. The VE802T features Power over HDBaseT (POH) which can send power over Cat 5e/6/6a cable without an additional power supply. The VE802T is HDMI (3D Deep Color4k) and HDCP compatible. The VE802T is perfect for a digital entertainment center or any installation that requires superior video quality.
Maximum Operating Distance
229.66 ft
Maximum Video Resolution
4096 x 2160
Media Type Supported
Twisted Pair
Number of Network (RJ-45) Ports
1
Package Contents
- HDMI HDBaseT-Lite Transmitter with POH (HDBaseT Class B)
- 1 x Power Adapter
- 1 x IR Transmitter
- 1 x Terminal Block
- 1 x User Instructions
Product Line
VanCryst
Product Name
HDMI HDBaseT-Lite Transmitter with POH (HDBaseT Class B)
Product Type
Video Extender Transmitter
Twisted Pair Cable Standard
Category 6a
