Eaton 500VA 300W 120V AC DIN Rail Industrial UPS - Hardwire Input/Output
Eaton 500VA 300W 120V AC DIN Rail Industrial UPS - Hardwire Input/Output - For PDU - 100 V AC, 240 V AC16 A - 8 ft Cord Length
| $617.10 | Retail $764.00 |
- Recommended for industrial locations where temperatures range within 0°C and 50°C
- Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
- Keeps power running during brief outages to allow time for safe system shutdown
- Restarts automatically when power is restored, eliminating a costly site visit
- Built-in clamp mounts easily to a "top hat" 35mm DIN rail with no mounting screws or brackets required
- 2-year limited warranty
By:
Eaton
Manufacturer:
Eaton Corporation
Product ID:
175119
Item:
DIN500AC
Our Part #
12TL64
Condition
New
$617.10EA
$764.00
$764.00
Availability
Only 49 Left In Stock
Product description
Eaton 500VA 300W 120V AC DIN Rail Industrial UPS - Hardwire Input/Output - For PDU - 100 V AC, 240 V AC16 A - 8 ft Cord Length
For PDU - 100 V AC, 240 V AC16 A - 8 ft Cord Length
Specifications
DC System Voltage
12 V DC
Load Capacity (VA)
500 VA
Load Capacity (W)
300 W
Maximum Operating Elevation
9843 ft
Output Frequency
60 Hz
Output Power Factor
0.6
Phase
Single Phase
Receptacle Detail
1 x Hardwired
Sound Emission (A-Weighted)
40 dB(A)
Storage Temperature
5°F (-15°C) - 122°F (50°C)
Waveform Type
Pulse-width Modulated Sine Wave
Application/Usage
Industrial
Application/Usage
Storage Device
Application/Usage
IT System
Application/Usage
Factory
Application/Usage
Network
Application/Usage
Edge Computing
Application/Usage
Automation Industry
Application/Usage
Manufacturing Facility
Application/Usage
Machine Control
Backup/Run Time (Full Load)
4 Minute
Backup/Run Time (Half Load)
14.50 Minute
Battery Characteristics
Valve-regulated
Battery Chemistry
Lead Acid
Brand Name
Eaton
Depth
7.7"
Display
LED
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
DIN Rail
Height
15.8"
Input voltage
120 V AC
Limited Warranty
2 Year
Load Capacity
500 VA/300 W
Manufacturer
Eaton Corporation
Manufacturer Part Number
DIN500AC
Manufacturer Website Address
http://www.eaton.com
Marketing Information
Flexible Power Protection for Smart Industrial Applications
The DIN500AC standby UPS system with hardwire AC input/output delivers reliable power and battery backup for computing networking control and storage equipment in factories warehouses edge computing locations and automated manufacturing and fabrication facilities. The rugged compact housing withstands demanding conditions and integrates seamlessly and securely into electrical enclosures in any non-traditional IT environment.
Ideal for Factory Floors and Extreme Temperatures
Get full use of the DIN500AC's power capacity because there is no derating based on its operating temperature range of 0°C (32°F) to 50°C (122°F) which expands the number of locations in which it can be used. Built to fit into small spaces the DIN500AC is a UL 508 recognized component for use in industrial panels. Its pre-installed clamp enables quick mounting to a 35 mm DIN rail. Its fanless design reduces noise and increases reliability.
Reliable Battery Backup Keeps You Operational Through Power Outages
Power outages not only drain productivity from the factory floor but they also damage expensive equipment. The DIN500AC protects productivity by providing enough runtime to maintain operation during a brief power outage and protects equipment by allowing it to complete an operation during an extended outage. It also prevents brownouts overvoltages surges and line noise from damaging equipment that could destroy data and contribute to costly downtime.
Convenient Automatic Restart
The DIN500AC automatically restarts when AC power is restored after an outage eliminating the need for a costly site visit.
Stay in Control of Your Operation
LEDs on the front panel confirm normal operation and indicate alarm or fault status. Remote on/off and a battery indicator mode can help you avoid maintenance surprises. The DIN500AC is compatible with PowerAlert® Office software for UPS monitoring and control via USB connection.
Easy Preventative Maintenance and Initial Troubleshooting
The DIN500AC's self-test capability and user-replaceable internal battery can extend the life of the UPS and minimize disruption to operations. A resettable circuit breaker helps prevent dangerous system overloads.
Maximum Operating Temperature
122°F (50°C)
Output voltage
115 V AC
Package Contents
- DIN500AC 500VA DIN Rail UPS
- USB Communication Cable
- Safety Card
- Owner's Manual
Plug/Connector Type
Hardwired
Product Name
DIN500AC 500VA DIN Rail UPS
Product Type
Standby UPS
Status Indicators
LED Indicators:
- ALARM - RED - Flashes when the battery needs to be recharged and tested.
- SOLID RED when the unit is subjected to an overload condition.
- YELLOW - ON SOLID when the UPS is supplying battery power to the loads.
- GREEN - ON SOLID GREEN when the line input voltage is normal.
Surge energy rating
558 J
Thermal Dissipation
9.09 W
Transfer Time
10 ms
Weight (Approximate)
11.60 lb
Width
7.9"
