AddOn 10/100Base-TX(RJ-45) to 100Base-FX(ST) MMF 1310nm 2km POE Media Converter
AddOn 10/100Base-TX(RJ-45) to 100Base-FX(ST) MMF 1310nm 2km POE Media Converter - 100% compatible and guaranteed to work
| $90.60 | Retail $154.00 |
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- With 10/100Base-TX technology get up to 100Mbps data transfer rate over optical fiber cable
- The Desktop provides convenient installation
Manufacturer:
AddOn
Product ID:
175283
Item:
ADD-FMCP-FX-ST
UPC Code:
821455056165
Our Part #
AND-ADD-FMCP-FX-ST
Condition
New
$90.60EA
$154.00
$154.00
Availability
Only 17 Left In Stock
Product description
AddOn 10/100Base-TX(RJ-45) to 100Base-FX(ST) MMF 1310nm 2km POE Media Converter - 100% compatible and guaranteed to work
100% compatible and guaranteed to work
Specifications
Fiber Mode Supported
Multi-mode
Maximum Distance Supported
1.24 Mile
Number of PoE (RJ-45) Ports
1
UPC Alternates
094204371219 821455056165
Certifications & Standards
IEEE Standards:
- 802.3
- 802.3u
Country of origin
United States
Depth
6"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Fast Ethernet
Form factor
Desktop
Height
1.5"
Input voltage
110 V AC
Limited Warranty
3 Year
Manufacturer
AddOn
Manufacturer Part Number
ADD-FMCP-FX-ST
Manufacturer Website Address
http://www.addoncomputer.com
Marketing Information
ADD-FMCP-FX-ST is a Media Converter that converts a 100Base-TX(RJ45) to 100Base-FX(ST) via a 1310nm multi-mode fiber (MMF) ST connector which allows distance reach up to 2km. ADD-FMCP-FX-ST provides a cost effective conversion from 100Base Copper to 100Base-FX fiber while extending the network reach beyond the 100m reach limitation of copper. This AC/DC powered PoE media converter is a Power Sourcing Equipment (PSE) which combines data transferred over a fiber optic link with 48V (or other voltage) power supply providing power to IEEE802.3af powered device (PD) over CAT5 and up UTP cable (cable length up to 100meters / 330feets). It complies with the IEEE802.3af standard. The converter includes a single port PSE controller which offers PD signature sensing and power monitoring features. Other features include over-current protection and LFP function. The LFP (Link Fault Pass-through) allows the media converter to monitor both the fiber and copper RX port for loss of signal. In case of a loss of RX signal on one media port the converter will automatically disable the TX signal to the other media port thus passing through the link fault.
Addoncomputer.com Media Converters and Network Interface Cards are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs. With our ADDON CERTIFICATION TEST Program we can guarantee your product will work right the first time.
Addoncomputer.com Media Converters and Network Interface Cards are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs. With our ADDON CERTIFICATION TEST Program we can guarantee your product will work right the first time.
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
10/100Base-TX
Network Technology
100Base-FX
Product Name
100Base-TX To 100Base-LX SMF ST 1310nm 2k POE Media Converter
Product Type
Transceiver/Media Converter
Total Number of Ports
2
USB
No
Weight (Approximate)
1.40 lb
Width
5"
