KanexPro 4K UHD HDMI 1x4 Port Splitter
KanexPro 4K UHD HDMI 1x4 Port Splitter - 60 Hz to 60 Hz - 1 x HDMI In - 4 x HDMI Out - USB
| $76.74 | Retail $104.95 |
- Split CATV and other signals with this satellite splitter so that it can be used for more than one device
- Supports up to 60 Hz frequency
- HDMI interface allows you to connect to a variety of HD devices for the ultimate true high-definition video
- Features HDMI port for delivering and transferring high-quality picture and sound simultaneously at a high-speed.
- Unhindered connections with USB devices are ensured by the built-in USB port
Manufacturer:
KanexPro
Product ID:
175737
Item:
SP-HD1X44K
UPC Code:
813982020054
Our Part #
32101529
Condition
New
$76.74EA
$104.95
$104.95
Availability
Only 1 Left In Stock
You may be also interested
Product description
KanexPro 4K UHD HDMI 1x4 Port Splitter - 60 Hz to 60 Hz - 1 x HDMI In - 4 x HDMI Out - USB
60 Hz to 60 Hz - 1 x HDMI In - 4 x HDMI Out - USB
Specifications
Product Material
Metal
UPC Alternates
813982020054 818200302226 818244181962
Additional Information
- Distribute high-resolution HDMI signals to four Ultra HD displays
- Supports 4Kx2K resolution
- Supports full HD 1080p (1920 x 1080@60Hz)
- Computer resolution up to WUXGA (1920 x1200@60Hz)
- EDID mode for copying the same resolution to input port
- HDCP & CEC compliant
- Supports latest HDMI High Speed Specifications
- Supports 12-bit per channel (36-bit all channel) Deep color
- Front USB ports for firmware update
- Compact metal enclosure
- Signal Inputs/Output:
- Input DDC Signal: 5 volts p-p (TTL)
- Maximum Single Link Range: 4K x 2K@30Hz
- Output Video: HDMI 1.4 with full HD 1080p
- 1920x1200 720p 3D and 4Kx2K + HDCP
- CEC - Pass through enabled
- Operating Frequency:
- Vertical Frequency Range: 50/60Hz
- Video Amplifier Bandwidth: 2.97 Gbps
- Resolutions (HDTV):
- Interlaced (50&60Hz): 480i 576i and 1080i
- Progressive (50&60Hz): 480p 576p 720p 1080p and
- 4Kx2K@30Hz
- Power Requirements:
- External Power Supply: 5V DC@ 1A
- Power consumption (Max): 5W
Height
1"
Input voltage
5 V DC
Length
5.7"
Limited Warranty
1 Year
Manufacturer
KanexPro
Manufacturer Part Number
SP-HD1X44K
Manufacturer Website Address
http://www.kanexpro.com
Marketing Information
The KanexPro 1x4 HDMI Splitter is a 4K@30Hz compliant distribution amplifier which lets you duplicate one HDMI source to four displays without losing signal integrity and resolution.
The Ultra HD 4K format on the HDMI splitter ensures astounding picture quality four times the resolution of high-definition 1080p. This HDCP compliant splitter is also backward compatible with previous HDMI revisions supporting 1080p / 720p HDMI video resolution devices. Even if you don't require 4K video today it ensures you'll be ready to take advantage of tomorrow's display technology.
Maximum Frequency
60 Hz
Number of HDMI Inputs
1
Number of HDMI Outputs
4
Package Contents
- 4K UHD HDMI 1x4 Port Splitter
- 5V 1A DC Power Supply
- Manual
Product Name
4K UHD HDMI 1x4 Port Splitter
Product Type
Signal Splitter
USB
Yes
Weight (Approximate)
4.32 oz
Width
2.7"
