ATEN HDMI HDBaseT-Lite Transmitter (HDBaseT Class B)-TAA Compliant
ATEN HDMI HDBaseT-Lite Transmitter (HDBaseT Class B)-TAA Compliant - 1 Input Device - 70.87" Range - 2 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
| $121.52 | Retail $152.00 |
- Extends HDMI signals over a single Cat 5e/6/6a cable or ATEN 2L-2910 Cat 6 cable
- HDMI (3D, Deep color, 4K); HDCP 2.2 compliant
- Superior video quality - up to 4K@35m (Cat 5e/6) / 40m (Cat 6a or ATEN 2L-2910 Cat 6 cable)
- HDBaseT Anti-jamming - resists signal interference during high-quality video transmission using HDBaseT technology
- Plug-and-play
- Rack-mountable
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
175846
Item:
VE801T
UPC Code:
672792006166
Our Part #
ZM1999
Condition
New
$121.52EA
$152.00
$152.00
Availability
Only 7 Left In Stock
Product description
ATEN HDMI HDBaseT-Lite Transmitter (HDBaseT Class B)-TAA Compliant - 1 Input Device - 70.87" Range - 2 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
1 Input Device - 70.87" Range - 2 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
Specifications
Product Material
Metal
Transmitter Depth
3.88"
Transmitter Height
1.18"
Transmitter Weight (Approximate)
8.47 oz
Transmitter Width
3.43"
UPC Alternates
672792006166
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphics Modes
4K
Input voltage
5 V DC
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE801T
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The VE801T HDMI HDBaseT-Lite Transmitter connects with HDBaseT receivers* to extend signals up to 70m from the source using one Cat 5e/6/6a cable. It supports HDMI features that include 3D Deep Color and 4K image resolutions plus Dolby Digital 5.1 DTS HD audio and it is HDCP compatible. The VE801T all-in-one design provides an easy method for mounting the device in any location. The side panel provides slip-resistant grooves that help prevent accidental drops when installing the unit. The grooves also enhance the ability to see the LED status lights. The VE801T is perfect for digital entertainment centers or any installation that requires superior HDMI video quality to be extended at great distances.
Maximum Operating Distance
70.87"
Maximum Video Resolution
4096 x 2160
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Package Contents
- VE801T HDMI HDBaseT-Lite Extender
- 1 x Power Adapters
- 1 x User Instructions
Product Line
VanCryst
Product Name
HDMI HDBaseT-Lite Transmitter (HDBaseT Class B)
Product Type
Video Extender Transmitter
Twisted Pair Cable Standard
Category 6a
