Black Box Opto Isolator - RS-232, DB25 Male to DB25 Female, 115.2-Kbps
Black Box Opto Isolator - RS-232, DB25 Male to DB25 Female, 115.2-Kbps - 1 x 25-pin DB-25 RS-232 Serial Male - 1 x 25-pin DB-25 RS-232 Serial Female - TAA Compliant
| $310.27 |
- Protect your computer and your data from ground loops.
- Internal fiber optic air gap prevents ground loops.
- Data signals are converted to line pulses inside the Opto-Isolator and continue along the circuit.
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
176532
Item:
SP340A-R3
UPC Code:
000059538042
Our Part #
26121604
Condition
New
$310.27EA
Availability
Only 6 Left In Stock
Product description
Black Box Opto Isolator - RS-232, DB25 Male to DB25 Female, 115.2-Kbps - 1 x 25-pin DB-25 RS-232 Serial Male - 1 x 25-pin DB-25 RS-232 Serial Female - TAA Compliant
1 x 25-pin DB-25 RS-232 Serial Male - 1 x 25-pin DB-25 RS-232 Serial Female - TAA Compliant
Specifications
Connector on First End Details
1 x 25-pin DB-25 RS-232 Serial Male
Connector on Second End Details
1 x 25-pin DB-25 RS-232 Serial Female
Connector Type on First End
DB-25 RS-232 Serial - Male
Connector Type on Second End
DB-25 RS-232 Serial - Female
UPC Alternates
000059538042 822088117636 893688423359
Adapter Type
Serial
Brand Name
Black Box
Compatibility
- Wallmount Power Supply with International Clips
- Standard RS-232 Low-Noise Cable 25-Conductor (ECM25C)
Country of origin
United States
Depth
3.8"
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
0.8"
Limited Warranty
5 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
SP340A-R3
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
Linking two devices powered by separate AC sources can create the potential for a ground-loop surge - a damaging electrical condition that can destroy your computer and wipe out data. But a Black Box ® Opto-Isolator interrupts that lethal pathway by completing the connection between the two devices with an internal fiber optic link.
Data signals converted to light pulses inside the Isolator continue along on the circuit. But the fiber optic air gap stops ground loops from wreaking havoc with your hardware.
Our High-Speed Opto-Isolator protects devices with 115.2-kbps serial ports up to 1000 feet (304.8 m) on either side of the interface. If the interface doesn't provide enough power order the optional 120-VAC Wallmount Power Supply (PS1002).
Product Name
Opto Isolator - RS-232 DB25 Male to DB25 Female 115.2-Kbps
Product Type
Data Transfer Adapter
Weight (Approximate)
12.80 oz
Width
2.1"
