Black Box FlexPoint T1/E1 MT663A-SSC Transceiver/Media Converter
Black Box FlexPoint T1/E1 MT663A-SSC Transceiver/Media Converter - 1 x SC Ports - DuplexSC Port - Single-mode - T1/E1 - Rack-mountable, Wall Mountable - TAA Compliant
| $1,075.36 | Retail $1,199.99 |
- Supports AMI, B8ZS, and HDB3 line codes.
- A crossover switch on the RJ-45/RJ-48 port enables easy equipment connections.
- Powered by a universal AC power supply or the optional rackmountable chassis.
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
176556
Item:
MT663A-SSC
UPC Code:
700604199147
Our Part #
ZP3823
Condition
New
$1,075.36EA
$1,199.99
$1,199.99
Availability
Only 5 Left In Stock
Product description
Black Box FlexPoint T1/E1 MT663A-SSC Transceiver/Media Converter - 1 x SC Ports - DuplexSC Port - Single-mode - T1/E1 - Rack-mountable, Wall Mountable - TAA Compliant
1 x SC Ports - DuplexSC Port - Single-mode - T1/E1 - Rack-mountable, Wall Mountable - TAA Compliant
Specifications
Fiber Mode Supported
Single-mode
Fiber Optic Cable Standard
9/125 µm
Fiber Optic Cable Standard
50/125 µm
Fiber Optic Cable Standard
62.5/125 µm
Maximum Distance Supported
17.40 Mile
SC Port Type
Duplex
UPC Alternates
700604199147 822088071037
Brand Name
Black Box
Country of origin
United States
Depth
4"
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Form factor
Wall Mountable
Height
1"
Limited Warranty
2 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
MT663A-SSC
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
- Easy to install.
- Connects T1 or E1 PBXs CSUs or routers over fiber to protect against noise and increase network reliability.
- Supports AMI B8ZS and HDB3 line codes.
- A crossover switch on the RJ-45/RJ-48 port enables easy equipment connections.
- Extensive diagnostics including local and remote fiber loopback switches.
- LEDs display T1/E1 link status modes of operation and line segment errors.
- To conveniently rackmount up to five FlexPoint Fiber Converters use the optional 5-Position Rackmounting Kit (LMC205). To order see "Related Products".
- Use optional Wallmounting Hardware (LMC206-WALL) to mount individual FlexPoint Fiber Converters on virtually any surface (also available under "Related Products".)
Use this flexible converter/line driver to connect your T1 or E1 devices to single-mode fiber to get extra distance as well as protection from environmental noise.
FlexPoint™ Converters from Black Box are versatile and cost-effective standalone converters that you can upgrade to a chassis-based system. They provide the ultimate in flexibility and reliability for your expanding multimedia LAN.
The incredible variety and versatility of this system make it ideal for networks that are subject to constant upgrades and changes.
Tailor the system to your requirements. Get the converters you need now and use them individually. Then when your LAN grows mount your converters on the wall in the FlexPoint 5-Position Rackmounting Kit or in the FlexPoint Power Chassis. The chassis holds 14 converters and single or dual AC power supplies.
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
T1/E1
Package Contents
- FlexPoint T1/E1 MT663A-SSC Transceiver/Media Converter
- AC Power Supply
Packaged Quantity
1
Power source
Power Supply
Product Family
FlexPoint T1/E1
Product Line
FlexPoint
Product Name
FlexPoint T1/E1 MT663A-SSC Transceiver/Media Converter
Product Type
Transceiver/Media Converter
Total Number of Ports
2
USB
No
Weight (Approximate)
6.40 oz
Width
3"
