Black Box 4K HDMI IR Extender 70M
Black Box 4K HDMI IR Extender 70M - 1 Input Device - 1 Output Device - 229.66 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 3840 x 2160 - Twisted Pair - Category 6
| $328.72 |
- Send HDMI signals to multimedia displays up to 230 feet (70 m) using a single CAT5e/6 cable
- Uses CATx technology
- This kit includes an HDMI transmitter and HDMI receiver
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
176561
Item:
VX-HDMI-TP-70M
UPC Code:
822088120711
Our Part #
45111815
Condition
New
$328.72EA
Availability
Only 114 Left In Stock
Product description
Black Box 4K HDMI IR Extender 70M - 1 Input Device - 1 Output Device - 229.66 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 3840 x 2160 - Twisted Pair - Category 6
1 Input Device - 1 Output Device - 229.66 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 3840 x 2160 - Twisted Pair - Category 6
Specifications
Transmitter Weight (Approximate)
1 lb
UPC Alternates
088611895031 822088120711 993245330110 995477222478 996593954113
Brand Name
Black Box
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Graphics Modes
4K
Limited Warranty
3 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
VX-HDMI-TP-70M
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
- Extend HDMI over a single CATx cable
The 4K CATx Lite Extender uses CATx technology for extension. Distribute digital signage content or other HD video and audio over a single CAT5e/6 cable. The transmitter-receiver combo makes it easy to send digital full 1080p-quality video and audio plus IR and serial RS-232 control signals up to 230 feet (70 m) or 4K/UHD up to 131 feet (40 m).
- Optimal PC-to-screen performance
The 4K CATx Lite Transmitter and Receiver feature EDID copy function and are HDCP-compliant and Blu-ray ready.
- Lossless compression for HD extension
The 4K CATx Lite Extender transmits broadcast-quality video and audio as well as all common PC resolutions (XGA SXGA UXGA WSXGA) up to 3840 x 2160 (Full HD WUXGA UHD) at 30 Hz.
- Simplified control
The extender supports CEC passthrough and source device control via a built-in IR extender function (an IR emitter and IR receiver are included). IR commands received in the vicinity of the display extend back to the source device. This way a receptionist stationed near a screen for instance can use an HDTV's remote controller to change settings on a source device in another room.
- 4K CATx Lite Extender Kit is great for:
- Hospitality (hotels and conference rooms)
- Digital signage (airports and shopping malls)
- Surveillance cameras
- Whole-home networking
- Point-to-point consumer application
Maximum Operating Distance
229.66 ft
Maximum Video Resolution
3840 x 2160
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Product Condition
New
Product Name
4K HDMI IR Extender 70M
Product Type
Video Extender Transmitter/Receiver
Twisted Pair Cable Standard
Category 6
