SIIG 2 Port DP Cyber RS-232 2S PCIe Card - 250Kbps
SIIG 2 Port DP Cyber RS-232 2S PCIe Card - 250Kbps - ASIX AX99100 Chipset - PCI Express Base Specification 2.0 Compliant
| $39.82 | Retail $49.99 |
- Adds two 9-pin RS-232 serial ports to PCIe enabled desktop computers
- Two 16C650 UART serial ports support data transfer rate up to 250Kbps
- Compliant with PCI Express 2.0 Gen 1
- Single-lane (x1) PCI Express End-point Controller with PHY integrated
- Full serial modem control with hardware and software flow control
- Supports 5, 6, 7, 8 and 9-bit serial formats
- Supports Even, Odd, None, Space and Mark parity
- On chip 256-byte FIFO buffers in transmit and receive path for each serial port
- Works as either standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners, table scanners, POS displays and many more). Configurable via jumpers
- Supports PCI Bus Power Management Interface Specification Revision 1.2
By:
SIIG
Manufacturer:
SIIG, Inc
Product ID:
176856
Item:
JJ-E20711-S1
UPC Code:
662774044095
Our Part #
8UL695
Condition
New
$39.82EA
$49.99
$49.99
Availability
Only 175 Left In Stock
You may be also interested
Product description
SIIG 2 Port DP Cyber RS-232 2S PCIe Card - 250Kbps - ASIX AX99100 Chipset - PCI Express Base Specification 2.0 Compliant
ASIX AX99100 Chipset - PCI Express Base Specification 2.0 Compliant
Specifications
Number of Serial Ports (External)
2
UPC Alternates
662774044095
Brand Name
SIIG
Card Height
Full-height/Low-profile
Country of origin
China
Depth
4.7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Plug-in Card
Height
0.7"
Host interface
PCI Express 2.0 x1
Limited Warranty
2 Year
Manufacturer
SIIG Inc
Manufacturer Part Number
JJ-E20711-S1
Manufacturer Website Address
http://www.siig.com
Marketing Information
Add two 16650 RS232 ports to your PCI Express system
Features- Adds two 9-pin RS-232 serial ports to PCIe enabled desktop computers
- Two 16C650 UART serial ports support data transfer rate up to 250Kbps
- Compliant with PCI Express 2.0 Gen 1
- Single-lane (x1) PCI Express End-point Controller with PHY integrated
- Full serial modem control with hardware and software flow control
- Supports 5 6 7 8 and 9-bit serial formats
- Supports Even Odd None Space and Mark parity
- On chip 256-byte FIFO buffers in transmit and receive path for each serial port
- Works as either standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners table scanners POS displays and many more). Configurable via jumpers
- Supports PCI Bus Power Management Interface Specification Revision 1.2
- Dual profile design installs into both full-size and low-profile system chassis with the included mounting brackets
- Installs into any PCI Express slot of any lane width
- Perfect solution to connect with POS system industrial testing and control device security system logistic management equipment printers scanners etc
Package Contents
- DP Cyber 2S PCIe Card
- Full Height Bracket
- 2 x Low Profile Bracket
- 1 x Y-Split Power Cable
- 4 x Voltage Jumper
- Software CD
- User Manual
Platform Supported
PC
Product Name
DP Cyber 2S PCIe Card
Product Type
Serial Adapter
Weight (Approximate)
1.92 oz
Width
2.9"
