Electro-Voice EVU-2062/95 2-way Speaker - 300 W RMS - Black
Electro-Voice EVU-2062/95 2-way Speaker - 300 W RMS - Black - 1200 W (PMPO) - 6.50" - 1.30" - 100 Hz to 16 kHz - 8 Ohm
| $686.71 | Retail $947.00 |
- 1.3" (33 mm) diaphragm, 1.4" (36 mm) exit pure titanium compression driver
- Dual 6.5" (165 mm) LF transducers
- Advanced third-order crossover network with HF protection
- Coverage pattern: 90° x 50° Constant DirectivityTM rotatable waveguide
- 94 dB sensitivity, 125 dB maximum SPL
- System rating: 300 W continuous, 1200 W peak
- Universal U-bracket included
- 70.7/100-V transformer accessory optional
- NL4 cover plate accessory optional
- (6) M8 threaded suspension points
By:
Electro-Voice
Manufacturer:
The Bosch Group
Product ID:
178032
Item:
EVU-2062/95-BLK
UPC Code:
800549622752
Our Part #
9Y0430
Condition
New
$686.71EA
$947.00
$947.00
Availability
Only 2 Left In Stock
Product description
Electro-Voice EVU-2062/95 2-way Speaker - 300 W RMS - Black - 1200 W (PMPO) - 6.50" - 1.30" - 100 Hz to 16 kHz - 8 Ohm
1200 W (PMPO) - 6.50" - 1.30" - 100 Hz to 16 kHz - 8 Ohm
Specifications
Crossover Type
2-way
RMS Output Power
300 W
Tweeter Driver Size
1.30"
UPC Alternates
800549622752
Woofer Driver Size
6.50"
Brand Name
Electro-Voice
Depth
8.15"
Height
8.2"
Impedance
8 Ohm
Manufacturer
The Bosch Group
Manufacturer Part Number
EVU-2062/95-BLK
Manufacturer Website Address
http://www.bosch.com
Marketing Information
The Electro-Voice EVU-2062/95 is a compact two-way loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in an ultra-compact lightweight enclosure. The enclosure design utilizes asymmetric angles to maintain tight clearances to wall and ceilings while providing optimal coverage patterns making it ideal to blend into surroundings. This design was optimized for wall stage lip and under balcony applications.
The EVU-2062/95 incorporates the ICT-1-8 a high-output 1.3" diaphragm titanium compression driver coupled to a Constant Directivity™ 90° x 50° rotatable waveguide. The ICT-6.5-16 woofer was developed using FEA optimization to provide the highest sensitivity while achieving the highest level of speech intelligibility. The crossover design uses 18-dB-per-octave slopes with equalization for very smooth response in the vocal range linear off-axis response and a protection circuit for long term reliability.
The EVU series is constructed of 9-ply hardwood plywood enclosures with six integral M8 suspension points to support a wide variety of mounting positions. The EVU system is finished in textured paint available in either white or black. Each EVU system includes a universal U-bracket to facilitate mounting. The U-bracket provides full unobstructed rotation of the loudspeaker (330° unobstructed rotation if the transformer kit is installed). Additional mounting points are located on the rear of the enclosure for use with an Omnimount™ type bracket. An available 70.7/100-V transformer kit may be easily mounted over the input panel for use in distributed systems. All of these features give you the flexibility to address a large range of venues while quickly and precisely supporting customer requirements.
The EVU-2062/95 incorporates the ICT-1-8 a high-output 1.3" diaphragm titanium compression driver coupled to a Constant Directivity™ 90° x 50° rotatable waveguide. The ICT-6.5-16 woofer was developed using FEA optimization to provide the highest sensitivity while achieving the highest level of speech intelligibility. The crossover design uses 18-dB-per-octave slopes with equalization for very smooth response in the vocal range linear off-axis response and a protection circuit for long term reliability.
The EVU series is constructed of 9-ply hardwood plywood enclosures with six integral M8 suspension points to support a wide variety of mounting positions. The EVU system is finished in textured paint available in either white or black. Each EVU system includes a universal U-bracket to facilitate mounting. The U-bracket provides full unobstructed rotation of the loudspeaker (330° unobstructed rotation if the transformer kit is installed). Additional mounting points are located on the rear of the enclosure for use with an Omnimount™ type bracket. An available 70.7/100-V transformer kit may be easily mounted over the input panel for use in distributed systems. All of these features give you the flexibility to address a large range of venues while quickly and precisely supporting customer requirements.
Maximum Frequency Response
16 kHz
Minimum Frequency Response
100 Hz
Package Contents
- EVU-2062/95 Dual 6.5" Two-Way 90° x 50° Full-Range Loudspeaker System
- Universal U-Bracket
PMPO Output Power
1200 W
Product color
Black
Product Model
EVU-2062/95
Product Name
EVU-2062/95 Dual 6.5" Two-Way 90° x 50° Full-Range Loudspeaker System
Product Series
EVU
Product Type
Speaker
Sensitivity
94 dB
Weight (Approximate)
24.91 lb
Width
21"
