Tripp Lite UPS 550VA 300W Desktop Battery Back Up AVR Compact 120V USB RJ11

Tripp Lite UPS 550VA 300W Desktop Battery Back Up AVR Compact 120V USB RJ11 - Mini Desktop - 9 Hour Recharge - 5.50 Minute Stand-by - 110 V AC Input - 120 V AC Output - 4 x NEMA 5-15R, 4 x NEMA 5-15R
$114.36Retail $146.02
Manufacturer:
Tripp Lite
Product ID:
18391
Item:
AVR550U
UPC Code:
037332211453
Our Part #
TRPAVR550U
Condition
New
Subscribe & Save 5%
Ferquency
$114.36EA
 $146.02
0 Reviews
Availability Only 2724 Left In Stock
Great Deals Everyday

You may be also interested

Product description

AVR Series Line-Interactive UPS System offers 550VA ultra-compact line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space-saving right-angle input plug, four battery/surge-protected outlets and four additional surge-only outlets (8 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.



Specifications

AVR Range
Boost +18% / Buck -15%
DC System Voltage
12 V DC
Energy Saving
Greater than 95% efficiency - GREEN UPS
Load Capacity (VA)
550 VA
Load Capacity (W)
300 W
Maximum Operating Elevation
10000 ft
Number of Battery & Surge Outlets
4
Output Frequency
60 Hz
Phase
Single Phase
Receptacle Detail
8 x NEMA 5-15R
Storage Temperature
5°F (-15°C) - 113°F (45°C)
UPC Alternates
003733212344 010343812246 013297551117 037332123442 037332211453 635665338795 706919705509 742309939109 777785490721 801096833493 803931089478 803982804600 997852203317
Waveform Type
Pulse-width Modulated Sine Wave
Additional Information
  • Low voltage transfer to battery power: Switches to battery power as line voltage drops to 83V or lower / Resets to AC mode as line voltage increases to 87V or higher
  • High voltage transfer to battery power: Switches to battery power as line voltage increases to 147V or higher / Resets to line power as line voltage drops to 143V or less
  • Cold Start: Yes inverter can be "cold started" to enable temporary AC output during a power failure
  • Switches: Combination power off / on / self-test push button switch
  • Typical Application: Basic PCs for home / home-office use network workstations audio/video equipment home entertainment systems and other sensitive electronic devices.
  • WatchDog compatibility: Yes compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications
  • Supports entry-level PC systems up to 17 minutes during blackout conditions
  • Form factors supported: Ultra-compact desk/floor mount mounting flanges enable wall-mount installation
  • 8 output receptacles 2 of which are widely spaced to accommodate large transformer plugs without blocking outlets
  • 4 outlets feature full battery support and surge suppression protecting computers monitors and other vital system components from loss of power
  • 4 additional outlets with surge suppression only are ideal for printers and other peripherals not requiring battery support
  • HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows Mac OS X and Linux
Additional Warranty Information

2-year warranty. $100000 Ultimate Lifetime Insurance (USA Puerto Rico and Canada only).
Alarm
Self-test Operation
Alarm
Battery Backup
Alarm
Fault
Alarm
Overload
Alarm
Replace Battery
Alarm
Low Battery
Application/Usage
Home Theater
Application/Usage
Security System
Application/Usage
Router
Application/Usage
Media Center
Application/Usage
Speaker
Application/Usage
Gaming Console
Application/Usage
Computer
Application/Usage
Blu-ray Player
Application/Usage
Printer
Application/Usage
Home/Office
Application/Usage
Digital Signage
Application/Usage
TV
Application/Usage
ATM
Backup/Run Time (Full Load)
5.50 Minute
Backup/Run Time (Full Load)
2 Minute
Backup/Run Time (Half Load)
9 Minute
Backup/Run Time (Half Load)
12 Minute
Battery life
6 Year
Brand Name
Tripp Lite
Certifications & Standards
  • Tested to UL1778 (USA)
  • cUL1778 (Canada)
  • NOM (Mexico)
  • FCC Class B (Emissions)
  • FCC Part 68
  • Industry Canada (Telecommunications)
Color
Black
Cord Length
6 ft
Country of origin
United States
Country of origin
China
Dataline Protection
RJ-11
Depth
6"
Depth
12"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Mini Desktop
Form factor
Ultra-compact Desktop/Tower/Wall Mount
Height
4.3"
Height
3.5"
Hot Swappable
Yes
Input current
12 A
Input voltage
120 V AC
Input voltage
110 V AC
Limited Warranty
3 Year Lifetime
Limited Warranty
3 Year
Load Capacity
550 VA/300 W
Manufacturer
Tripp Lite by Eaton
Manufacturer
Tripp Lite
Manufacturer Part Number
AVR550U
Manufacturer Website Address
http://www.tripplite.com
Marketing Information

550VA/300W/120V Battery Backup for PCs Home Theater or Digital Signage
The line-interactive AVR550U UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts brownouts overvoltages surges and line noise that can damage valuable electronics or destroy data. The eight-outlet 120V battery backup is ideal protection for your home office media center or commerce components including computers routers printers HDTVs Blu-ray players game consoles ATMs security systems and digital signage equipment.

Allows Time to Back Up Critical Files During a Blackout Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load but the line-interactive UPS system should keep an energy-efficient desktop computer with small LCD monitor powered as long as 32 minutes. During normal operation incoming utility power keeps the replaceable internal battery fully charged so backup power will always be available.

8 NEMA 5-15R Outlets Protect Your Connected Components Four 5-15R outlets provide battery backup surge protection and voltage regulation for your computer monitor and other crucial components. The other four 5-15R outlets provide surge suppression only for printers speakers and other desktop equipment regarded as non-essential during a blackout. A high >95% line mode efficiency rating reduces BTU emissions energy consumption and ultimately your energy costs.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions AVR protects your equipment from incremental hardware damage data loss and performance problems caused by brownouts and overvoltages. The AVR550U can correct brownouts as low as 89V and overvoltages as high as 145V back to nominal 120V power continuously all while keeping the battery fully charged and ready to take over in case of power failure.

316 Joules Fight Back Against Unexpected Power Surges A 316-joule surge suppression rating protects connected components from the harmful effects of power surges.

Combats Electromagnetic Interference That Can Harm Equipment Various electromagnetic and radio sources found in virtually every home and business can cause disruptive interference on the AC line. Known as EMI (electromagnetic interference) and RFI (radio frequency interference) this line noise is a common cause of performance problems and can lead to incremental hardware damage data corruption and audio/video transmission problems. The AVR550U incorporates technology that filters out disruptive line noise so that it won't affect your equipment

Home-Friendly Alarm and Diagnostic LEDs Keep You Informed 24/7 The UPS remains silent in both line and battery backup modes. The alarm sounds only to report low battery battery replace overload and fault condition. Dual front-panel LEDs report line and battery mode operation

More from the Manufacturer
Marketing Information

550VA/300W/120V Battery Backup for PCs Home Theater or Digital Signage
The line-interactive AVR550U UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts brownouts overvoltages surges and line noise that can damage valuable electronics or destroy data. The eight-outlet 120V battery backup is ideal protection for your home office media center or commerce components including computers routers printers HDTVs Blu-ray players game consoles ATMs security systems and digital signage equipment.

Allows Time to Back Up Critical Files During a Blackout Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load but the line-interactive UPS system should keep an energy-efficient desktop computer with small LCD monitor powered as long as 32 minutes. During normal operation incoming utility power keeps the replaceable internal battery fully charged so backup power will always be available.

8 NEMA 5-15R Outlets Protect Your Connected Components Four 5-15R outlets provide battery backup surge protection and voltage regulation for your computer monitor and other crucial components. The other four 5-15R outlets provide surge suppression only for printers speakers and other desktop equipment regarded as non-essential during a blackout. A high >95% line mode efficiency rating reduces BTU emissions energy consumption and ultimately your energy costs.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions AVR protects your equipment from incremental hardware damage data loss and performance problems caused by brownouts and overvoltages. The AVR550U can correct brownouts as low as 89V and overvoltages as high as 145V back to nominal 120V power continuously all while keeping the battery fully charged and ready to take over in case of power failure.

316 Joules Fight Back Against Unexpected Power Surges A 316-joule surge suppression rating protects connected components from the harmful effects of power surges.

Combats Electromagnetic Interference That Can Harm Equipment Various electromagnetic and radio sources found in virtually every home and business can cause disruptive interference on the AC line. Known as EMI (electromagnetic interference) and RFI (radio frequency interference) this line noise is a common cause of performance problems and can lead to incremental hardware damage data corruption and audio/video transmission problems. The AVR550U incorporates technology that filters out disruptive line noise so that it won't affect your equipment

Home-Friendly Alarm and Diagnostic LEDs Keep You Informed 24/7 The UPS remains silent in both line and battery backup modes. The alarm sounds only to report low battery battery replace overload and fault condition. Dual front-panel LEDs report line and battery mode operation

More from the Manufacturer
Maximum Operating Temperature
104°F (40°C)
Maximum Operating Temperature
122°F (50°C)
Output voltage
120 V AC
Output voltage
110 V AC
Output voltage
115 V AC
Package Contents
  • AVR 550VA Desktop UPS
  • USB cable
  • Owner's manual
Packaged Quantity
1 Each
Plug/Connector Type
NEMA 5-15P
Product Name
AVR 550VA Desktop UPS
Product Name
AVR 550VA Mini-Desktop UPS
Product Series
AVR
Product Type
Line-interactive UPS
Receptacle Type
NEMA 5-15R
Receptacles
4 x NEMA 5-15R
Recycled
No
Software Included
PowerAlert UPS monitoring software
Status Indicators

2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low overload replace-battery and fault conditions
Status Indicators

2 LEDs indicate:

  • Line power
  • Battery power
Surge energy rating
420 J
Surge energy rating
316 J
Transfer Time
6 ms
Transfer Time
4 ms
Typical Battery Recharge Time
8 Hour
Typical Battery Recharge Time
9 Hour
Weight (Approximate)
10.96 lb
Weight (Approximate)
13.69 lb
Width
6.4"
Width
11.3"
