Tripp Lite PDU Monitored 208/240V 30A 36 C13; 6 C19 L6-30P LX Interface 0U
Tripp Lite PDU Monitored 208/240V 30A 36 C13; 6 C19 L6-30P LX Interface 0U - Monitored - NEMA L6-30P - 6 x IEC 60320 C19, 36 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - Rack-mountable - TAA Compliant
| $707.48 | Retail $988.42 |
- 5/5.8kW 208/240V single-phase monitored 0U PDU
- 42 outlets-36 C13, 6 C19-with plug-lock insert sleeves
- Built-in Java-free LX Platform interface for remote access 24/7
- Digital ammeter for on-site load monitoring in real time
- NEMA L6-30P input with 10 ft. AC power cord
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
34532
Item:
PDUMNV30HV2LX
UPC Code:
037332204486
Our Part #
TRPPDUMNV30HV2LX
Condition
New
$707.48EA
$988.42
$988.42
Availability
Only 10 Left In Stock
Product description
Tripp Lite PDU Monitored 208/240V 30A 36 C13; 6 C19 L6-30P LX Interface 0U - Monitored - NEMA L6-30P - 6 x IEC 60320 C19, 36 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - Rack-mountable - TAA Compliant
Monitored - NEMA L6-30P - 6 x IEC 60320 C19, 36 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - Rack-mountable - TAA Compliant
Specifications
Mounting Orientation
Vertical
PDU Type
Monitored
Phase
Single Phase
Power Rating (Watt)
5800 W
Receptacle Detail
36 x IEC 60320 C13
Receptacle Detail
6 x IEC 60320 C19
UPC Alternates
037332204486 818283522986
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
2.7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
70"
Input current
30 A
Input voltage
230 V AC
Limited Warranty
2 Year
Management
Protocols:
- IPv4
- IPv6
- HTTP
- HTTPS
- SMTP
- SNMPv1
- SNMPv2
- SNMPv3
- telnet
- SSH
- FTP
- DHCP
- NTP
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMNV30HV2LX
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
The PDUMNV30HV2LX 5.8kW Single-Phase Monitored PDU provides real-time remote monitoring of voltage frequency and load levels via built-in network connection. By reducing the frequency of on-site visits these advanced remote capabilities can save you money and reduce downtime.
The 0U PDU features 42 outlets (36 C13 and 6 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A 10-foot cord with NEMA L6-30P plug connects the PDU to a compatible AC power source generator or protected UPS.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.
A digital ammeter allows you to monitor each load bank's current and the total connected PDU load in real time to ensure they remain well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
The 0U PDU features 42 outlets (36 C13 and 6 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A 10-foot cord with NEMA L6-30P plug connects the PDU to a compatible AC power source generator or protected UPS.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.
A digital ammeter allows you to monitor each load bank's current and the total connected PDU load in real time to ensure they remain well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
Mount Type
Rack-mountable
Output voltage
240 V AC
Output voltage
208 V AC
Output voltage
200 V AC
Package Contents
- PDUMNV30HV2LX 42-Outlet PDU
- Built-in LX Platform Interface
- Configuration Cable
- 42 x Plug-lock Insert Sleeves
- Rack-mounting Hardware
- Mounting Bracket Accessory
- Owner's Manual
Plug/Connector Type
NEMA L6-30P
Product Name
PDUMNV30HV2LX 42-Outlet PDU
Product Type
PDU
Rack Height
0U
Receptacle Type
IEC 60320 C19
Receptacle Type
IEC 60320 C13
Weight (Approximate)
15 lb
Width
2.2"
