AXIS A8207-VE MkII Network Video Door Station

• NEMA4X-rated
• IEEE802.3af/802.3at Type 1 Class 3
• IEEE802.3at Type 2 Class 4

• EN55032 Class A
• EN55024
• EN61000-6-2
• FCC Part 15 Subpart B Class A and Subpart C and Subpart E

• IEC/EN/UL62368-1
• IEC/EN/UL60950-22
• UL293
• UL294

• IEC60068-2-1
• IEC60068-2-2
• IEC60068-2-14
• IEC60068-2-27
• IEC60068-2-6
• IEC60068-2-78
• IEC/EN60529IP66
• IEC/EN62262IK08
• NEMA 250 Type 4X

• EN300330
• EN62311
• RSS-Gen
• RSS-210
• EN301489-3
• EN303348

• Full-featured 6 MP IP camera
• Integrated RFID reader with keypad for use with access control systems
• Support for HID® iClass®
• Keypad for dialing
• Acoustic echo cancellation and noise reduction
• Enhanced cybersecurity with Signed firmware and Secure Boot
• HDMI output for live streaming to a public monitor

AXIS A8207-VE MkII Network Video Door Station combines video surveillance two-way communication and the possibility for access control integration in a single device. Not only is it our most advanced door station yet it's also a powerful enabler of better overall security. Its open interfaces offer countless possibilities for integration so it can easily be combined with other systems within your security solution to meet your specific needs. AXIS A8207-VE MkII is perfect for installation at entrances where there are many known and unknown visitors passing through on a regular basis.

The best of three worlds

AXIS A8207-VE MkII is three top-of-the-line security solutions in one which eliminates the need for additional equipment around your entrances. For clear two-way communication between personnel and all visitors it offers echo cancellation noise reduction and an induction loop for hearing aids. It allows you to receive video calls from visitors and remotely control access through your computer desk phone or mobile device. For employees or other known visitors it has an integrated access control reader (RFID) for easy integration with the access control system of your choice.

There are superior network surveillance capabilities in the form of a full-featured 6 MP security camera with advanced technologies like wide dynamic range Axis Zipstream and ACAP support for intelligent analytics. It also includes a multifunctional PIR sensor for example to detect approaching individuals and then trigger events like a recording or a verbal greeting. Third party audio analytics can be integrated to trigger audio warnings or recordings for instance if the sound of gunshots or aggression is detected. And built-in tamper detectors can trigger events if someone attempts to gain access by manipulating the door station. AXIS A8207-VE MKII also has enhanced cyber security providing signed firmware with Secure Boot.

Truly open is truly smart

AXIS A8207-VE MkII offers true openness which means you're not dependent on proprietary hardware or software. Instead you're free to use AXIS A8207-VE MkII with open-standard hardware or software from the supplier of your choice -integrated with the solutions you already own or the ones you decide to purchase next year.

And because AXIS A8207-VE MkII is built on an open platform you can integrate with a long list of other systems and solutions for video surveillance access control and VoIP communication. It features a multitude of ports relays and supported protocols that allow you to connect external sensors activate lights open doors trigger cameras or sound alarms. The - smart - possibilities are practically endless. It even has an HDMI output that lets you mount any standard screen on the inside of the door creating a virtual window to see if it safe to go out.

• A8207-VE MkII Network Video Door Station
• Installation Guide
• Torx TR20 Bit
• Terminal Block Connectors
• Connector Guard
