APC by Schneider Electric Rack ATS, 208V, 30A, (2) L6-30P in, (1) L6-30R Out
APC by Schneider Electric Rack ATS, 208V, 30A, (2) L6-30P in, (1) L6-30R Out - 1 x NEMA L6-30R - 208 V AC - 30 A
| $2,020.11 | Retail $2,295.00 |
- 10 kAIC Overcurrent Protection - Provides protection in the event of a significant overcurrent event.
- Command line interface - Offers simultaneous remote management access through Telnet and SSH
- Current Monitoring - Monitors the aggregate current draw per power distribution unit.
- Cyber security - A cyber-secure connection provides improved security for your infrastructure devices, and machine data forms the basis of operational insights and analytics, aimed at reducing equipment maintenance costs.
- Local Current Monitoring Display - The aggregate current draw per rack PDU is displayed on the unit via a digital display. The local digital display helps installers avoid overloaded circuits by providing a visible warning when the current draw is close to the maximum amperage draw of the strip. (Available on designated SKUs only)
- Quick Transfer Rate - Transfer rate is within the industry standard and within the time power supplies will ty
By:
APC by Schneider Electric
Manufacturer:
Schneider Electric Sa
Product ID:
58914
Item:
AP4431
UPC Code:
731304333456
Our Part #
2CF099
Condition
New
$2,020.11EA
$2,295.00
$2,295.00
Availability
Only 2 Left In Stock
Product description
APC by Schneider Electric Rack ATS, 208V, 30A, (2) L6-30P in, (1) L6-30R Out - 1 x NEMA L6-30R - 208 V AC - 30 A
1 x NEMA L6-30R - 208 V AC - 30 A
Specifications
UPC Alternates
731304333456 818216955270
Brand Name
APC by Schneider Electric
Certifications & Standards
- FCC Part 15 Class A
- ICES-003
- TUV-C
- TUV-NURTL
- VCCI Class A
Certifications & Standards
- FCC Part 15 Class A
- ICES-003
- TUV-C
- TUV-NURTL
- VCCI Class A
Current
30 A
Depth
9.3"
Environmental Certification
RoHS
Environmental Certification
Tïż½V
Environmentally Friendly
Yes
Form factor
Rack-mountable
Height
3.5"
Input voltage
208 V AC
Limited Warranty
2 Year
Manufacturer
Schneider Electric SA
Manufacturer Part Number
AP4431
Manufacturer Website Address
http://www.schneider-electric.com
Marketing Information
APC Rack Automatic Transfer Switches (rack ATS) provide reliable redundant rack mount power to single-corded equipment. The rack ATS has dual input power cords supplying power to the connected load. If the primary power source becomes unavailable the rack ATS will seamlessly source power from the secondary source without interrupting critical loads. The Rack ATS has built-in network connectivity which allows for remote management via Web SNMP or Telnet interfaces.
Package Contents
Plug/Connector Type
NEMA L6-30P
Product color
Black
Product Name
Rack ATS 208V 30A (2) L6-30P in (1) L6-30R Out
Product Type
Automatic Transfer Switch
Protection Type
Over Current
Rack Height
2U
Receptacles
1 x NEMA L6-30R
Weight (Approximate)
14.30 lb
Width
17"
