Cisco IE-2000-4TS-G-B Ethernet Switch
Cisco IE-2000-4TS-G-B Ethernet Switch - 4 Ports - Manageable - Fast Ethernet - 10/100Base-TX - 2 Layer Supported - 2 SFP Slots - Power Supply - Twisted Pair - Desktop, Rail-mountable - 1 Year Limited Warranty
| $1,269.71 | Retail $1,732.93 |
- Quickly and easily set up a wired network with 4 networking ports
- Cascade to other network devices through the uplink port to expand your local area network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Featuring Fast Ethernet ports to speed up the transfer rate up to 100mb/sec of large files and digital assets across your network
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Management capability provides control over setup and configuration of your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
- The switch is rail mountable, you can easily install it in racks with concrete stability
By:
Cisco
Manufacturer:
Cisco Systems, Inc
Product ID:
59055
Item:
IE-2000-4TS-G-B
UPC Code:
020381399500
Our Part #
PN6093
Condition
New
$1,269.71EA
$1,732.93
$1,732.93
Availability
Only 96 Left In Stock
Product description
Cisco IE-2000-4TS-G-B Ethernet Switch - 4 Ports - Manageable - Fast Ethernet - 10/100Base-TX - 2 Layer Supported - 2 SFP Slots - Power Supply - Twisted Pair - Desktop, Rail-mountable - 1 Year Limited Warranty
4 Ports - Manageable - Fast Ethernet - 10/100Base-TX - 2 Layer Supported - 2 SFP Slots - Power Supply - Twisted Pair - Desktop, Rail-mountable - 1 Year Limited Warranty
Specifications
Maximum Memory Supported
1 GB
Memory Card Supported
SD
UPC Alternates
020381399500 882658495540
Brand Name
Cisco
Certifications & Standards
Safety:
- UL/CSA 60950-1
- EN 60950-1
- CB to IEC 60950-1 (with country deviations)
- NOM to NOM-019-SCF1 (through partners and distributors)
- CE Marking
Hazard:
- ANSI/ISA 12.12.01 (Class 1 Div 2 A-D)
- EN 60079-0 -15 ATEX certification (Class I Zone 2 A-D)
EMC Emission and Community:
- FCC 47 CFR Part 15 Class A
- EN 55022A Class A
- VCCI Class A
- AS/NZS CISPR 22 Class A AS/NZS CISPR 24
- CISPR11 Class A CISPR22 Class A
- ICES 003 Class A
- KCC -Korea
- CE Marking
- C-Tick (Australia)
- Russia certification
- Brazil certification
- IEC/EN61000-4-2 (Electro Static Discharge) 15kV Air/8kV Contact
- IEC/EN 61000-4-3 (Radiated Immunity 10 and 20V/m)
- IEC/EN 61000-4-4 (Fast Transients - 4kV power line 4kV data line
- IEC/EN 61000-4-5 (Surge 2 kV/1 kV)
- IEC/EN 61000-4-6 (Conducted Immunity 10V/emf)
- IEC/EN 61000-4-8 (Power Frequency Magnetic Field Immunity)
- IEC/EN 61000-4-9 (Pulse Magnetic Field Immunity)
- IEC/EN 61000-4-10 (Oscillatory Magnetic Field Immunity)
- IEC/EN 61000-4-11 (AC power Voltage Immunity)
- IEC/EN 61000-4-29 (Voltage Dips Immunity)
- IEC/EN 61000-6-1 (Immunity for Light Industrial Environments)
- IEC/EN 61000-6-4 Class A
- EN 61326
Shock and Vibration:
- IEC 60068-2-27 (Operational Shock: 30G 11ms half sine)
- IEC 60068-2-27 (Non-Operational Shock 55-70G trapezoidal)
- IEC 60068-2-6 IEC 60068-2-64 (Operational Vibration 2g@10-500Hz)
- IEC 60068-2-6 IEC 60068-2-64 (Non-operational Vibration)
Industry:
- UL 508
- CSA C22.2 No. 142
- EN 61131-2 (Programmable Controllers)
- Protective Coating
- Substation (IEEE 1613 IEC 61850-3) KEMA
- Lloyd's Register Type Approval - ENV2 or ENV3
- British German Lloyds
- Marine (LR BV GL DnV Rina ABS KR)
- RA 156-165 Mhz 24 dBuV/M - Class A is 50 dBuV/M - Marine Band
- Railway EN 50155
- NEMA TS-2
- IP30
- ODVA Industrial EtherNet/IP
- PROFINETv2
Corrosive Testing:
- ISO-12944-6
- IEC-60068-2-60
Humidity:
- IEC 60068-52-2 (Salt Fog Mist Test Kb) Marine environments
- IEC 60068 -2-3
- IEC 60068-2-30
- Relative Humidity: 5% to 95% Non-condensing
Depth
4.5"
Environmental Certification
RoHS
Ethernet Technology
Fast Ethernet
Expansion Slot Type
SFP
Flash memory
64 MB
Form factor
Rail-mountable
Form factor
Desktop
Height
5.1"
Input voltage
60 V DC
Layer Supported
2
Limited Warranty
1 Year
Manageable
Yes
Management
- Telnet
- HTTPS
- SNMP
- CNA
- VLAN
Manufacturer
Cisco Systems Inc
Manufacturer Part Number
IE-2000-4TS-G-B
Manufacturer Website Address
http://www.cisco.com
Marketing Information
The Cisco® Industrial Ethernet 2000 (IE 2000) Series is a range of compact industrially ruggedized access switches. IE 2000 series provide customers with ease of use secure access and industry leading convergence using Cisco Resilient Ethernet Protocol (REP). Multiple industries such as automotive oil and gas mining transportation and energy companies are all increasingly requiring IP based networks in their production areas. The newest IE 2000 additions have been designed to support access layer connectivity and to meet the increasing needs for security voice and video traffic across industrial networks.
Media Type Supported
Twisted Pair
Memory Technology
DRAM
MTBF
374052 Hour
Network Technology
10/100Base-TX
Number of Network (RJ-45) Ports
4
Power source
Power Supply
Product Name
IE-2000-4TS-G-B Ethernet Switch
Product Series
IE-2000
Product Type
Ethernet Switch
Standard Memory
256 MB
Token Ring Port
No
Twisted Pair Cable Standard
Category 5
Weight (Approximate)
2.45 lb
Width
3"
