Cisco IE-2000-8TC-G-L Ethernet Switch

Safety:

• UL/CSA 60950-1
• EN 60950-1
• CB to IEC 60950-1 (with country deviations)
• NOM to NOM-019-SCF1 (through partners and distributors)
• CE Marking

Hazard:

• ANSI/ISA 12.12.01 (Class 1 Div 2 A-D)
• EN 60079-0 -15 ATEX certification (Class I Zone 2 A-D)

EMC Emission and Community:

• FCC 47 CFR Part 15 Class A
• EN 55022A Class A
• VCCI Class A
• AS/NZS CISPR 22 Class A AS/NZS CISPR 24
• CISPR11 Class A CISPR22 Class A
• ICES 003 Class A
• KCC -Korea
• CE Marking
• C-Tick (Australia)
• Russia certification
• Brazil certification
• IEC/EN61000-4-2 (Electro Static Discharge) 15kV Air/8kV Contact
• IEC/EN 61000-4-3 (Radiated Immunity 10 and 20V/m)
• IEC/EN 61000-4-4 (Fast Transients - 4kV power line 4kV data line
• IEC/EN 61000-4-5 (Surge 2 kV/1 kV)
• IEC/EN 61000-4-6 (Conducted Immunity 10V/emf)
• IEC/EN 61000-4-8 (Power Frequency Magnetic Field Immunity)
• IEC/EN 61000-4-9 (Pulse Magnetic Field Immunity)
• IEC/EN 61000-4-10 (Oscillatory Magnetic Field Immunity)
• IEC/EN 61000-4-11 (AC power Voltage Immunity)
• IEC/EN 61000-4-29 (Voltage Dips Immunity)
• IEC/EN 61000-6-1 (Immunity for Light Industrial Environments)
• IEC/EN 61000-6-4 Class A
• EN 61326

Shock and Vibration:

• IEC 60068-2-27 (Operational Shock: 30G 11ms half sine)
• IEC 60068-2-27 (Non-Operational Shock 55-70G trapezoidal)
• IEC 60068-2-6 IEC 60068-2-64 (Operational Vibration 2g@10-500Hz)
• IEC 60068-2-6 IEC 60068-2-64 (Non-operational Vibration)

Industry:

• UL 508
• CSA C22.2 No. 142
• EN 61131-2 (Programmable Controllers)
• Protective Coating
• Substation (IEEE 1613 IEC 61850-3) KEMA
• Lloyd's Register Type Approval - ENV2 or ENV3
• British German Lloyds
• Marine (LR BV GL DnV Rina ABS KR)
• RA 156-165 Mhz 24 dBuV/M - Class A is 50 dBuV/M - Marine Band
• Railway EN 50155
• NEMA TS-2
• IP30
• ODVA Industrial EtherNet/IP
• PROFINETv2

Corrosive Testing:

• ISO-12944-6
• IEC-60068-2-60

Humidity:

• IEC 60068-52-2 (Salt Fog Mist Test Kb) Marine environments
• IEC 60068 -2-3
• IEC 60068-2-30
• Relative Humidity: 5% to 95% Non-condensing

• Telnet
• Web Base Management
• SNMP
• CNA
• VLAN
• CiscoWorks LAN Management Solution (LMS)
• DHCP

The Cisco® Industrial Ethernet 2000 (IE 2000) Series is a range of compact industrially ruggedized access switches. IE 2000 series provide customers with ease of use secure access and industry leading convergence using Cisco Resilient Ethernet Protocol (REP). Multiple industries such as automotive oil and gas mining transportation and energy companies are all increasingly requiring IP based networks in their production areas. The newest IE 2000 additions have been designed to support access layer connectivity and to meet the increasing needs for security voice and video traffic across industrial networks.
