APC by Schneider Electric Smart-UPS X 3000VA Rack/Tower LCD 100-127V
APC by Schneider Electric Smart-UPS X 3000VA Rack/Tower LCD 100-127V - 4U Rack-mountable - 3 Hour Recharge - 6 Minute Stand-by - 110 V AC Input - 120 V AC Output - 3 x NEMA 5-20R, 1 x NEMA L5-30R, 6 x NEMA 5-15R
| $2,435.53 | Retail $3,000.00 |
- Auto recognition of external batteries - UPS recognizes when external battery packs are attached and automatically adjusts runtime.
- Cold-start capable - Provides temporary battery power when the utility power is out.
- Energy meter - Provides actual kilowatt hours of usage for energy conscious users.
- Green mode - Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- High frequency design - Reduces or eliminates bulky transformers resulting in lighter units for ease of handling.
- High online efficiency - Reduces utility costs, generates less heat.
- Intelligent battery management - Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Intuitive LCD interface - Provides clear and accurate information in multiple languages with the ability to configure the UPS l
By:
APC by Schneider Electric
Manufacturer:
Schneider Electric Sa
Product ID:
59494
Item:
SMX3000LV
UPC Code:
012302529813
Our Part #
2Q0245
Condition
New
$2,435.53EA
$3,000.00
$3,000.00
Availability
Only 46 Left In Stock
Product description
APC by Schneider Electric Smart-UPS X 3000VA Rack/Tower LCD 100-127V - 4U Rack-mountable - 3 Hour Recharge - 6 Minute Stand-by - 110 V AC Input - 120 V AC Output - 3 x NEMA 5-20R, 1 x NEMA L5-30R, 6 x NEMA 5-15R
4U Rack-mountable - 3 Hour Recharge - 6 Minute Stand-by - 110 V AC Input - 120 V AC Output - 3 x NEMA 5-20R, 1 x NEMA L5-30R, 6 x NEMA 5-15R
Specifications
Load Capacity (VA)
2880 VA
Load Capacity (W)
2700 W
Number of Battery & Surge Outlets
10
Receptacle Detail
3 x NEMA 5-20R
Receptacle Detail
1 x NEMA L5-30R
Receptacle Detail
6 x NEMA 5-15R
UPC Alternates
012302529813 192223068261 731304292647 818214441188
Waveform Type
Sine Wave
Backup/Run Time (Full Load)
6 Minute
Backup/Run Time (Half Load)
18 Minute
Battery Characteristics
Spill-proof Maintenance-free
Battery Chemistry
Sealed Lead Acid (SLA)
Battery Chemistry
Lead Acid
Brand Name
APC by Schneider Electric
Certifications & Standards
- BSMI
- CSA
- EN 50091-2
- EN 55022 Class A
- FCC Part 15 Class A
- NOM
- TUV
- UL 1778
- VCCI Class A
- UL 1449
Depth
19"
Environmental Certification
REACH
Environmental Certification
RoHS
Form factor
Rack-mountable
Height
17"
Hot Swappable
Yes
Input voltage
110 V AC
Limited Warranty
3 Year
Load Capacity
2880 VA/2700 W
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SMX3000LV
Manufacturer Website Address
http://www.schneider-electric.com
Marketing Information
Over 20 million units sold - the UPS you can trust
APC award-winning Smart-UPS® is the most popular UPS in the world for servers storage and network power protection. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. In addition to legendary reliability and manageability Smart-UPS have extremely high efficiency at low medium and high load levels making them ideal for today's multi-core or virtualized servers that have varying load consumption. Available in a variety of form factors (tower rack mount rack/tower convertible) there is a model for every application and budget. Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS® models have long been considered the benchmark for all network and server UPS's. Smart-UPS feature a 16-segment LED display extended range automatic voltage regulation (AVR) and pure sine wave output on battery. Additional manageability options are available through the Smart-Slot interface which is an internal slot for the installation of optional accessory cards. The extended run Smart-UPS XL has the capability to add external battery packs to scale runtime from minutes to hours typically needed for converged voice and data network power protection. The entry level Smart-UPS SC is an economical choice for small and medium businesses looking to protect small switches networking devices and point-of-sale (POS) equipment.
Marketing Information
Over 20 million units sold - the UPS you can trust
APC award-winning Smart-UPS® is the most popular UPS in the world for servers storage and network power protection. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. In addition to legendary reliability and manageability Smart-UPS have extremely high efficiency at low medium and high load levels making them ideal for today's multi-core or virtualized servers that have varying load consumption. Available in a variety of form factors (tower rack mount rack/tower convertible) there is a model for every application and budget. Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS® models have long been considered the benchmark for all network and server UPS's. Smart-UPS feature a 16-segment LED display extended range automatic voltage regulation (AVR) and pure sine wave output on battery. Additional manageability options are available through the Smart-Slot interface which is an internal slot for the installation of optional accessory cards. The extended run Smart-UPS XL has the capability to add external battery packs to scale runtime from minutes to hours typically needed for converged voice and data network power protection. The entry level Smart-UPS SC is an economical choice for small and medium businesses looking to protect small switches networking devices and point-of-sale (POS) equipment.
Number of Batteries
1
Output voltage
120 V AC
Package Contents
Plug/Connector Type
NEMA L5-30P
Product color
Black
Product Line
Smart-UPS
Product Name
Smart-UPS X 3000VA Rack/Tower LCD 100-127V
Product Type
Line-interactive UPS
Rack Height
4U
Receptacle Type
NEMA 5-15R
Receptacle Type
NEMA 5-20R
Receptacle Type
NEMA L5-30R
Transfer Time
4 ms
Typical Battery Recharge Time
3 Hour
Weight (Approximate)
85.19 lb
Width
7"
