Panorama Antennas LG-IN2444 Antenna
Panorama Antennas LG-IN2444 Antenna - 617 MHz to 960 MHz, 1710 MHz to 6000 MHz, 1562 MHz to 1612 MHz - 9 dBi - Wireless Router, Cellular Network, GPS, GLONASS - White - Panel - Omni-directional - SMA Connector - TAA Compliant
| $301.84 | Retail $441.23 |
- Provides ease of management and installation thanks to its omni-direction feature
- Operates at 9 dBi gain
- Perfect to be used with wireless router
- Antenna can be mounted as panel
By:
Panorama Antennas
Manufacturer:
Panorama Antennas Ltd
Product ID:
59615
Item:
LG-IN2444-W
Our Part #
6KK642
Condition
New
$301.84EA
$441.23
$441.23
Availability
Currently out of stock
You may be also interested
Product description
Panorama Antennas LG-IN2444 Antenna - 617 MHz to 960 MHz, 1710 MHz to 6000 MHz, 1562 MHz to 1612 MHz - 9 dBi - Wireless Router, Cellular Network, GPS, GLONASS - White - Panel - Omni-directional - SMA Connector - TAA Compliant
617 MHz to 960 MHz, 1710 MHz to 6000 MHz, 1562 MHz to 1612 MHz - 9 dBi - Wireless Router, Cellular Network, GPS, GLONASS - White - Panel - Omni-directional - SMA Connector - TAA Compliant
Specifications
Antenna Gain
9 dBi
Antenna Gain (Isotropic)
9 dBi
Directivity
Omni-directional
Operating Frequency Range
617 MHz to 960 MHz
Operating Frequency Range
1710 MHz to 6000 MHz
Operating Frequency Range
1562 MHz to 1612 MHz
Application/Usage
GPS
Application/Usage
Wireless Router
Application/Usage
GLONASS
Application/Usage
Cellular Network
Brand Name
Panorama Antennas
Compatibility
Cradlepoint COR IBR1700 Series Routers
Connector Type
SMA
Diameter
7.09"
Environmental Certification
RoHS
Environmental Certification
REACH
Environmentally Friendly
Yes
Form factor
Panel
Height
3.15"
Manufacturer
Panorama Antennas Ltd
Manufacturer Part Number
LG-IN2444-W
Manufacturer Website Address
http://www.panorama-antennas.com
Marketing Information
The LG-IN2444 is a high performance 4x4 MiMo LTE and GPS/GNSS antenna covering 617-960/1710-6000MHz.
- Low profile antenna with 5 functions in 1
- 4x4 MiMo 4G/5G LTE cellular and GPS/GNSS in one housing
- Kits with extension cables available for a range of LTE routers
- Suitable for Cradlepoint COR IBR1700 Series Routers
The LG-IN2444 range has been designed to provide 4x4 4G/5G MiMo performance from 617-960/1710-6000MHz combined with GPS/GNSS in a compact low profile housing.
The antenna is designed to be panel mounted and can be fitted on a conductive or non- conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UNECE 118.01 and EN45545-2) and a halogen free flame retardant radome the antenna is suitable for many environments and applications. The antenna radome is available in black or white and meets IK10 for vandal resistance and IP69K for ingress protection.
The integrated GPS/GNSS module supports GPS Glonass Galileo QZSS and Compass with 26dB LNA gain. This GPS module features advanced filtering for LTE B13/14 designed to minimise potential in band interference.
LG-IN2444 is supplied as a complete plug and play kit with integrated 5m (16') ultra-low loss TPE extension cables and SMA (m) connectors for 4G/5G and GPS.
Product color
White
Product Model
LG-IN2444
Product Name
LG-IN2444 Antenna
Product Type
Antenna
