Panorama Antennas LP[G]AM-BC3G-26 | Compact Low profile MiMo 2G/3G/4G Antenna
Panorama Antennas LP[G]AM-BC3G-26 | Compact Low profile MiMo 2G/3G/4G Antenna - 698 MHz to 960 MHz, 1710 MHz to 3800 MHz, 1562 MHz to 1612 MHz - 26 dB - Cellular Network, Wireless Data Network - Black - Panel - Omni-directional - SMA Connector
| $61.84 | Retail $75.60 |
- Provides ease of management and installation thanks to its omni-direction feature
- Operates at 26 dB gain
- This antenna is ideal for use and provide connectivity to your cellular network
- Designed to be light in weight and easy to install
By:
Panorama Antennas
Manufacturer:
Panorama Antennas Ltd
Product ID:
59640
Item:
LGAM-BC3G-26-3SP
Our Part #
6DC639
Condition
New
$61.84EA
$75.60
$75.60
Availability
Currently out of stock
Product description
Panorama Antennas LP[G]AM-BC3G-26 | Compact Low profile MiMo 2G/3G/4G Antenna - 698 MHz to 960 MHz, 1710 MHz to 3800 MHz, 1562 MHz to 1612 MHz - 26 dB - Cellular Network, Wireless Data Network - Black - Panel - Omni-directional - SMA Connector
698 MHz to 960 MHz, 1710 MHz to 3800 MHz, 1562 MHz to 1612 MHz - 26 dB - Cellular Network, Wireless Data Network - Black - Panel - Omni-directional - SMA Connector
Specifications
Antenna Gain
26 dB
Directivity
Omni-directional
Operating Frequency Range
1710 MHz to 3800 MHz
Operating Frequency Range
698 MHz to 960 MHz
Operating Frequency Range
1562 MHz to 1612 MHz
Application/Usage
Wireless Data Network
Application/Usage
Cellular Network
Brand Name
Panorama Antennas
Connector Type
SMA
Depth
5.91"
Form factor
Panel
Height
1.93"
Manufacturer
Panorama Antennas Ltd
Manufacturer Part Number
LGAM-BC3G-26-3SP
Manufacturer Website Address
http://www.panorama-antennas.com
Marketing Information
The LP[G]AM-BC3G-26 range has been designed to provide MiMo Cellular / LTE antenna function for IOT and M2M applications.
- Supports 2x2 MiMo 2G/3G/4G
- Ideal for vending machines and kiosks
- Optional GPS/GNSS (26dB LNA)
The compact robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTEbands in freq. range 698-960/1710-3800MHz. The LG version includes an active GPS/GNSS/Galileo/Beidou antenna for applications which require position or timing function.
The antenna can be fitted on a non- conductive panel if required and offers easy quick secure and weatherproof installation with the single hole mounting bush and acrylic adhesive sealing pad. Supplied with integrated 3m (10') cables and SMA plug connectors the antenna will offer plug and play connectivity with many different terminals.
Product color
Black
Product Name
LP[G]AM-BC3G-26 | Compact Low profile MiMo 2G/3G/4G Antenna
Product Type
Antenna
Width
1.77"
