Geist Environmental Monitor -Watchdog 100-P

• Activity LED: 1
• Idle LED: 1
• Power Over Eithernet (PoE): Yes
• Power Supply Compatible with these Systems Input: AC 100-240V 50/60Hz Output: DC 6V 2A: North America (NEMA 5-15P)
• Internal Temperature Sensor: -4°F to 185°F /-20°C to 85°C
• Internal Temperature Measurement Accuracy: +/-0.5°F / ±0.3°C
• Internal Humidity Sensor: 0% to 100% (20% to 80%)
• Internal Humidity Sensor Measurement Accuracy: +/-3% (+/-2 )
• Dew Point Measurement Range: -37°C to 75°C +/-2.5°C OR -35°F to 167°F +/-4.5°F (-20°C to 80°C and 20-80%RH)
• Network Connection: Ethernet via RJ45
• Network Protocols Supported and Data Access Formats: HTTP HTTPS (SSL/TLS) SMTP DHCP ICMP TCP/IP HTML (Desktop) SNMP v1/v2c XML CSV JSON
• Reboot Button: Yes
• Remote Sensor RJ Connection Jacks: 2 (Supports up to 4 Sensors)
• Analog Ports: 4 Dry Contact / 0-5VDC
• Output Relays: 1
• Configuration: Zero U or 1U
• Adjustable Mount Brackets: Yes

Certification/ Agency Approvals:

• FCC Part 15 Class A Conformance
• EN 55032
• EN 55024
• CE Marked

Environmental factors like heat humidity and moisture pose a severe threat to mission-critical infrastructure. These dangers can be minimized by incorporating a network of environmental sensors to collect data and alert users of potential threats. Adding optional sensors to a Vertiv Geist Environmental Monitor or Rack Power Distribution Unit (rPDU) allows users to observe conditions from a secure Web interface and receive alerts via Email SNMP or Email-to-SMS.

• Environmental Monitor -Watchdog 100-P
• US Power Supply
