APC by Schneider Electric Smart-UPS X SMX2200RMLV2U 2200 VA Rack-mountable UPS
APC by Schneider Electric Smart-UPS X SMX2200RMLV2U 2200 VA Rack-mountable UPS - 2U Rack-mountable - 3 Hour Recharge - 10 Minute Stand-by - 110 V AC Input - 120 V AC Output - 2 x NEMA 5-20R, 6 x NEMA 5-15R
| $2,032.72 | Retail $2,740.00 |
- Adjustable voltage sensitivity - Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
- Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
- Audible alarms - Provides notification of changing utility power and UPS power conditions
- Auto recognition of external batteries - UPS recognizes when external battery packs are attached and automatically adjusts runtime.
- Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
- Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Battery failure notification - Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Boost and Trim Automatic Voltage Regul
By:
APC by Schneider Electric
Manufacturer:
Schneider Electric Sa
Product ID:
62488
Item:
SMX2200RMLV2U
UPC Code:
643749352063
Our Part #
DX4816
Condition
New
$2,032.72EA
$2,740.00
$2,740.00
Availability
Only 192 Left In Stock
Product description
APC by Schneider Electric Smart-UPS X SMX2200RMLV2U 2200 VA Rack-mountable UPS - 2U Rack-mountable - 3 Hour Recharge - 10 Minute Stand-by - 110 V AC Input - 120 V AC Output - 2 x NEMA 5-20R, 6 x NEMA 5-15R
2U Rack-mountable - 3 Hour Recharge - 10 Minute Stand-by - 110 V AC Input - 120 V AC Output - 2 x NEMA 5-20R, 6 x NEMA 5-15R
Specifications
Load Capacity (VA)
2200 VA
Load Capacity (W)
1980 W
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
2 x NEMA 5-20R
UPC Alternates
643749352063 731304268567 818240257432 854585228751
Waveform Type
Sine Wave
Backup/Run Time (Full Load)
10 Minute
Backup/Run Time (Half Load)
25 Minute
Battery Characteristics
Maintenance-free Sealed Spill-proof
Battery Chemistry
Lead Acid
Brand Name
APC by Schneider Electric
Certifications & Standards
- BSMI
- CSA
- EN 50091-2
- EN 55022 Class A
- FCC Part 15 Class A
- NOM
- TUV
- UL 1778
- VCCI Class A
- UL 1449
Depth
26.3"
Environmental Certification
REACH
Environmental Certification
RoHS
Form factor
Rack-mountable
Height
3.4"
Hot Swappable
Yes
Input voltage
110 V AC
Limited Warranty
3 Year
Load Capacity
2200 VA/1980 W
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SMX2200RMLV2U
Manufacturer Website Address
http://www.schneider-electric.com
Output voltage
120 V AC
Package Contents
Plug/Connector Type
NEMA L5-30P
Product color
Black
Product Family
Smart-UPS X
Product Line
Smart-UPS
Product Name
Smart-UPS X SMX2200RMLV2U 2200 VA Rack-mountable UPS
Product Series
X
Product Type
Line-interactive UPS
Rack Height
2U
Receptacle Type
NEMA 5-15R
Receptacle Type
NEMA 5-20R
Total Number of Expansion Slots
1
Transfer Time
4 ms
Typical Battery Recharge Time
3 Hour
Weight (Approximate)
84.60 lb
Width
17"
