StarTech.com 1 Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - Power over Ethernet Extender - PoE Repeater Network Extender
StarTech.com 1 Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - Power over Ethernet Extender - PoE Repeater Network Extender - Extend your PoE connection 100m or daisy chain up to four extenders for longer distance - 1 Port Gigabit PoE+ Extender 802.3at & 802.3af - 330ft - Power over Ethernet Extender - Network Extender - Compact and Mountable - 24W - Daisy chain up to 500m
| $155.38 | Retail $165.99 |
- Deploy and access your Gigabit PoE-powered devices (PD) further away
- Extend your PoE PDs over longer distances by daisy-chaining four extenders up to 500m (1640ft) total range (reduced power output at each connection)
- Compact, wall-mountable, and rugged metal housing for convenience and reliability
- 2kV ESD and surge protection
- Plug-and-play setup with no power adapter required
- IEEE 802.3at 30W input to IEEE 802.3at/af 24W output
- 52V to 56V output voltage
- Automatically detects your connected PD to prevent damage if incorrectly installed
Manufacturer:
StarTech.com
Product ID:
62535
Item:
POEEXT1GAT
UPC Code:
065030860895
Our Part #
1C4781
Condition
New
$155.38EA
$165.99
$165.99
Availability
Only 209 Left In Stock
You may be also interested
Product description
StarTech.com 1 Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - Power over Ethernet Extender - PoE Repeater Network Extender - Extend your PoE connection 100m or daisy chain up to four extenders for longer distance - 1 Port Gigabit PoE+ Extender 802.3at & 802.3af - 330ft - Power over Ethernet Extender - Network Extender - Compact and Mountable - 24W - Daisy chain up to 500m
Extend your PoE connection 100m or daisy chain up to four extenders for longer distance - 1 Port Gigabit PoE+ Extender 802.3at & 802.3af - 330ft - Power over Ethernet Extender - Network Extender - Compact and Mountable - 24W - Daisy chain up to 500m
Specifications
Input Ports
1 x Gigabit Ethernet
Maximum Extended Range
328.08 ft
Maximum Output Voltage
56 V DC
Output Ports
1 x Gigabit PoE+
Product Material
Steel
Transmitter Weight (Approximate)
6.95 oz
UPC Alternates
065030860895
Additional Information
- Color: Black
- Enclosure Type: Steel
- Input Voltage: 52 ~ 56 DC
- Power Consumption: 3.2 W Max
- Connector Type(s): 2 - RJ-45 Female
- MTBF: 50000 Hours
- Compatible Networks: 10/100/1000 Mbps
- Flow Control: Half-duplex back-pressure IEEE 802.3x pause frame for full-duplex
- Maximum Cable Length: 328 ft [100 m]
Certifications & Standards
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
Compatibility
Compatible Products:
- Wi-Fi Access Points
- IP Phones
- Surveillance Cameras
- Kiosks
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmental Certification
REACH
Environmentally Friendly
Yes
Form factor
Wall Mountable
Height
1"
Length
3.7"
Limited Warranty
2 Year
Manufacturer
StarTech.com
Manufacturer Part Number
POEEXT1GAT
Manufacturer Website Address
http://www.startech.com
Marketing Information
This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances letting you double the 100m limitations of a traditional PoE infrastructure.
Now you can connect your Gigabit PoE device up to a maximum of 200m away so it's easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.
Unrestricted PoE+ range and convenience
Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft) while providing 24-watt power output to compatible devices.
Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you're all set. The extender is compliant with the 802.3at/af standard so it will work with existing PSE such as a StarTech.com PoE+ switch (IES81000POE).
Daisy chain for longer distance and flexibility
Still need more distance? If an extra 100m isn't enough this full-featured PoE extender offers daisy chain capability.
You can easily connect four extenders together letting you install your PoE+ PD up to 500m (1640ft) away. It's perfect for business education and retail environments (output wattage is dependent on the number of daisy-chained extenders used).
Convenient installation options and durable construction
Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it with a wall-mountable design that requires no external power adapter.
You can enjoy reliable performance with little worry of downtime or failure the extender features a rugged metal housing with built-in ESD and surge protection.
The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
- Ideal for Wi-Fi® access points IP phones surveillance cameras and kiosks where a power connection is not available
- Enable remote installation of PoE+ devices over longer distance than conventional PoE range capabilities
- Perfect for SOHO SMB system integrators and IT administrators
Marketing Information
This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances letting you double the 100m limitations of a traditional PoE infrastructure.
Now you can connect your Gigabit PoE device up to a maximum of 200m away so it's easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.
Unrestricted PoE+ range and convenience
Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft) while providing 24-watt power output to compatible devices.
Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you're all set. The extender is compliant with the 802.3at/af standard so it will work with existing PSE such as a StarTech.com PoE+ switch (IES81000POE).
Daisy chain for longer distance and flexibility
Still need more distance? If an extra 100m isn't enough this full-featured PoE extender offers daisy chain capability.
You can easily connect four extenders together letting you install your PoE+ PD up to 500m (1640ft) away. It's perfect for business education and retail environments (output wattage is dependent on the number of daisy-chained extenders used).
Convenient installation options and durable construction
Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it with a wall-mountable design that requires no external power adapter.
You can enjoy reliable performance with little worry of downtime or failure the extender features a rugged metal housing with built-in ESD and surge protection.
The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
- Ideal for Wi-Fi® access points IP phones surveillance cameras and kiosks where a power connection is not available
- Enable remote installation of PoE+ devices over longer distance than conventional PoE range capabilities
- Perfect for SOHO SMB system integrators and IT administrators
Marketing Information
This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances letting you double the 100m limitations of a traditional PoE infrastructure.
Now you can connect your Gigabit PoE device up to a maximum of 200m away so it's easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.
Unrestricted PoE+ range and convenience
Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft) while providing 24-watt power output to compatible devices.
Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you're all set. The extender is compliant with the 802.3at/af standard so it will work with existing PSE such as a StarTech.com PoE+ switch (IES81000POE).
Daisy chain for longer distance and flexibility
Still need more distance? If an extra 100m isn't enough this full-featured PoE extender offers daisy chain capability.
You can easily connect four extenders together letting you install your PoE+ PD up to 500m (1640ft) away. It's perfect for business education and retail environments (output wattage is dependent on the number of daisy-chained extenders used).
Convenient installation options and durable construction
Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it with a wall-mountable design that requires no external power adapter.
You can enjoy reliable performance with little worry of downtime or failure the extender features a rugged metal housing with built-in ESD and surge protection.
The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Marketing Information
This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances letting you double the 100m limitations of a traditional PoE infrastructure.
Now you can connect your Gigabit PoE device up to a maximum of 200m away so it's easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.
Unrestricted PoE+ range and convenience
Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft) while providing 24-watt power output to compatible devices.
Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you're all set. The extender is compliant with the 802.3at/af standard so it will work with existing PSE such as a StarTech.com PoE+ switch (IES81000POE).
Daisy chain for longer distance and flexibility
Still need more distance? If an extra 100m isn't enough this full-featured PoE extender offers daisy chain capability.
You can easily connect four extenders together letting you install your PoE+ PD up to 500m (1640ft) away. It's perfect for business education and retail environments (output wattage is dependent on the number of daisy-chained extenders used).
Convenient installation options and durable construction
Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it with a wall-mountable design that requires no external power adapter.
You can enjoy reliable performance with little worry of downtime or failure the extender features a rugged metal housing with built-in ESD and surge protection.
The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Maximum Output Power
24 W
Minimum Output Voltage
52 V DC
Package Contents
- Network Extender
- Instruction Manual
Package Contents
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft)
- 1 x Instruction Manual
Packaged Quantity
1
Product color
Black
Product Name
1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft)
Product Type
PoE Extender
Product Type
Network Extender
Protection Type
ESD Protection
Protection Type
Surge Protection
Weight (Approximate)
6.81 oz
Width
2.7"
