Tripp Lite PDU Monitored 120V 30A 5-15/20R 16 Outlet L5-30P Horizontal 2URM
Tripp Lite PDU Monitored 120V 30A 5-15/20R 16 Outlet L5-30P Horizontal 2URM - 16 x NEMA 5-15/20R - 2U - Rack-mountable
| $726.66 | Retail $1,059.56 |
- 16 NEMA 5-15/20R outlets with cord retention brackets
- Digital readout monitors current to prevent circuit overload
- Built-in LX Platform network interface reports voltage, frequency and load level
- Temperature, humidity and contact-closure monitoring options
- L5-30P input with 10 ft. (3 m) cord
- 2-year limited warranty
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
63284
Item:
PDUMNH30
UPC Code:
037332157652
Our Part #
GT0816
Condition
New
$726.66EA
$1,059.56
$1,059.56
Availability
Only 65 Left In Stock
Product description
Tripp Lite PDU Monitored 120V 30A 5-15/20R 16 Outlet L5-30P Horizontal 2URM - 16 x NEMA 5-15/20R - 2U - Rack-mountable
16 x NEMA 5-15/20R - 2U - Rack-mountable
Specifications
Receptacle Detail
16 x NEMA 5-15/20R
UPC Alternates
037332157652 818263133881 827969083727
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
12.5"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
3.5"
Input voltage
120 V AC
Limited Warranty
2 Year
Management
Protocols:
- HTTP
- HTTPS
- SMTP
- SNMPv1
- SNMPv2
- Telnet
- FTP
- DHCP
- BOOTP
- NTP
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMNH30
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
2.9kW Single-Phase Monitored PDU with LX Platform Interface
Tripp Lite's PDUMNH30 distributes and monitors single-phase 120V power to connected rack equipment in data centers network closets server rooms computer rooms and other applications requiring network-grade power. Its built-in network interface allows real-time remote monitoring of voltage frequency and load levels to prevent overloads that cause expensive downtime. It features 16 NEMA 5-15/20R outlets and a 10-foot (3-meter) power cord with NEMA L5-30P plug which connects the PDU to a compatible AC power source generator or protected UPS system.
Built-In LX Platform Network Management Interface Card
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities including temperature and humidity conditions. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP. DHCP/Manual configuration lets you assign network settings to the card automatically reducing the need for manual configuration. Automated alerts help prevent accidental overloads power loss and downtime.
Digital Load Meter
The easy-to-read two-character digital LED meter displays output load levels in three segments: breakered bank 1 breakered bank 2 and total PDU output. Monitoring the individual breakered load banks helps ensure proper balance across the two output load banks. Monitoring total PDU output helps prevent PDU and supply circuit overloads that cause downtime.
Optimized for Demanding Applications
The all-metal housing is designed to endure in busy demanding IT and industrial environments. The included cord retention brackets for the outlets help prevent connected equipment from becoming accidentally disconnected. Real-time clock backup maintains the time of day and date even if the PDU is shut down and unpowered.
Versatile Installation Options
This server rack PDU features a 2U horizontal rack-mount form factor. Mounting flanges support installation in 2- and 4-post racks with additional support for wall-mount and under-counter installation. Mounting ears are reversible for front- or rear-facing rack-mount installation.
TAA-Compliant for GSA Schedule Purchases
The PDUMNH30 monitored power distribution unit is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
2-Year Warranty and Environmentally Responsible Design
This monitored PDU comes with a 2-year limited warranty. It's manufactured in compliance with strict RoHS specifications reflecting Tripp Lite's commitment to environmental responsibility.
Tripp Lite's PDUMNH30 distributes and monitors single-phase 120V power to connected rack equipment in data centers network closets server rooms computer rooms and other applications requiring network-grade power. Its built-in network interface allows real-time remote monitoring of voltage frequency and load levels to prevent overloads that cause expensive downtime. It features 16 NEMA 5-15/20R outlets and a 10-foot (3-meter) power cord with NEMA L5-30P plug which connects the PDU to a compatible AC power source generator or protected UPS system.
Built-In LX Platform Network Management Interface Card
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities including temperature and humidity conditions. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP. DHCP/Manual configuration lets you assign network settings to the card automatically reducing the need for manual configuration. Automated alerts help prevent accidental overloads power loss and downtime.
Digital Load Meter
The easy-to-read two-character digital LED meter displays output load levels in three segments: breakered bank 1 breakered bank 2 and total PDU output. Monitoring the individual breakered load banks helps ensure proper balance across the two output load banks. Monitoring total PDU output helps prevent PDU and supply circuit overloads that cause downtime.
Optimized for Demanding Applications
The all-metal housing is designed to endure in busy demanding IT and industrial environments. The included cord retention brackets for the outlets help prevent connected equipment from becoming accidentally disconnected. Real-time clock backup maintains the time of day and date even if the PDU is shut down and unpowered.
Versatile Installation Options
This server rack PDU features a 2U horizontal rack-mount form factor. Mounting flanges support installation in 2- and 4-post racks with additional support for wall-mount and under-counter installation. Mounting ears are reversible for front- or rear-facing rack-mount installation.
TAA-Compliant for GSA Schedule Purchases
The PDUMNH30 monitored power distribution unit is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
2-Year Warranty and Environmentally Responsible Design
This monitored PDU comes with a 2-year limited warranty. It's manufactured in compliance with strict RoHS specifications reflecting Tripp Lite's commitment to environmental responsibility.
Mount Type
Rack-mountable
Package Contents
- Monitored PDUMNH30 16-Outlets PDU
- Plug Retention Plates
- Rack Mounting Brackets
- Owner's Manual
Plug/Connector Type
NEMA L5-30P
Product Name
Monitored PDUMNH30 16-Outlets PDU
Product Series
Monitored
Product Type
PDU
Protection Type
Overload Protection
Rack Height
2U
Receptacle Type
NEMA 5-15/20R
Weight (Approximate)
13.80 lb
Width
17.5"
