C2G 4K HDMI HDBaseT Extender over Cat Transmitter to Box Receiver
C2G 4K HDMI HDBaseT Extender over Cat Transmitter to Box Receiver - 1 Input Device - 1 Output Device - 230 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K UHD - Twisted Pair - Category 7
| $106.87 |
- Extend 4K at 60Hz (4:2:0) up to 130ft and 1080p at 60Hz up to 230ft with Cat 6a cable
- Extend 4K at 60Hz (4:2:0) up to 115ft and 1080p at 60Hz up to 200ft with Cat 5e/6 cable
- HDCP 2.2 compliant, to create a secure connection between the source and display
- Bi-directional PoC, when either transmitter or receiver is plugged into power
Manufacturer:
C2G
Product ID:
63643
Item:
C2G30010
UPC Code:
757120300106
Our Part #
45111815
Condition
New
$106.87EA
Availability
Currently out of stock
Product description
C2G 4K HDMI HDBaseT Extender over Cat Transmitter to Box Receiver - 1 Input Device - 1 Output Device - 230 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K UHD - Twisted Pair - Category 7
1 Input Device - 1 Output Device - 230 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K UHD - Twisted Pair - Category 7
Specifications
UPC Alternates
757120300106
Connectivity technology
Wired
Country of origin
China
Environmental Certification
RoHS 2
Environmentally Friendly
Yes
Frequency
60 Hz
Graphics Modes
4K UHD
Limited Warranty
3 Year
Manufacturer
C2G
Manufacturer Part Number
C2G30010
Manufacturer Website Address
http://www.cablestogo.com
Marketing Information
The HDMI HDBaseT Extender over Cat Box Transmitter to Box Receiver - 4K 60Hz allows a 4K HDMI source to be extended up to 130ft to a 4K display using a single Cat6a Ethernet cable. This is an ideal solution for delivering uncompressed HDMI video and audio to displays in conference rooms classrooms lecture halls and many other installation needs that are far beyond the length limitations of standard HDMI cabling.
This HDMI HDBaseT Extender supports 4K resolutions at 60Hz up to 130ft and 1080p at 60Hz up to 230ft when using a single recommended Cat6a Ethernet cable. Also extend 4K at 60Hz up to 115ft and 1080p at 60Hz up to 200ft when using Cat5e or Cat6 cabling.
This HDMI HDBaseT Extender is HDCP 2.2 compliant making sure that the connection between the source and display is secure. The bi-directional PoC (Power over Cable) function allows both the transmitter and the receiver to be powered on when either side is plugged into power allowing for greater flexibility in installations.
Note: Ensure a solid reliable connection between the 4K HDMI HDBaseT Extender and critical equipment.
Maximum Operating Distance
230 ft
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Package Contents
- 1 x Transmitter Unit
- 1 x Receiver Unit
Product color
Black
Product Name
HDMI HDBaseT Extender over Cat Box Transmitter to Box Receiver - 4K 60Hz
Product Type
Video Extender Transmitter/Receiver
Twisted Pair Cable Standard
Category 7
