Tripp Lite UPS Smart 3000VA 2400W Tower AVR 120V XL DB9 for Servers
Tripp Lite UPS Smart 3000VA 2400W Tower AVR 120V XL DB9 for Servers - 3000VA/2400W - 7 Minute Full Load - 4 x NEMA 5-15R, 4 x NEMA 5-20R
| $1,556.86 | Retail $2,207.08 |
- 3kVA / 3000VA / 2400W line interactive, extended-run tower UPS
- 120V output, Corrects brownouts and overvoltages from 87V to 140V
- 3 DB9 ports (1 RS232 / 2 contact-closure)
- Front panel status LEDs with load and battery capacity display
- 2 independently switchable output load banks
- NEMA L5-30P input; 4 NEMA 5-15/20R & 4 NEMA 5-15R outlets
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
63733
Item:
SMART3000NET
UPC Code:
037332032065
Our Part #
483571
Condition
New
$1,556.86EA
$2,207.08
$2,207.08
Availability
Only 190 Left In Stock
Product description
Tripp Lite UPS Smart 3000VA 2400W Tower AVR 120V XL DB9 for Servers - 3000VA/2400W - 7 Minute Full Load - 4 x NEMA 5-15R, 4 x NEMA 5-20R
3000VA/2400W - 7 Minute Full Load - 4 x NEMA 5-15R, 4 x NEMA 5-20R
Specifications
Load Capacity (VA)
3000 VA
Load Capacity (W)
2400 W
Receptacle Detail
4 x NEMA 5-20R
Receptacle Detail
4 x NEMA 5-15R
UPC Alternates
037332032065 743406374220
Additional Information
- SMART3000NET line interactive UPS offers battery derived AC output during power outages voltage regulation during brownouts and overvoltages plus network-grade AC surge suppression
- 3000VA / 2400 watt power handling capability supports a variety of networking telecom and other sensitive electronic devices
- Large internal batteries offer runtimes of 23 minutes at half load (1500VA / 1200 watts) and 7 minutes at full load (3000VA / 2400 watts)
- Runtime is further expandable with optional external BP24V33 battery packs
- Automatic Voltage Regulation (AVR) circuits maintain 120V nominal output over an input voltage range of 87-140V
- Includes 8 fully protected outlets (4 NEMA 5-15R & 4 NEMA 5-15/20R) with 2 single outlet load banks that can be individually powered off and back on again via software interface
- PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging pager & email notification event logging and running user defined script commands
- Offers simultaneous monitoring of up to 3 directly connected devices through included DB9 contact closure and RS-232 enabled interfaces or the monitoring of any number of additional servers over IP with included PowerAlert monitoring software
- In addition to the contact closure monitoring of on battery low battery and power restored messaging built-in RS-232 interface supports messaging of UPS and line power status including AC line voltage DC battery voltage and remaining battery capacity
- Supports activate self-test and UPS output power control for scheduled or immediate reboot of connected equipment
- Diagnostic LEDs (indicate 17 performance conditions)
- UL (USA) cUL (Canada) NOM (Mexico) FCC Class B (Residential) Listed
- $250000 Ultimate Lifetime Insurance (USA & Canada Only)
Alarm
On Battery
Backup/Run Time (Full Load)
7 Minute
Backup/Run Time (Half Load)
23 Minute
Battery Chemistry
Lead Acid
Battery Chemistry
Sealed Lead Acid (SLA)
Battery life
6 Year
Brand Name
Tripp Lite
Certifications & Standards
UL1778 (USA) cUL (Canada) FCC Class A (emissions) NOM (Mexico) Conforms to IEEE 587 / ANSI C62.41 specifications
Cord Length
8 ft
Country of origin
China
Depth
13"
Form factor
Tower
Height
17"
Input voltage
120 V AC
Limited Warranty
3 Year
Load Capacity
3000 VA/2400 W
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
SMART3000NET
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's SMART3000NET intelligent line interactive large tower UPS system protects servers networking accessories and telecommunications equipment from blackouts voltage fluctuations and transient surges. Large internal batteries offer 23 minutes half load runtime and 7 minutes fully loaded. Runtime is expandable with optional BP24V33 external battery packs. 3000VA / 2400 watt power handling capability supports a variety of networking telecom and other sensitive electronic applications. Includes 8 protected outlets. Supports remote monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port plus standard UPS monitoring via 2 built in contact closure ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Supports SNMP with optional external SNMPWEBSOLO adapter. Built-in audible alarm and front panel LEDs indicate line power battery power battery charge level load level plus voltage regulation status. Network grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges. Attractive large gray tower housing. Two year warranty with $250000 connected equipment insurance.
Maximum Operating Temperature
104°F (40°C)
Network Management
SNMP Manageable
Package Contents
- SmartPro 3000NET UPS
- SMART 3000NET UPS System
- PowerAlert Software and three 6 foot network cables
- Warranty information
- Instruction manual
Plug/Connector Type
NEMA L5-30P
Product Line
SmartPro
Product Name
SmartPro 3000NET UPS
Product Type
Line-interactive UPS
Receptacle Type
NEMA 5-20R
Receptacle Type
NEMA 5-15R
Status Indicators
Includes 5 front panel LEDs to indicate BATTERY CHARGE LEVEL AC LINE POWER STATUS VOLTAGE REGULATION STATUS UPS LOAD LEVEL and BATTERY LOW / REPLACE information
Transfer Time
4 ms
Typical Battery Recharge Time
4 Hour
Weight (Approximate)
80 lb
Width
9"
