StarTech.com Dual M.2 PCIe SSD Adapter Card, x8 / x16 Dual NVMe or AHCI M.2 SSD to PCI Express 4.0, Up to 7.8GBps/Drive, For 2242/2260/2280/22110mm PCIe M-Key M2 SSDs, Bifurcation Required - PC/Linux Compatible
StarTech.com Dual M.2 PCIe SSD Adapter Card, x8 / x16 Dual NVMe or AHCI M.2 SSD to PCI Express 4.0, Up to 7.8GBps/Drive, For 2242/2260/2280/22110mm PCIe M-Key M2 SSDs, Bifurcation Required - PC/Linux Compatible - Dual M.2 PCIe SSD Adapter enables installation of 2x PCIe M.2 SSDs (NVMe/AHCI) through an x8/x16 PCI Express 4.0 slot; Read/write speeds up to 7.8GBps/drive; PCIe Bifurcation support is required; Windows/Linux; Vented full/low-profile brackets incl.
| $78.64 | Retail $100.99 |
- HIGH PERFORMANCE: Install 2x PCIe M.2 SSDs (NVMe or AHCI) into a computer or server through an available x8 or x16 PCI Express 4.0 slot for ultra-fast data access, capable of reaching high performance read and write speeds up to 7.8GBps per drive
- WIDE COMPATIBILITY: This Dual M.2 PCIe SSD adapter card was extensively tested to ensure compatibility with Samsung 980 Pro, 970 EVO, 950 EVO, SM951, and other 2242/2260/2280/22110mm PCIe M-Key M.2 SSDs | Not compatible with SATA based M.2 drives
- BACKWARDS COMPATIBILITY: Compatible with PCIe 3.0 motherboards with PCIe bifurcation and an available x8 or x16 PCIe slot | PCIe bifurcation is required | Works with all workstation and server OS's such as Windows, Windows Server, and Linux
- SOFTWARE RAID FUNCTIONALITY: The M.2 PCI Express adapter enables access to your M.2 PCIe SSDs individually | With OS or 3rd party RAID software, build an array to add redundancy, higher capacity, or performance through RAID 0, RAID
Manufacturer:
StarTech.com
Product ID:
64233
Item:
DUAL-M2-PCIE-CARD-B
UPC Code:
065030895620
Our Part #
06DY60
Condition
New
$78.64EA
$100.99
$100.99
Availability
Only 111 Left In Stock
You may be also interested
Product description
StarTech.com Dual M.2 PCIe SSD Adapter Card, x8 / x16 Dual NVMe or AHCI M.2 SSD to PCI Express 4.0, Up to 7.8GBps/Drive, For 2242/2260/2280/22110mm PCIe M-Key M2 SSDs, Bifurcation Required - PC/Linux Compatible - Dual M.2 PCIe SSD Adapter enables installation of 2x PCIe M.2 SSDs (NVMe/AHCI) through an x8/x16 PCI Express 4.0 slot; Read/write speeds up to 7.8GBps/drive; PCIe Bifurcation support is required; Windows/Linux; Vented full/low-profile brackets incl.
Dual M.2 PCIe SSD Adapter enables installation of 2x PCIe M.2 SSDs (NVMe/AHCI) through an x8/x16 PCI Express 4.0 slot; Read/write speeds up to 7.8GBps/drive; PCIe Bifurcation support is required; Windows/Linux; Vented full/low-profile brackets incl.
Specifications
UPC Alternates
065030895620
Additional Information
Connector(s)
- Drive Connectors: 2 - M.2 (NVMe M-Key PCIe x4)
- Host Connectors: 1 - PCI Express x8
- Operating Temperature: -40°C to 80°C (-40°F to 176°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Humidity: 15 ~ 90% RH
- Interface: M.2 PCIe
- Bus Type: PCI Express
- Number of Drives: 2
- Drive Size: 22 mm - M.2 NVMe
- Compatible Drive Types: M.2 (PCIe NVMe M-Key NGFF)
- Drive Installation: Fixed
- Supported Drive Height(s): 2242; 2260; 2280; 22110
Additional Information
Drive Connectors: 2 - M.2 (NVMe M-Key PCIe x4)
Host Connectors: 1 - PCI Express x8
Interface: M.2 PCIe
Bus Type: PCI Express
Number of Drives: 2
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe NVMe M-Key NGFF)
Drive Installation: Fixed
Supported Drive Height(s):
2242
2260
2280
22110
Certifications & Standards
- CE
- FCC
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Height
0.9"
Length
9"
Limited Warranty
2 Year
Manufacturer
StarTech.com
Manufacturer Part Number
DUAL-M2-PCIE-CARD-B
Manufacturer Website Address
http://www.startech.com
Marketing Information
This Dual M.2 PCIe SSD Adapter adds two high performance PCIe M.2 SSDs (NVMe and AHCI) into the PCIe x8 or x16 slot of a desktop workstation or server.
Boost System Performance
Take full advantage of the fast performance and compact size of PCIe M.2 internal solid-state drives with read and write speeds up to 7.8GBps per drive.
Access two M.2 PCIe SSDs simultaneously
No on-board chip leads to wide system compatibility. This card requires PCIe bifurcation meaning it easily integrates into any system with an available x8 or x16 PCIe slot that supports PCIe bifurcation.
Utilize software RAID such as Storage Spaces (Microsoft) or mdraid/mdadm (Linux) to build a RAID array adding redundancy or enhancing system performance.
Wide Compatibility
The PCIe M.2 NGFF (M Key or B+M Key) adapter supports PCIe NVMe and PCIe AHCI M.2 SSDs including 2242 2260 2280 and 22110mm drives. The PCIe M.2 Adapter Card does not require any software or drivers meaning it works with most operating systems if the computer/motherboard supports bifurcation.
Vented Brackets
The included full and low-profile vented brackets increase air flow to improve heat dissipation which aids in maintaining optimal and reliable operating temperatures.
The DUAL-M2-PCIE-CARD-B is backed for 2-years by StarTech.com including free 24/5 multi-lingual technical assistance
Package Contents
- PCIe to M.2 Adapter Card
- 1 x Low Profile Bracket
- 1 x Quick-Start Guide
- 1 x Set of Mounting Screws
Package Contents
- M.2 to PCI Express Adapter
- 1 x Low Profile Bracket
- 1 x Quick-Start Guide
- 1 x Set of Mounting Screws
Packaged Quantity
1
Product color
Red
Product Name
PCIe to M.2 Adapter Card
Product Type
M.2 NVMe to PCIe Adapter
Product Type
M.2 to PCI Express Adapter
Weight (Approximate)
2.61 oz
Width
4"
