CyberPower OL2200RTXL2U Smart App Online UPS Systems
CyberPower OL2200RTXL2U Smart App Online UPS Systems - 2200VA/1800W, 100 - 125 VAC, NEMA 5-20P, 2U, Rack / Tower, Sine Wave, 7 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
| $1,705.69 | Retail $1,959.00 |
- Capacity: 2200 VA / 1800 W
- Power Factor (PF): 0.82
- Topology: Double-Conversion
- Waveform: Sine Wave
- Output: 100, 110, 115, 120, 125 V ±2% (configurable)
- Plug type & cord: NEMA 5-20P, 10 ft. cord
- Outlet types: 6 � NEMA 5-20R, 1 � L5-20R
- Monitoring & Management: USB, Serial, Network, Relay, EPO
- Data line surge protection: Telephone, Network
- Management software: PowerPanel® Business Edition
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
64557
Item:
OL2200RTXL2U
UPC Code:
649532604623
Our Part #
9GM215
Condition
New
$1,705.69EA
$1,959.00
$1,959.00
Availability
Currently out of stock
Product description
CyberPower OL2200RTXL2U Smart App Online UPS Systems - 2200VA/1800W, 100 - 125 VAC, NEMA 5-20P, 2U, Rack / Tower, Sine Wave, 7 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
2200VA/1800W, 100 - 125 VAC, NEMA 5-20P, 2U, Rack / Tower, Sine Wave, 7 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
Specifications
Directly Connected Equipment Guarantee
$400000Lifetime
Energy Saving
ECO Mode Efficiency >95%
Maximum Operating Elevation
10000 ft
Maximum Storage Elevation
50000 ft
Output Frequency
60 Hz
Overload Protection
Yes
Receptacle Detail
6 x NEMA 5-20R
Receptacle Detail
1 x NEMA L5-20R
Storage Relative Humidity
0% - 95%
Storage Temperature
-4°F (-20°C) - 113°F (45°C)
UPC Alternates
649532604623 649532604883
Waveform Type
Sine Wave
Additional Information
- Replacement Battery Cartridge Quantity: 1
- Smart Battery Management (SBM) Mode: Yes
- Circuit Breaker: 20A
- Cold Start: Yes
- Input Power Factor: 0.99
- Input Voltage Range: 60 VAC - 69 VAC for 0-60% Load
- Crest Factor: 3:1
- ECO Mode Voltage Regulation: ±10% ±15% (Configurable)
- Harmonic Distortion: < 3% at Linear Load
- On Battery Frequency: 50/60 Hz ± 0.25Hz (auto-sensing or configurable)
- Output Power Factor: 0.82
- Overload Protection: Line Mode: 105% ~ 125% Load - 1 min
- Short Circuit Protection: UPS Output Cut Off Immediately or Input Fuse / Circuit Breaker Protection
- VA by Input Type: 2200 (2.2 kVA) at 120 125 V input
- Watts by Input Type: 1800 (1.8 kW) at 120 125 V input
- Phone / Network Protection RJ11/RJ45: 1-In / 1-Out (Combo)
- Dry Contacts: Yes
- Expansion Slot: Yes - with optional RMCARD205 or RELAYIO500
- LCD: Multifunction LCD
- LED Indicators: Power On (White)
- Management Cable: USB Cable
- Removable LCD Control Panel Option: Yes - Requires DB26 cable (not included)
- Rotatable LCD Control Panel Option: Yes
- Serial Port: 1 Serial
- Upgradeable firmware: Yes
- Material of Construction: Metal
- Mounting Hardware: Yes
- ECO Mode Thermal Dissipation: 249 BTU/hr
- Operating Elevation: 0 - 10000 ft (0 - 3048 m)
- Operating Relative Humidity: 0 - 90 % (non-condensing)
- Operating Temperature: 32 - 104 °F (0 - 40 °C)
- Storage Elevation: 0 - 50000 ft (0 - 15239 m)
Alarm
UPS Fault
Alarm
Battery Mode
Alarm
Low Battery
Alarm
Overload
Application/Usage
Mission Critical Equipment
Application/Usage
Network Device
Application/Usage
Storage Device
Application/Usage
Server
Application/Usage
PBX System
Application/Usage
VoIP Device
Backup/Run Time (Full Load)
6.50 Minute
Backup/Run Time (Half Load)
20 Minute
Battery capacity
9000 mAh
Battery Characteristics
Maintenance-free/Sealed
Battery Chemistry
Lead Acid
Battery Size
12V
Brand Name
CyberPower
Certifications & Standards
- UL1778
- CSA C22.2 NO.107.3-05
- FCC DOC Class A
Country of origin
China
Dataline Protection
RJ-11
Dataline Protection
RJ-45
Depth
23.6"
Energy Star
No
Environmental Certification
RoHS
Form factor
Rack/Tower
Height
3.5"
Input frequency
70 Hz
Input voltage
120 V AC
Input Voltage Range
100 V AC - 125 V AC
Limited Warranty
3 Year
Load Capacity
2200 VA
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
OL2200RTXL2U
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
Prevent business interruptions and safeguard mission-critical enterprise network equipment.
The CyberPower OL2200RTXL2U is a rack/tower UPS with double conversion topology. It provides sine wave output to critical applications and equipment that require seamless power correction. The Extended Battery Module (EBM) expands runtime and Fast Charge Technology restores full backup power faster. This model comes with an extendable LCD control panel Smart Battery Management charging technology and energy-saving GreenPower UPS™ ECO Mode.
The OL2200RTXL2U offers generator compatibility and delivers clean AC power with zero transfer time. Its sine wave output keeps sensitive equipment working by preventing unnecessary shutdowns that can occur with simulated sine wave output.
With a $400000 lifetime connected equipment guarantee and a three-year warranty you can trust CyberPower's commitment to high quality.
Maximum Operating Temperature
104°F (40°C)
Network Management
SNMP/HTTP Remote Monitoring
Number of Batteries
6
Output voltage
115 V AC
Output voltage
110 V AC
Output voltage
100 V AC
Output voltage
125 V AC
Package Contents
- Smart App Online OL2200RTXL2U 2200VA 100-125V Sine Wave LCD Rack/Tower UPS
- User Manual
- Registration card
- 2 x Rackmount rails
- 2 x Hanging brackets
- 2 xRackmount ears
- USB communication cable
- Serial interface cable (RS-232)
- 8 x M5X7L black flat head screws
- 12 x M5X12L black pan head screws
- 6 x M5X6L silver pan head screws
- 8 x Plastic washers
- 12 x Screw hole dust covers
- 12 x Rubber pads
- Software download card
Plug/Connector Type
NEMA 5-20P
Product color
Black
Product Name
Smart App Online OL2200RTXL2U 2200VA 100-125V Sine Wave LCD Rack/Tower UPS
Product Series
Smart App Online UPS
Product Type
Dual Conversion Online UPS
Product Type
Double Conversion Online UPS
Rack Height
2U
Receptacle Type
NEMA L5-20R
Receptacle Type
NEMA 5-20R
Software Included
PowerPanel® Business
Status Indicators
- Power On (White)
- Line Mode (Green)
- Battery Mode (Yellow)
- Bypass Mode (Yellow)
- Fault (Red)
- Replace Battery (Red)
Surge energy rating
1335 J
Thermal Dissipation
158.55 W
Transfer Time
0 ns
Typical Battery Recharge Time
4 Hour
Weight (Approximate)
68.20 lb
Width
17"
