CyberPower PDU30MHVT19AT 200 - 240 VAC 30A Metered ATS PDU
CyberPower PDU30MHVT19AT 200 - 240 VAC 30A Metered ATS PDU - 19 Outlets, 10 ft, 2 x NEMA L6-30P, Horizontal, 2U, LCD, 3YR Warranty
| $598.00 | Retail $684.95 |
- 200V - 240V 30A ATS PDU with 16 IEC-320 C13 Outlets, 2 IEC-320 C19 Outlets and 1 NEMA L6-30R Outlet. Dual NEMA L6-30P Input Plugs for Redundancy
- Metered Automatic Transfer Switching (ATS) to provide a redundant input power option
- Digital Display (Load, Voltage, and KW) for on-site monitoring of total PDU load
- SNMP/HTTP option slot for real-time monitoring and event logging of the ATS PDU. RMCARD202 & RMCARD203 sold separately.
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
64579
Item:
PDU30MHVT19AT
UPC Code:
649532610938
Our Part #
9GM198
Condition
New
$598.00EA
$684.95
$684.95
Availability
Only 3 Left In Stock
You may be also interested
Product description
CyberPower PDU30MHVT19AT 200 - 240 VAC 30A Metered ATS PDU - 19 Outlets, 10 ft, 2 x NEMA L6-30P, Horizontal, 2U, LCD, 3YR Warranty
19 Outlets, 10 ft, 2 x NEMA L6-30P, Horizontal, 2U, LCD, 3YR Warranty
Specifications
Mounting Orientation
Horizontal
Number of Cord/Cable
2
PDU Type
Metered
Phase
Single Phase
Plug/Connector Detail
2 x NEMA L6-30P
Receptacle Detail
1 x NEMA L6-30R
Receptacle Detail
16 x IEC 60320 C13
Receptacle Detail
2 x IEC 60320 C19
UPC Alternates
649532610938
Brand Name
CyberPower
Certifications & Standards
- UL60950-1 Certified by ETL (USA)
- CSA C22.2(Canada)
- FCC Class A
Circuit Breaker
Yes
Compatibility
- Data Centers
- Servers
- Network Devices
- Telecom Equipment
- PR5000LCDRTXL5U
- PR6000LCDRTXL5U
- OL6000RT3U
- OL8000RT3U
- OL10000RT3U
- OL6000RT3UTF
- OL8000RT3UTF
- OL10000RT3UTF
Cord Length
10 ft
Country of origin
China
Depth
9.3"
Environmental Certification
RoHS
Height
3.5"
Input current
30 A
Input voltage
230 V AC
Input Voltage Range
200 V AC - 240 V AC
Limited Warranty
3 Year
Management
- HTTP
- TCP/IP
- UDP
- DHCP
- SNMP
- SNMPv3
- IPv4
- IPv6
- NTP
- SMTP
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PDU30MHVT19AT
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
The CyberPower PDU30MHVT19AT a 19-outlet (rear) 2U rackmount metered automatic transfer switch (ATS) power distribution unit (PDU) provides 200-240V 30A output. The PDU distributes unfiltered electrical pass-through from redundant NEMA L6-30P plugs to 19 receptacles: 1 NEMA L6-30R 18 IEC-320 (16) C13 / (2) C19 receptacles. Dual power cords can be plugged into separate power sources to provide redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds or if power fails the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable. The current draw for connected equipment is displayed in amps on the front LCD for real-time load monitoring.
Designed for datacenters and other electrically demanding applications the PDU30MHVT19AT has rugged industrial-grade metal housing and a 10-foot AC power cord. It can be mounted either horizontally or vertically. The PDU30MHVT19AT comes with a cord retention tray and is UL and CSA certified by ETL. A three-year limited warranty covers the PDU for three years and connected equipment for as long as you own the product.
Power DistributionDelivers AC power to servers equipment and connected devices via a power distribution unit.
Automatic Transfer Switch
Dual power cords (A & B) provide redundant power sources to devices with single power supplies and can be plugged into separate compatible sources to ensure continuous access. Users select the preferred source as the primary input. CyberPower Smart App Online and Sinewave series UPS are highly recommended for use as the power source.
Note: Only sine wave AC power sources are compatible with this ATS PDU. Simulated sine wave AC power sources are NOT compatible.
LCD Screen
Provides real-time meter status for current (amperes) input and output voltages power consumptions (kilowatts) and hardware/firmware versions.
Upgradeable Hardware & LCD Firmware
Are updatable to the latest versions by using the serial communication port and included cable.
Serial Communication Port & Cable
Used to update/upgrade the hardware and LCD firmware.
SNMP/HTTP Card Slot
Accepts an RMCARD205 (sold separately) providing remote monitoring reporting and event notifications via Email SMS Text or SNMP Trap.
Protocol Support
With installation of an RMCARD205 (sold separately) the metered ATS PDU provides protocol support for PowerPanel Business Edition HTTP TCP/IP UDP DHCP and SNMP including SNMPv3 IPv4 IPv6 NTP SMTP protocols.
Network-Grade Plugs and Outlets
Highly durable construction ensures the efficient distribution of power in demanding IT or industrial environments to servers equipment and connected devices.
Rackmounting Brackets
Allow for 2U horizontal rack installation.
Cord Retention Tray
Secures power cords keeping them organized and accessible. Helps cords stay plugged in.
Three-Year Limited Warranty
Covers the PDU for three years and connected equipment for as long as you own the product. See warranty for details.
Mount Type
Rack-mountable
Package Contents
- PDU30MHVT19AT 19-Outlets PDU
- 2 x Mounting Brackets
- 24 x (M4x8) Bracket Mounting Screws
- 6 x (M5x12) Rack Mounting Screws
- 6 x Washers
- 2 Cord Retention Tray
- 4 x (M3x4) Cord Retention Tray Mounting Screws
- 30 x Cable Ties
- RJ45/DB9 Serial Port Connection Cable
- User Manual
- Registration Card
- 4 x IEC Socket Power Cord Stand
- 29 x (M3x4) Screws
- 27 x Power Cord Retention Cable Clip
- 27 x Cable Ties
Plug/Connector Type
NEMA L6-30P
Product Name
PDU30MHVT19AT 19-Outlets PDU
Product Series
Metered ATS PDU
Product Type
PDU
Protection Type
Overload Protection
Protection Type
Under Voltage Protection
Protection Type
Over Voltage
Rack Height
2U
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
Receptacle Type
NEMA L6-30R
Weight (Approximate)
15.43 lb
Width
17.1"
