CyberPower PR2200RTXL2UHVAN New Smart App Sinewave UPS Systems
CyberPower PR2200RTXL2UHVAN New Smart App Sinewave UPS Systems - 2200VA/2200W, 120 VAC, NEMA L6-20P, 2U, Rack / Tower, Sine Wave, 6 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
| $1,682.41 | Retail $1,979.95 |
- Capacity: 2200 VA / 2200 W
- Topology: Line Interactive
- Waveform: Sine Wave
- Output: 200-240 VAC ± 5%
- Plug type & cord: NEMA L6-20P, 10 ft. cord
- Outlet types: 4 � NEMA 6-20R; 2 x NEMA L6-20R
- Communication: USB, Serial, SNMP, Relay, EPO
- Management software: PowerPanel® Business Edition
- Remote management: Yes, pre-installed RMCARD205
- Warranty: 3 year
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
64830
Item:
PR2200RTXL2UHVAN
UPC Code:
649532930104
Our Part #
9MF719
Condition
New
$1,682.41EA
$1,979.95
$1,979.95
Availability
Currently out of stock
Product description
CyberPower PR2200RTXL2UHVAN New Smart App Sinewave UPS Systems - 2200VA/2200W, 120 VAC, NEMA L6-20P, 2U, Rack / Tower, Sine Wave, 6 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
2200VA/2200W, 120 VAC, NEMA L6-20P, 2U, Rack / Tower, Sine Wave, 6 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
Specifications
Directly Connected Equipment Guarantee
$400000Lifetime
Energy Saving
GreenPower UPS™ Bypass Technology
Maximum Operating Elevation
9842.52 ft
Maximum Storage Elevation
49212.60 ft
Number of Battery & Surge Outlets
6
Number of Critical Load Outlets
2
Output Frequency
60 Hz
Overload Protection
Yes
Receptacle Detail
2 x NEMA L6-20R
Receptacle Detail
4 x NEMA 6-20R
Sound Emission (A-Weighted)
57.5 dB(A)
Storage Relative Humidity
0% - 95%
Storage Temperature
5°F (-15°C) - 113°F (45°C)
UPC Alternates
649532930104
Waveform Type
Sine Wave
Additional Information
- Active PFC Compatible: Yes
- Extended Battery Option: Yes
- Plug Style: Straight Twist Lock
- Circuit Breaker: 20A
- Automatic Voltage Regulation: Double boost single buck
- Rated Power Factor: 1
- Enclosure Construction: Metal
- Management Cable: USB Cable EPO Cable
- Dry Contacts: Yes
- Internal Circuitry Limiting
- Replacement Battery Cartridge Quantity: 1
- Adjustable Voltage Range: 70 - 155 Vac
- Overload Protection: Internal Circuitry Limiting Circuit Breaker
- Operating Relative Humidity: 0 - 95% (non-condensing)
- Operating Temperature: 32 °F to 104°F (0°C to 40°C)
Alarm
Low Battery
Alarm
Overload
Alarm
Overheat
Alarm
Battery Mode
Alarm
Over Charge
Backup/Run Time (Full Load)
5.30 Minute
Backup/Run Time (Half Load)
15.20 Minute
Battery capacity
6000 mAh
Battery Characteristics
Sealed
Battery Chemistry
Lead Acid
Battery Size
12V
Brand Name
CyberPower
Certifications & Standards
- CE
- UL1778
- FCC Class A
- VCCI
Country of origin
Philippines
Dataline Protection
RJ-45
Depth
24.8"
Environmental Certification
GreenPower UPS
Environmental Certification
RoHS
Form factor
Rack/Tower
Height
3.4"
Input frequency
63 Hz
Input voltage
230 V AC
Input Voltage Range
131 V AC - 302 V AC
Limited Warranty
3 Year
Load Capacity
2200 VA
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PR2200RTXL2UHVAN
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
The PR2200RTXL2UHVAN is a high voltage Smart App Sinewave rack/tower convertible UPS with line-interactive topology surge protection and battery backup. CyberPower's Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment.
The Smart App Sinewave PR2200RTXL2UHVAN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR) which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel captive screws for battery panel access and color-coded rear panel make battery changes and installations simple and fast. The PR2200RTXL2UHVAN also has an innovative LCD panel that rotates 90° tilts for a better viewing angle and provides information on 47 different settings including UPS stats UPS setup and control management and testing options.
This model accepts the BP48VP2U03 Extended Battery Module (EBM) for expanded runtime during power outages and includes pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system.
With a $400000 connected equipment guarantee and a three-year warranty you can trust CyberPower's commitment to the quality of the PR2200RTXL2UHVAN.
Maximum Operating Temperature
104°F (40°C)
Network Management
SNMP/HTTP Remote Monitoring
Number of Batteries
8
Output voltage
240 V AC
Output voltage
220 V AC
Output voltage
208 V AC
Output voltage
200 V AC
Plug/Connector Type
NEMA L6-20P
Product color
Black
Product Condition
New
Product Name
Smart App Sinewave PR2200RTXL2UHVAN 2200VA Rack/Tower UPS
Product Series
New Smart App Sinewave UPS
Product Type
Line-interactive UPS
Rack Height
2U
Receptacle Type
NEMA 6-20R
Receptacle Type
NEMA L6-20R
Software Included
PowerPanel® Business Edition
Sound Emission
57.5 dB(A)
Status Indicators
Multifunction LCD Panel:
- 47 Settings (27 setup and control items + 20 status updates and log menus)
- Power on
- Line mode
- Battery mode
- Fault
- Night mode
Surge energy rating
2430 J
Thermal Dissipation
24.35 W
Transfer Time
4 ms
Typical Battery Recharge Time
3 Hour
Weight (Approximate)
92.59 lb
Width
17.1"
