CyberPower OL3000RTXL2UHVN Smart App Online UPS Systems
CyberPower OL3000RTXL2UHVN Smart App Online UPS Systems - 3000VA/2700W, 200 - 240 VAC, NEMA L6-20P, 2U, Rack / Tower, Sine Wave, 3 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
| $2,642.23 | Retail $3,059.00 |
- Capacity: 3000 VA / 2700 W
- Power Factor (PF): 0.9
- Topology: Double-Conversion
- Waveform: Sine Wave
- Output: 200, 208, 220, 230, 240 V ±2% (configurable)
- Plug type & cord: NEMA L6-20P, 10 ft. cord
- Outlet types: 2 � NEMA L6-20R, 1 � NEMA L6-30R
- Monitoring & Management: USB, Serial, RMCARD205, Relay, EPO
- Data line surge protection: Telephone, Network
- Management software: PowerPanel® Business Edition
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
64939
Item:
OL3000RTXL2UHVN
UPC Code:
649532621934
Our Part #
9MF645
Condition
New
$2,642.23EA
$3,059.00
$3,059.00
Availability
Currently out of stock
You may be also interested
Product description
CyberPower OL3000RTXL2UHVN Smart App Online UPS Systems - 3000VA/2700W, 200 - 240 VAC, NEMA L6-20P, 2U, Rack / Tower, Sine Wave, 3 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
3000VA/2700W, 200 - 240 VAC, NEMA L6-20P, 2U, Rack / Tower, Sine Wave, 3 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty
Specifications
DC System Voltage
12 V DC
Directly Connected Equipment Guarantee
$400000Lifetime
Energy Saving
ECO Mode Efficiency >97%
Maximum Operating Elevation
10000 ft
Maximum Storage Elevation
50000 ft
Operating Humidity
0% - 90%
Output Frequency
60 Hz
Overload Protection
Yes
Receptacle Detail
1 x NEMA L6-30R
Receptacle Detail
2 x NEMA L6-20R
Storage Relative Humidity
0% - 95%
Storage Temperature
-4°F (-20°C) - 113°F (45°C)
UPC Alternates
649532621934
Waveform Type
Sine Wave
Additional Information
- Replacement Battery Cartridge Quantity: 1
- Smart Battery Management (SBM) Mode: Yes
- Circuit Breaker: 20A
- Cold Start: Yes
- Input Power Factor: 0.99
- Crest Factor: 3:1
- ECO Mode Voltage Regulation: ±10% ±15% (Configurable)
- Harmonic Distortion: < 3% at Linear Load
- Nominal Output Voltage: 200 - 240 VAC
- On Battery Frequency: 50/60 Hz ± 0.25Hz (auto-sensing or configurable)
- Output Power Factor: 0.9
- Overload Protection: Line Mode: 105% ~ 125% Load - 1 min
- Short Circuit Protection: UPS Output Cut Off Immediately or Input Fuse / Circuit Breaker Protection
- Phone / Network Protection RJ11/RJ45: 1-In / 1-Out (Combo)
- Dry Contacts: Yes
- Expansion Slot: Yes - RMCARD205 pre-installed
- LCD: Multifunction LCD
- Management Cable: USB Cable
- Removable LCD Control Panel Option: Yes - Requires DB26 cable (not included)
- Rotatable LCD Control Panel Option: Yes
- Upgradeable firmware: Yes
- Material of Construction: Metal
- Mounting Hardware: Yes
- ECO Mode Thermal Dissipation: 207 BTU/hr
Alarm
Low Battery
Alarm
Overload
Alarm
UPS Fault
Alarm
Battery Mode
Application/Usage
Server
Application/Usage
Network Device
Application/Usage
PBX System
Application/Usage
High-end System Component
Application/Usage
Electronic Device
Application/Usage
Lab Equipment
Application/Usage
Edge Computing
Application/Usage
VoIP
Backup/Run Time (Full Load)
3.50 Minute
Backup/Run Time (Half Load)
11 Minute
Battery capacity
9000 mAh
Battery Characteristics
Sealed
Battery Chemistry
Lead Acid
Battery Size
12V
Brand Name
CyberPower
Certifications & Standards
UL 1778
Country of origin
Philippines
Dataline Protection
RJ-45
Dataline Protection
RJ-11
Depth
23.6"
Environmental Certification
RoHS
Form factor
Rack/Tower
Height
3.5"
Input frequency
70 Hz
Input voltage
120 V AC
Input voltage
230 V AC
Input Voltage Range
200 V AC - 240 V AC
Input Voltage Range
120 V AC - 139 V AC
Limited Warranty
3 Year
Load Capacity
3000 VA
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
OL3000RTXL2UHVN
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
Prevent business interruptions and safeguard mission-critical enterprise network equipment.
The CyberPower OL3000RTXL2UHVN is a rack/tower UPS with double conversion topology. It provides sine wave output to critical applications and equipment that require seamless power correction. The Extended Battery Module (EBM) expands runtime and Fast Charge Technology restores full backup power faster. This model comes with an extendable LCD control panel Smart Battery Management charging technology and energy-saving GreenPower UPS™ ECO Mode.
The OL3000RTXL2UHVN offers generator compatibility and delivers clean AC power with zero transfer time. A factory installed RM card allows remote management and configuration of the UPS via a standard web browser command line interface (CLI) or network management system (NMS). Its sine wave output keeps sensitive equipment working by preventing unnecessary shutdowns that can occur with simulated sine wave output.
With a $400000 lifetime connected equipment guarantee and a three-year warranty you can trust CyberPower's commitment to high quality.
Maximum Operating Temperature
104°F (40°C)
Network Management
SNMP/HTTP/CLI Remote Monitoring
Number of Batteries
6
Output voltage
208 V AC
Output voltage
220 V AC
Output voltage
240 V AC
Output voltage
200 V AC
Package Contents
- Smart App Online OL3000RTXL2UHVN 3KVA Rack/Tower UPS
- User Manual
- Registration Card
- 2 x Rackmount Rails
- 2 x Rackmount Ears
- 2 x Hanging Brackets
- Phone Line
- USB Communication Cable
- Serial Interface Cable (RS-232)
- 8 x M5X7L Black Flat Head Screws
- 12 x M5X12L Black Pan Head Screws
- 6 x M5X6L Silver Pan Head Screws
- 8 x Plastic Washers
- 12 x Screw Hole Dust Covers
- 12 x Rubber Pads
- Software Download Card
Plug/Connector Type
NEMA L6-20P
Product color
Black
Product Name
Smart App Online OL3000RTXL2UHVN 3KVA Rack/Tower UPS
Product Series
Smart App Online UPS
Product Type
Dual Conversion Online UPS
Rack Height
2U
Receptacle Type
NEMA L6-20R
Receptacle Type
NEMA L6-30R
Software Included
PowerPanel® Business
Sound Emission
38 dB(A)
Status Indicators
- Power On (white)
- Line Mode (green)
- Battery Mode (yellow)
- Bypass Mode (yellow)
- Fault (red)
- Replace Battery (red)
Surge energy rating
445 J
Thermal Dissipation
231.53 W
Transfer Time
0 ns
Typical Battery Recharge Time
4 Hour
Weight (Approximate)
68.20 lb
Width
17"
