CyberPower PDU20BHVT12R 200 - 230 VAC 20A Basic PDU
CyberPower PDU20BHVT12R 200 - 230 VAC 20A Basic PDU - 12 Outlets, 10 ft, NEMA L6-20P, Horizontal, 1U, 3YR Warranty
| $172.57 | Retail $179.95 |
- Basic PDU
- 12 IEC-320 C13 output receptacles
- 200/230V AC - 50/60Hz - 20-amp electrical capacity with circuit breaker
- 1U Rack Mount - Rugged industrial-grade metal housing
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
65003
Item:
PDU20BHVT12R
UPC Code:
649532901418
Our Part #
9GM185
Condition
New
$172.57EA
$179.95
$179.95
Availability
Only 23 Left In Stock
Product description
CyberPower PDU20BHVT12R 200 - 230 VAC 20A Basic PDU - 12 Outlets, 10 ft, NEMA L6-20P, Horizontal, 1U, 3YR Warranty
12 Outlets, 10 ft, NEMA L6-20P, Horizontal, 1U, 3YR Warranty
Specifications
Mounting Orientation
Vertical
PDU Type
Basic
Phase
Single Phase
Receptacle Detail
12 x IEC 60320 C13
UPC Alternates
649532901418 818239629806
Brand Name
CyberPower
Certifications & Standards
- UL60950_1 certified by ETL
- CSA C22.2
Depth
1.5"
Energy Star
No
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input voltage
230 V AC
Input Voltage Range
200 V AC - 230 V AC
Limited Warranty
Lifetime
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PDU20BHVT12R
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
The CyberPower PDU20BHVT12R a 12-outlet (rear) rackmount basic power distribution unit (PDU) provides 208V/230V 20A output. It distributes power to 12 IEC-320 C13 receptacles from a single NEMA L6-20P twist lock plug with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications the PDU20BHVT12R has rugged industrial-grade metal housing and a 10-foot AC power cord. It can be mounted either horizontally or vertically includes a cord retention tray and is ETL/RoHS certified. A limited lifetime warranty covers defects in materials and workmanship in the product under normal use and conditions.
Power DistributionDelivers AC power to servers equipment and connected devices via a power distribution unit.
Switch-Free Design
Safeguards against accidental power shutdown.
Network-Grade Plugs and Outlets
Highly durable construction ensures the efficient distribution of power in demanding IT or industrial environments to servers equipment and connected devices.
Long Input Power Cord
Reaches distant power sources allowing the PDU to be placed where it's needed.
Twist Lock Plug
Secures an outlet by twisting and locking into place to prevent accidental disconnection.
Cord Retention Tray
Secures power cords keeping them organized and accessible. Helps cords stay plugged in.
Configurable Mounting Brackets
Allow for installation of the PDU in the following configurations: 0U (vertical under counter and wall mount) 1U (horizontal vertical under counter and wall mount) and 2U (horizontal and wall mount).
Durable Metal Housing
Protects internal components and resists damage from impact or abrasions within challenging industrial environments. Also extends the life of the product.
Limited Lifetime Warranty
Covers defects in materials and workmanship in the product under normal use and conditions. See warranty for details.
What's In The Box
PDU Cord Retention Tray User Manual Screw Kit Cord Clip Kit Horizontal Mounting Brackets Vertical Mounting Brackets Product Registration Card
Mount Type
Rack-mountable
Package Contents
- Basic PDU20BHVT12R 12-Outlets PDU
- Cord Retention Tray
- User Manual
- Screw Kit
- Cord Clip Kit
- Horizontal Mounting Brackets
- Vertical Mounting Brackets
- Product Registration Card
Plug/Connector Type
NEMA L6-20P
Product Name
Basic PDU20BHVT12R 12-Outlets PDU
Product Series
Basic PDU
Product Type
PDU
Protection Type
Overload Protection
Rack Height
1U
Receptacle Type
IEC 60320 C13
Weight (Approximate)
3.70 lb
Width
17.5"
