CyberPower OR500LCDRM1U Smart App LCD UPS Systems
CyberPower OR500LCDRM1U Smart App LCD UPS Systems - 500VA/300W, 120 VAC, NEMA 5-15P, 1U, Rackmount, 6 Outlets, LCD, PowerPanel® Business, $300000 CEG, 3YR Warranty
| $212.65 | Retail $219.95 |
- Capacity: 500VA / 300W
- Topology: Line Interactive
- Waveform: Simulated Sine Wave
- Output: 120Vac ± 10%
- Plug type & cord: NEMA 5-15P, 10 ft. cord
- Outlet types: 6 � NEMA 5-15R
- Communication: USB, Relay, SNMP
- Management software: PowerPanel® Business
- Remote management: Yes, with optional RMCARD205
- ENERGY STAR® certified: Yes
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
65096
Item:
OR500LCDRM1U
UPC Code:
163120850990
Our Part #
9GM354
Condition
New
$212.65EA
$219.95
$219.95
Availability
Only 112 Left In Stock
Product description
CyberPower OR500LCDRM1U Smart App LCD UPS Systems - 500VA/300W, 120 VAC, NEMA 5-15P, 1U, Rackmount, 6 Outlets, LCD, PowerPanel® Business, $300000 CEG, 3YR Warranty
500VA/300W, 120 VAC, NEMA 5-15P, 1U, Rackmount, 6 Outlets, LCD, PowerPanel® Business, $300000 CEG, 3YR Warranty
Specifications
Directly Connected Equipment Guarantee
$300000Lifetime
Energy Saving
GreenPower UPS™ Bypass Technology
Maximum Operating Elevation
10000 ft
Maximum Storage Elevation
60"
Number of Battery & Surge Outlets
4
Overload Protection
Yes
Receptacle Detail
6 x NEMA 5-15R
Storage Relative Humidity
0% - 95%
Storage Temperature
5°F (-15°C) - 113°F (45°C)
UPC Alternates
163120850990 649532715015 695975509414 803931039169
Waveform Type
Simulated Sine Wave
Additional Information
- Replacement Battery Cartridge Quantity: 1
- Adjustable Voltage Range: 88 - 144 VAC
- Circuit Breaker: 15A
- Plug Style: Straight
- Automatic Voltage Regulation: Single Boost
- On Battery Frequency: 60 Hz ± 1%
- On Battery Voltage: 120 VAC ± 10%
- Output Power Factor: 0.6
- Overload Protection: Internal Circuitry Limiting
- Network Protection RJ45: 1-in / 1-Out (10/100/1000)
- LCD: Multifunction LCD
- Management Cable: USB Cable
- SNMP / HTTP Remote Monitoring: Yes - with optional RMCARD205
- Material of Construction: Metal
- Operating Relative Humidity: 0 - 95 % (non-condensing)
- Operating Temperature: 32 - 104 °F (0 - 40 °C)
Additional Warranty Information
CyberPower stands behind its products by offering an industry leading 3-year warranty. CyberPower also has a #1 rated technical support team that will assist you with product installation or warranty concerns --- Free of charge.
Alarm
Overload
Alarm
Battery Mode
Alarm
On Battery
Application/Usage
Server
Application/Usage
Network Device
Application/Usage
Workstation
Application/Usage
Telecommunication
Backup/Run Time (Full Load)
3 Minute
Backup/Run Time (Half Load)
12 Minute
Battery capacity
7000 mAh
Battery Characteristics
Maintenance-free
Battery Chemistry
Lead Acid
Battery Chemistry
Sealed Lead Acid (SLA)
Battery Size
6V
Brand Name
CyberPower
Certifications & Standards
- FCC Class B
- cUL 107.1
- UL 1778
Country of origin
Philippines
Dataline Protection
RJ-45
Dataline Protection
RJ-11
Depth
9.3"
Environmental Certification
RoHS
Form factor
Rack-mountable
Height
1.8"
Input frequency
63 Hz
Input voltage
120 V AC
Input Voltage Range
90 V AC - 140 V AC
Limited Warranty
3 Year
Load Capacity
500 VA
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
OR500LCDRM1U
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
A rackmount UPS with line interactive topology the CyberPower Smart App LCD OR500LCDRM1U provides battery backup (using simulated sine wave output) and surge protection for department servers workgroup servers workstations network devices and telecom installations without active PFC power supplies. The OR500LCDRM1U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The OR500LCDRM1U comes with a three-year warranty and a $300000 Connected Equipment Guarantee.
Maximum Operating Temperature
104°F (40°C)
Number of Batteries
2
Package Contents
- Smart App Intelligent LCD OR500LCDRM1U 500VA UPS
- Rack Ears (2)
- User Manual
- Power Management Software
- Warranty Card
- Serial Cable
- Phone Cable
- USB Cable
Plug/Connector Type
NEMA 5-15P
Product color
Black
Product Name
Smart App Intelligent LCD OR500LCDRM1U 500VA UPS
Product Series
Smart App LCD UPS
Product Type
Line-interactive UPS
Protection Type
Sag
Protection Type
Black Out
Protection Type
AC Surge
Protection Type
Dataline Surge
Protection Type
EMI / RFI
Rack Height
1U
Receptacle Type
NEMA 5-15R
Software Included
PowerPanel® Business
Status Indicators
On Unit:
- Power On
- Wiring Fault
LCD Panel:
- Input Voltage
- Output Voltage
- Battery Capacity
- Load Level
- Runtime
- On Battery
- Overload
- Silent Mode
Surge energy rating
1150 J
Transfer Time
8 ms
Typical Battery Recharge Time
8 Hour
Weight (Approximate)
18 lb
Width
17.1"
