StarTech.com MSA Uncoded Compatible 0.5m 10G SFP+ to SFP+ Direct Attach Cable - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Twinax
StarTech.com MSA Uncoded Compatible 0.5m 10G SFP+ to SFP+ Direct Attach Cable - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Twinax - SFP+ Direct-Attach Twinax cable complies w/ MSA industry standards - Copper Twinax Cable length: 0.5 m - Copper SFP+ cables use cost effective copper compared to fiber - SFP cable low power consumption: < 0.1 W - Copper DAC cable is hot-swappable
| $40.62 | Retail $48.99 |
- MSA UNCODED SFP+ CABLE (DAC): 10G direct attach cable works with MSA compliant switches the accept uncoded transceivers and modules
- TECHNICAL SPECS: 0.5m (1.6ft) | 10 Gbps | Passive Twinax (Copper) | 2x SFP+ Pluggable Connector | 100 Ohm Impedance | 30 AWG Wire Gauge | PVC Cable Jacket | Hot swappable | MSA Compliant
- DESIGNED FOR SERVER ROOMS: Mini GBIC DAC is a cost-effective copper alternative to fiber cable inside & between racks. Factory termination means high performance & reliability with less maintenance.
- OUTSTANDING SUPPORT: Backed by StarTech.com for the life of the cable itself, not your equipment; our cables won't void your OEM support and with access to our Tech Advisors 5/24
- WORKS WITH MSA COMPLIANT SWITCHES: Low power 10 GbE DAC also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules and transceivers
- Hot-swappable
Manufacturer:
StarTech.com
Product ID:
65633
Item:
SFP10GPC05M
UPC Code:
065030875011
Our Part #
2NP574
Condition
New
$40.62EA
$48.99
$48.99
Availability
Only 220 Left In Stock
Product description
StarTech.com MSA Uncoded Compatible 0.5m 10G SFP+ to SFP+ Direct Attach Cable - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Twinax - SFP+ Direct-Attach Twinax cable complies w/ MSA industry standards - Copper Twinax Cable length: 0.5 m - Copper SFP+ cables use cost effective copper compared to fiber - SFP cable low power consumption: < 0.1 W - Copper DAC cable is hot-swappable
SFP+ Direct-Attach Twinax cable complies w/ MSA industry standards - Copper Twinax Cable length: 0.5 m - Copper SFP+ cables use cost effective copper compared to fiber - SFP cable low power consumption: < 0.1 W - Copper DAC cable is hot-swappable
Specifications
Connector Gender on First End
Male
Connector on First End Details
1 x SFP+ Network - Male
Connector Type on First End
SFP+ Network - Male
Jacket Material
Polyvinyl Chloride (PVC)
Product Material
Copper
UPC Alternates
065030875011 818214154491 818215047716 993245964179
UPC Alternates
065030875011 818214154491 818215047716 818275310935 993245964179
American Wire Gauge
30 AWG
Cable length
1.64 ft
Cable type
Twinaxial
Color
Black
Connector on First End
1 x SFP+ Male Network
Connector on First End
SFP+ Male Network
Country of origin
Taiwan
Country of origin
China
Data transfer rate
10 Gbit/s
Device Supported
Switch
Device Supported
Transceiver
Device Supported
Network Device
Device Supported
Server
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmental Certification
REACH
Environmentally Friendly
Yes
Features
Hot-swappable
Features
Passive
Limited Warranty
Lifetime
Manufacturer
StarTech.com
Manufacturer Part Number
SFP10GPC05M
Manufacturer Website Address
http://www.startech.com
Marketing Information
The SFP10GPC05M is an MSA compliant direct-attach copper SFP+ cable that's designed programmed and tested to work in 10G network deployments. It delivers dependable 10 GbE connectivity over copper cabling which is a cost-effective alternative to fiber-optic cable setups.
This passive Twinax cable supports 10 Gigabit Ethernet applications connected through SFP+ (Mini-GBIC) ports. The cable is hot-swappable making upgrades and replacements seamless by minimizing network disruptions.
At 0.5 meters long and designed for high-speed performance this copper SFP+ cable is ideal for medium-distance applications such as across-rack network switch or server connections.
StarTech.com SFP CablesAll StarTech.com SFP & SFP+ cables are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of direct-attach SFP Cables and SFP modules providing the convenience and reliability you need to ensure dependable network performance.
Packaged Quantity
1
Product color
Black
Product Name
SFP+ Direct Attach Cable - MSA Compliant - 0.5 m (1.6 ft.)
Product Type
Network Cable
Weight (Approximate)
0.12 lb
