Eaton ATS Rack PDU 1U 200-240V 3.33 kW 2 5ft Cords 16A Single-Phase PDU LCD
Eaton ATS Rack PDU 1U 200-240V 3.33 kW 2 5ft Cords 16A Single-Phase PDU LCD - NEMA L6-20P - 8 x IEC 60320 C13, 1 x IEC 60320 C19 - 120 V AC, 230 V AC - 3330 W - Network (RJ-45) - 1U - Horizontal - Rack-mountable
| $1,040.23 | Retail $1,244.00 |
- Provides power redundancy to equipment with 1 or 2 power supplies
- Automatically transfers power from the primary source to a secondary source if there is an issue with the primary
- Power is transferred back to the primary source when it is automatically restored
- Simplifies monitoring by displaying current, voltage and power source information on intuitive, graphical LCD
- Offers remote monitoring and email alerts with included network card
By:
Eaton
Manufacturer:
Eaton Corporation
Product ID:
67277
Item:
EATS220
UPC Code:
743172079343
Our Part #
2M4720
Condition
New
$1,040.23EA
$1,244.00
$1,244.00
Availability
Only 346 Left In Stock
Product description
Eaton ATS Rack PDU 1U 200-240V 3.33 kW 2 5ft Cords 16A Single-Phase PDU LCD - NEMA L6-20P - 8 x IEC 60320 C13, 1 x IEC 60320 C19 - 120 V AC, 230 V AC - 3330 W - Network (RJ-45) - 1U - Horizontal - Rack-mountable
NEMA L6-20P - 8 x IEC 60320 C13, 1 x IEC 60320 C19 - 120 V AC, 230 V AC - 3330 W - Network (RJ-45) - 1U - Horizontal - Rack-mountable
Specifications
Mounting Orientation
Horizontal
Network (RJ-45)
Yes
Plug/Connector Detail
2 x NEMA L6-20P
Power Rating (Watt)
3330 W
Receptacle Detail
8 x IEC 60320 C13
Receptacle Detail
1 x IEC 60320 C19
UPC Alternates
743172079343
Brand Name
Eaton
Country of origin
China
Depth
9.8"
Height
1.7"
Input current
16 A
Input voltage
230 V AC
Input voltage
120 V AC
Input Voltage Range
120 V AC - 230 V AC
Limited Warranty
3 Year
Manufacturer
Eaton Corporation
Manufacturer Part Number
EATS220
Manufacturer Website Address
http://www.eaton.com
Marketing Information
Eaton eATS ePDUs
Designed for switching non phase synchronized AC power sources the automatic transfer switch ePDUs intelligent circuitry monitors both inputs providing a fast switch transfer from primary to secondary source power critical equipment without interruption. These ePDUs assure the highest level of redundancy to mission critical applications.
Designed for switching non phase synchronized AC power sources the automatic transfer switch ePDUs intelligent circuitry monitors both inputs providing a fast switch transfer from primary to secondary source power critical equipment without interruption. These ePDUs assure the highest level of redundancy to mission critical applications.
Mount Type
Rack-mountable
Plug/Connector Type
NEMA L6-20P
Product Line
eATS
Product Name
eATS 9-Outlet PDU
Product Type
PDU
Rack Height
1U
Receptacle Type
IEC 60320 C19
Receptacle Type
IEC 60320 C13
Weight (Approximate)
7.80 lb
Width
17.3"
