StarTech.com 4-Slot PCIe Expansion Chassis, External PCIe Slots for PC, PCIe 2.0 w/10Gbps Throughput, PCI Express Expansion Box/Adapter
StarTech.com 4-Slot PCIe Expansion Chassis, External PCIe Slots for PC, PCIe 2.0 w/10Gbps Throughput, PCI Express Expansion Box/Adapter - 4-Slot PCIe Expansion Chassis | External PCIe Slots for Desktop/Server | Host Card PCI-e 2.0 x2, 10Gbps, included 6ft (1.8m) USB-C locking cable | For USB, Ethernet/fiber, or Serial/I-O cards | SECC steel enclosure withstands temps up to 140°F
| $528.41 | Retail $623.99 |
- EXPANSION CHASSIS FOR PCIE CARDS: Increase the PCI-e slot count of a desktop computer or server; Add four external PCIe x1 slots; PCI Express 2.0 x2 proprietary USB-C Host Card with locking port; 5.9ft (1.8m) USB-C locking cable included
- RUGGED CONSTRUCTION: PCI Express expansion box is built with SECC steel to withstand harsh conditions and up to 140°F (60°C); Vented chassis for cooling; Quiet operation; Power adapter (12V 3A) included, terminal block port (12-24 VDC) available
- HASSLE FREE UPGRADES: Connect add-on cards (e.g., USB, Ethernet, SFP, Serial, and I/O Cards) to a host system with limited expansion slots; Implement fast deployments and reduce the cost and downtime required to configure an existing or new host system
- COMPATIBILITY: This PCIe expansion chassis is OS independent and requires no additional software; Windows, macOS, and Linux are supported; Installed add-on card may require additional drivers and specific supported OS; No
Manufacturer:
StarTech.com
Product ID:
68230
Item:
4PCIE-PCIE-ENCLOSURE
UPC Code:
065030894630
Our Part #
08HV86
Condition
New
$528.41EA
$623.99
$623.99
Availability
Only 297 Left In Stock
Product description
StarTech.com 4-Slot PCIe Expansion Chassis, External PCIe Slots for PC, PCIe 2.0 w/10Gbps Throughput, PCI Express Expansion Box/Adapter - 4-Slot PCIe Expansion Chassis | External PCIe Slots for Desktop/Server | Host Card PCI-e 2.0 x2, 10Gbps, included 6ft (1.8m) USB-C locking cable | For USB, Ethernet/fiber, or Serial/I-O cards | SECC steel enclosure withstands temps up to 140°F
4-Slot PCIe Expansion Chassis | External PCIe Slots for Desktop/Server | Host Card PCI-e 2.0 x2, 10Gbps, included 6ft (1.8m) USB-C locking cable | For USB, Ethernet/fiber, or Serial/I-O cards | SECC steel enclosure withstands temps up to 140°F
Specifications
Power Plug Type
Type M
Product Material
Steel
UPC Alternates
065030894630
Additional Information
- Power Source: AC Adapter Included and TerminalBlock
- Input Voltage: 100 - 240 AC
- Input Current: 1A
- Output Voltage: 12V DC
- Output Current: 3A
- Center Tip Polarity: Positive
- Plug Type: M
- Power Consumption (In Watts): 36W
Application/Usage
Desktop
Application/Usage
Server
Country of origin
Taiwan
Environmental Certification
WEEE
Environmentally Friendly
Yes
Height
5.6"
Length
5.4"
Limited Warranty
2 Year
Manufacturer
StarTech.com
Manufacturer Part Number
4PCIE-PCIE-ENCLOSURE
Manufacturer Website Address
http://www.startech.com
Marketing Information
The robust expansion chassis supports up to 4 PCIe x1 add-on cards and features up to 10Gbps of total bandwidth. The expansion chassis connects to the host using a proprietary USB-C PCIe x2 adapter card and a locking USB Type-C cable.
External PCIe Expansion Box
The chassis communicates with the desktop computer or server using a host card (PCIe 2.0 x2) in combination with the 5.9ft (1.8m) USB Type-C (USB-C) cable with screw-locks. The included low-profile bracket widens the compatibility as you can install the host card in small form factor (SFF) systems. Features support for PCI-E Advanced Error Reporting (AER) and EndPoint Cyclic Redundancy Check (ECRC). Both of these PCIe features to aid in establishing and maintaining PCIe connections between devices.
The PCI express expansion box does not require drivers to be installed. It's operating system independent; meaning it can be used in Windows Linux or macOS. Note: the expansion cards installed in the chassis may require drivers.
Robust Construction
The expansion chassis is built with SECC galvanized steel enabling it to operate in harsh environments. It features an operating temperature range of 32° to 140°F (0° to 60°C). The vented design of the chassis allows for passive cooling and quiet operation. Secure the enclosure to the desired location using the mounting brackets and included hardware.
Power Options
Power the expansion chassis using the included 12V 3A power adapter or the terminal block port that supports 12 to 24V and 3A.
Applications
There are multiple application scenarios:
- Upgrade or swap cards with ease.
- Test hardware between multiple computers operating systems or with different devices/peripherals.
- Maximize the I/O capabilities of the host system by installing Ethernet or fiber USB serial or parallel PCIe cards.
Avoid costly computer/server upgrades when more expansion slots are unavailable.
The external PCIe slots for desktop is backed for two years including free lifetime 24/5 multi-lingual technical assistance.
Package Contents
- PCIe to PCIe Expansion Chassis
- 1 x PCIe Host Adapter Card
- 1 x 6ft (1.8m) USB Type-C to C Male to Male Cable
- 1 x LowxProfile Bracket
- 1 x Power Adapter
- 1 x Terminal Block Connector
- 2 x Mounting Brackets
- 4 x Mounting Brackets Screws
- 1 x Quick-Start Guide
Packaged Quantity
1
Power source type
Power Adapter
Product color
Black
Product Name
PCIe to PCIe Expansion Chassis
Product Type
Expansion Chassis
Weight (Approximate)
5.10 lb
Width
16.2"
