ATEN HDMI HDBaseT Extender (4K@100m) (HDBaseT Class A)-TAA Compliant
ATEN HDMI HDBaseT Extender (4K@100m) (HDBaseT Class A)-TAA Compliant - 1 Input Device - 1 Output Device - 492.13 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Surface-mountable, Rack-mountable
| $370.26 | Retail $492.00 |
- HDBaseT Connectivity - extends an HDMI connection up to 100m via a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
- Supports HDBaseT Long Reach Mode - up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p
- HDMI (3D, Deep Color, 4K)
- HDCP 2.2 compatible
- Supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD
- Consumer Electronic Control (CEC) allows interconnected HDMI devices to communicate and respond to a single remote control
- Supports wide screen format
- Plug and play - no software required
- Built- in 8KV/ 15 KV ESD protection
- Rack Mountable
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
68808
Item:
VE811
UPC Code:
608631020963
Our Part #
3GQ806
Condition
New
$370.26EA
$492.00
$492.00
Availability
Currently out of stock
Product description
ATEN HDMI HDBaseT Extender (4K@100m) (HDBaseT Class A)-TAA Compliant - 1 Input Device - 1 Output Device - 492.13 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Surface-mountable, Rack-mountable
1 Input Device - 1 Output Device - 492.13 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Surface-mountable, Rack-mountable
Specifications
Transmitter Depth
3.40"
Transmitter Height
0.97"
Transmitter Weight (Approximate)
11.64 oz
Transmitter Width
2.87"
UPC Alternates
608631020963 672792007651 881317517463
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Form factor
Surface-mountable
Graphics Modes
4K
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE811
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The ATEN VE811 HDMI HDBaseT Extender guarantees the optimum HDMI connection up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. The VE811 meets HDMI Specification features including 3D Deep Color HD lossless audio formats and CEC pass-through. It supports Dolby Digital 5.1 DTS HD audio and video signals at resolutions up to 4K. In addition the VE811 supports long reach mode providing an effective means for extending HDMI signals up to 150m over a single Cat 5e/6 cable.
Pushing the technology and design to the limit the compact design makes the VE811 easy to mount in any location. Engineered for today's digital trends the VE811 is ideal for meeting rooms or any setting that requires high quality HDMI video to be extended for great distances.
Maximum Operating Distance
492.13 ft
Maximum Video Resolution
4096 x 2160
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Package Contents
- 1 x VE811T HDMI HDBaseT Transmitter
- 1 x VE811R HDMI HDBaseT Receiver
- 2 x Power Adapters
- 1 x User Instructions
Product Line
VanCryst
Product Name
HDMI HDBaseT Extender (4K@100m) (HDBaseT Class A)
Product Type
Video Extender Transmitter/Receiver
Twisted Pair Cable Standard
Category 6a
