Tripp Lite UPS 900VA 480W Desktop Battery Back Up AVR Compact 120V USB RJ11
Tripp Lite UPS 900VA 480W Desktop Battery Back Up AVR Compact 120V USB RJ11 - Mini Desktop - 4 Hour Recharge - 3 Minute Stand-by - 110 V AC Input - 120 V AC Output - 12 x NEMA 5-15R
| $155.27 | Retail $205.92 |
Manufacturer:
Tripp Lite
Product ID:
7051
Item:
AVR900U
UPC Code:
037332211491
Our Part #
TRPAVR900U
Condition
New
Subscribe & Save 5%
| Ferquency |
$155.27EA
$205.92
$205.92
Availability
Only 2617 Left In Stock
Product description
AVR Series Line-Interactive UPS System offers ultra-compact, line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space saving right-angle input plug, six battery/surge-protected outlets and six additional surge-only outlets (12 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.
Specifications
AVR Range
Boost +18% / Buck -15%
DC System Voltage
12 V DC
Load Capacity (VA)
900 VA
Load Capacity (W)
480 W
Number of Battery & Surge Outlets
6
Output Frequency
60 Hz
Phase
Single Phase
Receptacle Detail
12 x NEMA 5-15R
Storage Temperature
5°F (-15°C) - 113°F (45°C)
UPC Alternates
013297543341 037332139948 037332211491 635665345045 777780080712 997853259696
Waveform Type
Pulse-width Modulated Sine Wave
Additional Information
- Appearance: All black ultra-compact housing
Output voltage regulation:
- Sine wave 120V +14% / -12% (line mode)
- PWM sine wave 115V +/-5% (battery mode)
Output frequency regulation:
- Line Mode: Passes line frequency of 60Hz +/-10%
- Battery Mode: Inverter output regulated to 60Hz +/-0.5Hz
Additional Warranty Information
2 year warranty $100000 Connected equipment guarantee
Alarm
Replace Battery
Alarm
Low Battery
Alarm
Battery Backup
Alarm
Overload
Alarm
Fault
Assembly Required
No
Backup/Run Time (Full Load)
2.70 Minute
Backup/Run Time (Full Load)
3 Minute
Backup/Run Time (Half Load)
10 Minute
Battery Chemistry
Sealed Lead Acid (SLA)
Brand Name
Tripp Lite
Certifications & Standards
- Tested to UL1778 (USA)
- CSA C22.2 No. 107.3 (Canada)
- NOM (Mexico)
- Class B (emissions)
- FCC Part 68 and Industry Canada (telecommunications)
Certifications & Standards
UL Listed Certification
Country of origin
United States
Country of origin
China
Depth
12"
Depth
7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Ultra-compact Desktop/Tower/Wall Mount
Form factor
Mini Desktop
Height
4.1"
Height
4"
Hot Swappable
Yes
Input voltage
120 V AC
Input voltage
110 V AC
Limited Warranty
3 Year
Load Capacity
900 VA/480 W
Manufacturer
Tripp Lite by Eaton
Manufacturer
Tripp Lite
Manufacturer Part Number
AVR900U
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
900VA/480W/120V Battery Backup for PCs Home Theater or Digital Signage The line-interactive AVR900U UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts brownouts overvoltages surges and line noise that can damage valuable electronics or destroy data. The 12-outlet 120V battery backup is ideal protection for your home office media center or commerce components including computers routers printers HDTVs Blu-ray players game consoles ATMs security systems and digital signage equipment. Allows Time to Back Up Critical Files During a Blackout Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load but the line-interactive UPS system should keep an energy-efficient desktop computer with small LCD monitor powered as long as 47 minutes. During normal operation incoming utility power keeps the replaceable internal battery fully charged so backup power will always be available. 12 NEMA 5-15R Outlets Protect Your Connected Components Six 5-15R outlets provide battery backup surge protection and voltage regulation for your computer monitor and other crucial components. The other six 5-15R outlets provide surge suppression only for printers speakers and other desktop equipment regarded as non-essential during a blackout. A high >96% line mode efficiency rating reduces BTU emissions energy consumption and ultimately your energy costs. Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions AVR protects your equipment from incremental hardware damage data loss and performance problems caused by brownouts and overvoltages. The AVR900U can correct brownouts as low as 89V and overvoltages as high as 145V back to nominal 120V power continuously all while keeping the battery fully charged and ready to take over in case of power failure. 316 Joules Fight Back Against Unexpected Power Surges A 316-joule surge suppression rating protects connected components from the harmful effects of power surges. Combats Electromagnetic Interference That Can Harm Equipment Various electromagnetic and radio sources found in virtually every home and business can cause disruptive interference on the AC line. Known as EMI (electromagnetic interference) and RFI (radio frequency interference) this line noise is a common cause of performance problems and can lead to incremental hardware damage data corruption and audio/video transmission problems. The AVR900U incorporates technology that filters out disruptive line noise so that it won't affect your equipment. Home-Friendly Alarm and Diagnostic LEDs Keep You Informed 24/7 The UPS remains silent in both line and battery backup modes. The alarm sounds only to report low battery battery replace overload and fault condition. Dual front-panel LEDs report line and battery mode operation.
Maximum Operating Temperature
104°F (40°C)
Output voltage
110 V AC
Output voltage
115 V AC
Output voltage
120 V AC
Package Contents
- AVR 900VA Desktop UPS
- Owner's manual
Packaged Quantity
1 Each
Plug/Connector Type
NEMA 5-15P
Product Name
AVR Series 900VA Mini Desktop UPS
Product Name
AVR 900VA Desktop UPS
Product Series
AVR
Product Type
Line-interactive UPS
Receptacle Type
NEMA 5-15R
Receptacles
12 x NEMA 5-15R
Recycled
No
Software Included
PowerAlert Software
Software Included
Status Indicators
2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low overload replace-battery and fault conditions
Surge energy rating
316 J
Transfer Time
4 ms
Transfer Time
6 ms
Typical Battery Recharge Time
8 Hour
Typical Battery Recharge Time
4 Hour
Weight (Approximate)
15.30 lb
Weight (Approximate)
16.50 lb
Width
7.5"
Width
12"
