Chief ConnexSys LVS1U Wall Mount for Flat Panel Display - Black
Chief ConnexSys LVS1U Wall Mount for Flat Panel Display - Black - Adjustable Height - 1 Display(s) Supported - 42" to 80" Screen Support - 150 lb Load Capacity
| $789.01 | Retail $1,035.00 |
- Sustains a maximum load capacity of 150 lb
- Compatible with the screen size of 80"
- Suits displays with 200 x 100 mounting hole pattern
By:
Chief
Manufacturer:
Legrand Group
Product ID:
72094
Item:
LVS1U
UPC Code:
012300174305
Our Part #
UU8168
Condition
New
$789.01EA
$1,035.00
$1,035.00
Availability
Only 21 Left In Stock
Product description
Chief ConnexSys LVS1U Wall Mount for Flat Panel Display - Black - Adjustable Height - 1 Display(s) Supported - 42" to 80" Screen Support - 150 lb Load Capacity
Adjustable Height - 1 Display(s) Supported - 42" to 80" Screen Support - 150 lb Load Capacity
Specifications
UPC Alternates
012300174305 638317179012 841872161150
VESA Mount Standard
200 x 100
VESA Mount Standard
700 x 400
Additional Information
SPEED
- Hang units on a single strut channel for quick row leveling
- No need for horizontal spacers
- Vertical measurement is simply the height of the display to the next rail
- Compatible with most 1-5/8" sizes of channel strut
- Reduces installation time - especially for XL and recessed configurations
- Tool-free ClickConnect™ latching secures displays
- PowerZone™ provides 6 points of adjustment in one easy-to-access location at the top of the mount
ALIGNMENT
- PowerZone™ Adjustments
- Height adjustment ±1" on each interface
- Tilt adjustment at single pivot point protects displays from twisting
- Depth can be set between 4" and 7.4" from the wall providing a range of "home positions" ideal for recessed installations
- Both sides adjust independently compensating for imperfections in the wall
- Walls can be out of alignment by up to 2" (horizontally)
- 3 levels of lateral adjustment
- Mount left/right along rail
- Interface left/right along mount
- Lock in lateral guide for fine-tune adjustment using turn knobs protecting screens from potential collisions
SERVICEABILITY
- RapidDraw™ Display Release
- Cord release system gently and remotely pops any screen out for easy access and can be extended 13.4" for service
- Protects displays by not requiring an aggressive push to release/pop-out
- Releases only on demand preventing accidental pop-outs
- Cord can be set up to pull for release from any 90 degree angle
- Kickstand provides 20 degrees of bottom tilt access
RIGIDITY
- Rigid frame keeps displays where you set them even after extending for service
- Adjustable home depth position locks screens in place to maintain alignment despite accidental bumps/pushes
Adjustable Height
Yes
Brand Name
Chief
Country of origin
China
Depth
4"
Device Supported
Flat Panel Display
Features
Adjustable Depth
Features
Leveling System
Features
Tilt
Features
Lateral Adjustment
Features
Lockable
Height
21.8"
Limited Warranty
10 Year
Manufacturer
Legrand Group
Manufacturer Part Number
LVS1U
Manufacturer Website Address
http://www.legrand.us
Marketing Information
Chief's ConnexSys Video Wall Mounting System solves common video wall challenges of speed alignment serviceability and rigidity. The ConnexSys Video Wall Mounting System provides the ability to level each row once by using strut channel to connect multiple mounts together with a simple-to-install system that can handle the largest requirements
Maximum Adjustable Depth
7.40"
Maximum Adjustable Height
1"
Maximum Adjustable Width
13.40"
Maximum Load Capacity
150 lb
Maximum Screen Size Supported
80"
Minimum Screen Size Supported
42"
Number of Displays Supported
1
Product color
Black
Product Line
ConnexSys
Product Name
ConnexSys Video Wall Landscape Mounting System with Rails
Product Type
Wall Mount
Width
35.5"
