Asus HYPER M.2 X16 CARD V2

• Interface: PCI Express 3.0 x16 interface compatible with PCI Express x8 and x16 slots support data transfer rates up to 128 Gbps.
• External Connectors: 4 x M.2 Socket 3 with M Key design type 2242/2260/2280/22110 storage devices support(Support PCIE SSD only)
• LED & Button: 1 x M.2 FAN Power Switch 4 x M.2 access LEDs

ASUS Hyper M.2 x16 PCIe 3.0 x4 Expansion Card V2 supports 4 NVMe M.2 (2242/2260/2280/22110) up to 128 Gbps for Intel VROC and AMD Ryzen Threadripper NVMe RAID

• Intel® VROC ready and NVMe RAID support on AMD Ryzen™ Threadripper™
• New two-phase power solution with up to 14W output
• Supports four additional NVMe M.2 drives using Intel® VROC for transfer speeds up to 128Gbps
• PCI Express 3.0 x16 interface compatible with PCI Express x8 and x16 slots
• Stylish heatsink and integrated blower style fan prevent M.2 throttling

RAID on CPU

Hyper M.2 x 16 card V2 is compatible with Intel® Virtual RAID on CPU (VROC) and the AMD Ryzen™ Threadripper™ platform for NVMe RAID support. Unused CPU PCle® lanes can be assigned to storage allowing you to create a bootable RAID array with multiple M.2 SSDs.

Design for unthrottled transfer speed

The ASUS Hyper M.2 x16 V2 card provides four M.2 slots to let you expand your system with high-performance SSD storage. Designed for the latest generation of NVMe drives the card features an upgraded power supply that provides up to 14W of power per drive as well as a large heatsink and active fan to ensure drives stay cool for optimum performance.

One card
4X the bandwidth

Hyper M.2 x16 is designed specifically for Intel® Virtual RAID on CPU (VROC) and the AMD Ryzen™ Threadripper™ platform for NVMe RAID support and features four M.2 slots providing up to 128 Gbps of bandwidth per card.
