Tripp Lite 8-Port HDMI Splitter - HDMI 2.0, 4K x 2K@60 Hz, HDCP 2.2, EDID Management

• LED Indicators: (x1) Amber (Power); (x8) Blue (Signal)
• Material of Construction: Metal
• Rackmountable
• Max Supported Video Resolution: 4096 x 2160 @60Hz
• HDMI Specification: 2.0
• HDCP Specification: 2.2
• Audio Specification: DTS-HD Dolby® TrueHD Dolby Digital Plus™ and LPCM 7.1 Channel Surround Sound
• Max Supported Color Depth: 36-bit Deep Color
• EDID Compatible

• UL
• cUL
• NEMA
• FCC

Splitter with EDID management transmits 4K x 2K video and audio from an HDMI source to eight HDMI displays at the same time.

HDMI Splitter Transmits 4K Video + Audio to 8 HDMI Displays at the Same Time
Recommended for home theaters or short-distance digital signage applications in classrooms showrooms offices churches restaurants bars hotels and trade shows this Ultra High Definition (UHD) HDMI splitter is quick and easy to install. It connects to an HDMI source device such as a computer or Blu-ray player and transmits a 4K audio/video signal to eight HDMI monitors projectors or televisions simultaneously. You can cascade up to three levels of splitters which expands the total number of connected displays to 512.Note: The B118-008E-UHD-2 is an HDMI Splitter it sends the same image to all connected displays. If you would like to extend an image over multiple displays you will need an MST hub like the B156-002-HD-V2.

Supports UHD 4K x 2K Signals up to 15 ft. via HDMI Cabling
Using standard 28 AWG HDMI cable the B118-008E-UHD-2 distributes a 4K x 2K audio/video signal (at 60 Hz) up to 15 feet (4 meters). Be sure the HDMI cables connecting the splitter to the source and displays are no longer than 15 feet. For best performance we recommend using Tripp Lite's P569-Series Premium High-Speed HDMI cables.

Supports Up-To-Date Features and Formats
The B118-008E-UHD-2 supports a wide range of audio formats including DTS-HD Dolby TrueHD Dolby Digital Plus and LPCM 7.1-channel surround sound. It also features lip sync pass-through 36-bit Deep Color xvYCC and x.vColor while receiving and transmitting up to 18 Gbps of bandwidth with no data loss. To ensure compatibility with the latest hardware this splitter is compliant with HDCP 2.2 3D and HDMI 2.0 standards.

User-Adjustable EDID Settings Gives You Control over A/V Resolutions
EDID (Extended Display Identification Data) allows the source device to identify the capabilities of each connected display and transmit to the highest video and audio resolutions shared by all displays. The B118-008E-UHD-2's default EDID setting uses the lowest level of video format shared by the displays (for instance if two monitors support 4K video and one supports 1080p all three monitors will show 1080p). In the event you want to override the automatic detection setting and control the audio/video output yourself you may do so by adjusting the built-in DIP switches.

Ready to Use Right Out of the Package
The plug-and-play B118-008E-UHD-2 requires no additional software or drivers. Connect your devices to the HDMI ports with user-supplied HDMI cables (such as Tripp Lite's P569-Series) and plug the included external power supply into an AC power source to get started. An amber LED indicates the unit is receiving power and blue LEDs indicate connected HDMI inputs. Use the included hardware to install the unit on a desktop or mount it to a wall.

• 8-Port HDMI Splitter - HDMI 2.0 4K x 2K@60 Hz HDCP 2.2 EDID Management
• External power supply with 5 ft. cord & NEMA 1-15P plug (Input: 100-240V 50/60 Hz 0.6A; Output: 12V 2A)
• Mounting hardware
• Owner's manual
