Tripp Lite PDU ATS / Metered 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM
Tripp Lite PDU ATS / Metered 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM - Metered Auto Transfer Switch - NEMA 5-20P, NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Horizontal - Rack-mountable, Wall-mountable - TAA Compliant
| $495.54 | Retail $741.32 |
- 16 NEMA 5-15/20R 120V outlets distribute AC power to connected equipment
- Digital ammeter for on-site real-time load monitoring helps prevent power overloads
- Dual 12 ft. cords with NEMA L5-20P inputs connect to separate power sources
- Installs in 1U of space in EIA-standard 19 in. racks using included mounting brackets
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 2-year limited warranty
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
73059
Item:
PDUMH20ATS
UPC Code:
037332261373
Our Part #
9HC107
Condition
New
$495.54EA
$741.32
$741.32
Availability
Only 13 Left In Stock
Product description
Tripp Lite PDU ATS / Metered 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM - Metered Auto Transfer Switch - NEMA 5-20P, NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Horizontal - Rack-mountable, Wall-mountable - TAA Compliant
Metered Auto Transfer Switch - NEMA 5-20P, NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Horizontal - Rack-mountable, Wall-mountable - TAA Compliant
Specifications
Mounting Orientation
Horizontal
PDU Type
Metered Auto Transfer Switch
Phase
Single Phase
Plug/Connector Detail
2 x NEMA 5-20P
Plug/Connector Detail
2 x NEMA L5-20P
Power Rating (Watt)
2030 W
Receptacle Detail
16 x NEMA 5-15/20R
UPC Alternates
037332261373
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
14.5"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input current
20 A
Input voltage
120 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMH20ATS
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Single-Phase 20A ATS PDU Distributes and Monitors Network-Grade Power in Real Time
This metered PDU provides real-time local reporting of the total load level via its built-in digital current metering. Ideal for network IT applications small computer rooms and other equipment rack applications the PDUMH20ATS features 16 NEMA 5-15/20R 120V outlets for connecting equipment. Dual 12-foot (3.7-meter) power cords with NEMA L5-20P inputs (two 5-20P adapters are included) connect to separate primary and secondary mains circuits backup generators UPS systems or utility power grids including out-of-phase sources.
Switches from Primary to Secondary Power Source in Milliseconds
Automatic transfer switching (ATS) allows the PDU to switch to the secondary source within 2-7 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption. An on-board ATS processor constantly evaluates the power quality of both input sources. It prevents switching if the secondary source is unavailable or of lower quality than the primary source.
Digital Load Meter Helps Prevent Potentially Expensive Overloads
A digital ammeter reports the total load for all connected equipment. Monitoring amperage helps ensure load levels remain well below maximum capacity with no danger of overload that could lead to costly downtime or damaged equipment. Maintaining proper load levels even while adding new equipment can keep your TCO (total cost of ownership) low.
Mounts into 1U of Rack Space or on a Wall
Use the included mounting hardware to install the all-metal housing into 1U of space in an EIA-standard 19-inch rack. You may also use the mounting brackets to secure the PDU to a wall or under a counter.
TAA-Compliant for GSA Schedule Purchases
The PDUMH20ATS is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Mount Type
Rack-mountable
Mount Type
Wall-mountable
Output voltage
127 V AC
Output voltage
100 V AC
Package Contents
- 16-Outlets PDU
- Detachable C19 To NEMA L5-20P Secondary Input Cord 12 Ft. (3.7 m)
- 2 x L5-20R To 5-20P Plug Adapters
- Cable Retention Kit
- Rack-Mounting Hardware
- Owner's Manual
Plug/Connector Type
NEMA 5-20P
Plug/Connector Type
NEMA L5-20P
Product Name
16-Outlets PDU
Product Type
PDU
Protection Type
Circuit Protection
Rack Height
1U
Receptacle Type
NEMA 5-15/20R
Weight (Approximate)
12.20 lb
Width
17.5"
