CyberPower Switched ATS PDU PDU44001 10-Outlets PDU
CyberPower Switched ATS PDU PDU44001 10-Outlets PDU - Switched - NEMA 5-15P - 10 x NEMA 5-15R - 120 V AC - Network (RJ-45) - 1U - Horizontal - Rack-mountable
| $636.95 | Retail $850.00 |
- Automated notifications: Email, SMS Text, and SNMP Trap
- Phase: Single
- Amps: 15A (Derated to 12A)
- Volts: 100-120V
- Frequency: 50/60Hz
- Plug type: 2 x NEMA 5-15P
- Outlets: 10 x NEMA 5-15R
- Size: 1U Rackmount
- Warranty: 3 year
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
73103
Item:
PDU44001
UPC Code:
649532933877
Our Part #
01FL30
Condition
New
$636.95EA
$850.00
$850.00
Availability
Only 12 Left In Stock
You may be also interested
Product description
CyberPower Switched ATS PDU PDU44001 10-Outlets PDU - Switched - NEMA 5-15P - 10 x NEMA 5-15R - 120 V AC - Network (RJ-45) - 1U - Horizontal - Rack-mountable
Switched - NEMA 5-15P - 10 x NEMA 5-15R - 120 V AC - Network (RJ-45) - 1U - Horizontal - Rack-mountable
Specifications
Mounting Orientation
Horizontal
PDU Type
Switched
Phase
Single Phase
Plug/Connector Detail
2 x NEMA 5-15P
Receptacle Detail
10 x NEMA 5-15R
UPC Alternates
649532933877
Additional Information
- Shipping - Dimensions (WxHxD in) : 21.65 x 4.9 x 15.67 (in)
- Shipping - Weight (lb) : 13.3
- Cord Length : 10 ft (3.0 m)
- Derated Input Current : 12 A
- Input Frequency Range : 50 Hz - 60 Hz
- Plug Style : Straight
- Overload Protection : None
- Power Source Transfer Time : 2-7 ms
- Source Failure Detection Time : 2-3 ms
- Total Transfer Time : <10 ms
- Environmental Sensor : Optional via RJ45
- LCD : Multifunction LCD
- LED Indicators : Source Status
- Upgradeable firmware : Yes
- Cord Retention Tray/Cord Organizers : Yes
- External Site Ground Pin : Yes
- Material of Construction : Metal
- Operating Elevation : 0 - 13123 ft (0 - 4000 m)
- Operating Relative Humidity : 0 - 95 % (non-condensing)
- Operating Temperature : 32 - 113 °F (0 - 45 °C)
- Storage Elevation : 0 - 49213 ft (0 - 14999 m)
- Storage Temperature : 5 - 131 °F (-15 - 55 °C)
Brand Name
CyberPower
Certifications & Standards
- UL62368
- FCC Class A
- cTUVus
Country of origin
China
Depth
8.5"
Design
Modular
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input current
15 A
Input voltage
120 V AC
Input Voltage Range
100 V AC - 120 V AC
Limited Warranty
3 Year
Management
- IPv4
- TCP/IP
- UDP
- SNMPv1
- HTTP
- NTP
- DNS
- Telnet
- DHCP
- SMTP
- FTP
- IPv6
- SNMPv3
- HTTPs
- SSH
- SSL
- TLS
- LDAP(S)
- RADIUS
- Syslog
- CLI
- Windows AD
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PDU44001
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
Ensure continued operation of critical devices with the CyberPower PDU44001 Switched ATS PDU. Ideal for data centers and network closets this unit provides power redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds or if power fails the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable. Additionally this unit offers real time remote and local monitoring and outlet management.
The PDU44001 supports inputs between 100-120V and includes (10) NEMA 5-15R outlets. Dual NEMA 5-15P power cords are plugged into separate power sources (A and B) and information about each power source is clearly displayed on the front panel LED indicator lights. Other features include an LCD with selectable background color built-in web interface and power event notifications. The CyberPower PDU44001 is protected by a three-year limited warranty.
Mount Type
Rack-mountable
Plug/Connector Type
NEMA 5-15P
Product color
Black
Product Name
Switched ATS PDU PDU44001 10-Outlets PDU
Product Series
Switched ATS PDU
Product Type
PDU
Rack Height
1U
Receptacle Type
NEMA 5-15R
Weight (Approximate)
10.01 lb
Width
17.1"
