StarTech.com Industrial 5 Port Gigabit PoE Switch 30W - Power Over Ethernet Switch - GbE POE+ Network Switch - Unmanaged - IP-30
StarTech.com Industrial 5 Port Gigabit PoE Switch 30W - Power Over Ethernet Switch - GbE POE+ Network Switch - Unmanaged - IP-30 - 5 Port Gigabit PoE switch 30W PSE power per port to devices w/GbE on Cat5e/6 - Power over Ethernet Network IEEE 802.3af/at |10/100/1000 Mbps |Unmanaged |Alarm Relay |DIN/Wall Mount |Redundant Power Input IP-30 /Industrial Hardened -40C to 75C temp
| $263.28 |
- POWER OVER ETHERNET: Gigabit PoE Switch provides up to 30W of PSE power per PoE port to IEEE 802.3af (PoE) & IEEE 802.3at (PoE+) | Use with devices like cameras & access points using Cat 5e/6
- FLEXIBLE POWER INPUT: Power over Ethernet network switch can be hardwired using terminal block (48-56VDC) power or powered using a standard (48-56VDC) Type-N barrel wall adapter (not included)
- ROBUST DESIGN: Industrial Network Switch w/MTBF 500,000+hrs @ 50C | Vibration, shock & free fall rated | Rugged industrial IP-30 aluminum housing | -40C to 75C hardened operating temp | DIN/Wall Mount
- TECH SPECS: 5 Port GbE Switch | 4 PoE ports | IEEE 802.3af / IEEE 802.3at | 10/100/1000 Mbps | Unmanaged | Redundant Power Input | Terminal Block Power | Total power budget: 120W
- STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years | This Gigabit PoE switch is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech
Manufacturer:
StarTech.com
Product ID:
73623
Item:
IESC1G50UP
UPC Code:
065030889629
Our Part #
8NT066
Condition
New
$263.28EA
Availability
Only 4 Left In Stock
Product description
StarTech.com Industrial 5 Port Gigabit PoE Switch 30W - Power Over Ethernet Switch - GbE POE+ Network Switch - Unmanaged - IP-30 - 5 Port Gigabit PoE switch 30W PSE power per port to devices w/GbE on Cat5e/6 - Power over Ethernet Network IEEE 802.3af/at |10/100/1000 Mbps |Unmanaged |Alarm Relay |DIN/Wall Mount |Redundant Power Input IP-30 /Industrial Hardened -40C to 75C temp
5 Port Gigabit PoE switch 30W PSE power per port to devices w/GbE on Cat5e/6 - Power over Ethernet Network IEEE 802.3af/at |10/100/1000 Mbps |Unmanaged |Alarm Relay |DIN/Wall Mount |Redundant Power Input IP-30 /Industrial Hardened -40C to 75C temp
Specifications
PoE Budget
120 W
Product Material
Steel
Total Number of Network Ports
5
UPC Alternates
065030889629
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Form factor
DIN Rail Mountable
Form factor
Wall Mountable
Height
1.3"
Layer Supported
2
Length
4.1"
Limited Warranty
2 Year
Manageable
No
Manufacturer
StarTech.com
Manufacturer Part Number
IESC1G50UP
Manufacturer Website Address
http://www.startech.com
Marketing Information
This industrial 5 port gigabit PoE switch ( 4-port PoE) features 30W of power and is designed to be installed in harsh environments and supports up to a total of 120W power outputs.
For Demanding Environments Where No Fiber Connections Are RequiredUsing Cat 5e (or higher rated) Ethernet cabling this Ethernet switch Provides up to 30W of PSE power per PoE port (PSE) to IEEE 802.3af (PoE / Type 1) and IEEE 802.3at (PoE+ / Type 2) PD devices like:
- Cameras
- Sensors
- Wi-Fi Access Points
High total power budget with high PoE port count at a maximum of 30 watts per port up to 120 watts max. Power provided in order of device connection; max four 802.3at (30W) devices (120W total) at any time.
Truly Industrial for Devices That Must Function Under Harsh ConditionsIndustrial features include:
- Operating Temperature Range: -40 C to 75 C
- IP-30 rated housing
- Vibration shock and free-fall standard testing
This Ethernet switch supports additional features such as redundant power inputs 2kV surge protection on RJ45 ports and an MTBF of 600000+ hrs (Telcordia/Bellcore ) at 50°C for long-term reliability.
A Flexible & Easy-to-Deploy SolutionIncludes hardware for DIN rail or wall mounting right out of the box. The unique barrel power adapter allows for standard wall adapters to be used instead of being hardwired and the alarm relay can be integrated into any solution.
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-T
Networking standards
IEEE 802.3x
Networking standards
IEEE 802.3at
Networking standards
IEEE 802.3
Package Contents
- Ethernet Switch
- Mounting Hardware Kit
- Quick-Start Guide
- Terminal Block
Plug/Connector Type
Terminal Block
Port/Expansion Slot Details
1 x Gigabit Ethernet Network
Port/Expansion Slot Details
4 x Gigabit Ethernet PoE+
Power consumption
126 W
Power source
PoE+
Product Type
Ethernet Switch
Weight (Approximate)
5.30 oz
Width
3.2"
