dbx ZC2 Wall-Mounted Zone Controller
dbx ZC2 Wall-Mounted Zone Controller
| $58.27 | Retail $80.76 |
- Programmable Volume Control
- Program or Scene Selection
- Programmable Contact Closure Interface
- Up to 1000 ft. on CAT 5 Cable
- Programmable Push-To-Talk Paging
- Programmable Source Selection
By:
dbx
Manufacturer:
Harman International Industries, Inc
Product ID:
73989
Item:
DBXZC2V
Our Part #
6VB454
Condition
New
$58.27EA
$80.76
$80.76
Availability
Only 3 Left In Stock
You may be also interested
Product description
dbx ZC2 Wall-Mounted Zone Controller
Specifications
Additional Information
Connectors
(2) RJ-45
Series Wiring
Maximum Cable Length varies with number of Zone Controllers. For ExampleThree Zone Controllers: 600 ft. Six Zone Controllers: 300 ft.
Parallel Wiring using ZC-BOB
Up to Six Zone Controllers: 1000 ft.
Parallel Wiring Cable
CAT5 or CAT5E with 28.6 Ohm/M (Ohm/1000ft.) nominal DCR and rated VW-1 or higher.
Safety Agency Certifications
UL 60065 IEC 60065 EN 55013 E60065
Brand Name
dbx
Compatibility
- dbx DriveRack 260 220i
- dbx ZonePRO Devices
Form factor
Wall Mountable
Manufacturer
Harman International Industries Inc
Manufacturer Part Number
DBXZC2V
Manufacturer Website Address
http://www.harman.com
Marketing Information
The Zone Controllers offer extended utility to the DriveRack® and ZonePRO™ families. The nine Zone Controllers use analog DC voltage to provide logic control ranging from zone source selection volume and muting to program or scene selection and fire safety muting. Wired with readily available and affordable CAT5 cable with universally accepted RJ-45 connectors at distances up to 1000 ft the ZC Zone Controllers offer simple yet elegant solutions to the contractor.
The ZC-2 offers programmable volume and mute control for the DriveRack 220i 260 and ZonePRO products.
All information is subject to change without notice.
Product Model
ZC2
Product Name
ZC2 Wall-Mounted Zone Controller
Product Series
ZC
Product Type
Audio Control Device
